▶ EngineEngine Manufacturer YANMAR FPT Engine Model 4TNV98C R 753 IE4 Engine Type 4-cylinder, naturally aspirated diesel 3-cylinder, FPT turbocharged & aftercooled No. of Cylinders 4 3 Displacement 202.5 in³ 135.9 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 58.9 hp 60 hp PTO Power 52 hp 51 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Dual stage cyclonic (resin 6.5") Dry Fuel System Common rail direct injection Electronic high pressure common rail Alternator 55 A, 12 V 75 A ▶ HydraulicsPump Type Not Published Engine-driven dual gear-type Implement Flow 9.4 gpm 11.9 gpm Steering Flow 5.3 gpm 5.5 gpm Total Hydraulic Flow 14.7 gpm (9.4 + 5.3, computed) 17.4 gpm (11.9 + 5.5, computed) Overall Hydraulic Pump Flow 14.7 gpm (9.4 + 5.3, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 1 2 ▶ Fluid CapacityFuel Tank Capacity 12.7 gal 17.2 gal Coolant Capacity 7.8 qt Not Published Crankcase Capacity 8.0 qt Not Published Transmission / Hydraulic System Capacity 7.7 gal Not Published Front Axle Fluid Capacity 2.4 gal Not Published ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Independent PTO Rear 540 rpm 540 / 540E Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I/II Hitch Lift Capacity 3,307 lb Not Published Hitch Lift Capacity (at 24”) 2,756 lb 2,701 lb Lift Control Type Position control Mechanical Draft Control (MDC), top link sensing ▶ Transmission & DrivetrainTransmission Type I-HMT (Integrated Hydro Mechanical Transmission) 8x8 mechanical shuttle (dry clutch) No. of Speeds 3 ranges (variable speed) 8F/8R Max Travel Speed (Forward) 18 mph (with R1 tires) Not Published Max Travel Speed (Reverse) 18 mph (with R1 tires) Not Published Clutch Clutch-less shifting (i-HMT) Dry clutch Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Mechanical rear differential lock; MFD engagement mechanical; limited-slip MFD front axle ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Fully hydraulic power steering Hydrostatic Brakes Mechanical wet disc Wet disc Seat Suspension & Adjustability Not Published Contoured seat, adjustable Front Axle Type 2WD/4WD selectable engagement 2WD or MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.1 in 2WD: 129.5 in; MFD: 134.0 in Overall Width 70.6 in (with R4 tires) 67.5 in Wheelbase 77.4 in 2WD: 77.5 in; MFD: 77.7 in Ground Clearance 12.8 in (with R4 tires) Not Published Min. Turn Radius without Brakes Not Published 2WD: 135.8 in; MFD: 190.9 in Height to Top of ROPS 95.7 in (with R4 tires) 2WD: 92.7 in; MFD: 97.4 in Height to Top of ROPS (folded) Not Published 77 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 4,039 lb (with ROPS, R4 tires, full fluid) 2WD: 4,442 lb; MFD: 5,060 lb Weight with ROPS and Loader 5,135 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 (bar tread) 2WD or MFD; R4 (industrial tread) MFD R1 Agricultural - Front 8-16 2WD: 7.5x16; MFD: 8.3x24 R1 Agricultural - Rear 14.9-24 13.6x28 R3 Turf - Front 27x10.5-15 Not Published R3 Turf - Rear 44x18-20 Not Published R4 Industrial - Front 10-16.5 MFD: 12.5x18 R4 Industrial - Rear 17.5L-24 MFD: 18.4x24 ▶ Loader & AttachmentsQuick Attach Loader System YL610: Skid-steer-style loader quick attachment system Compatible loaders: L545, L555 Loader Model YL610 L545; L555 Loader Lift Height YL610: 113 in (to bucket pivot pin) L545: 106 in; L555: 105 in Loader Lift Capacity (Full Height) YL610: 2,500 lb at pivot pins L545 NSL: 1,565 lb; L545 MSL: 2,205 lb; L555 NSL: 1,940 lb; L555 MSL: 2,734 lb Loader Breakout Force YL610: 3,969 lb at pivot pins L545: 3,131 lb; L555: 3,527 lb ▶ WarrantyWarranty Length & Coverage Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty Not Published
