▶ EngineEngine Manufacturer YANMAR KIOTI (Daedong) Engine Model 4TNV98C 3F183T Engine Type 4-cylinder, naturally aspirated diesel KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI No. of Cylinders 4 3 Displacement 202.5 in³ 111.4 in³ Rated Engine Speed 2500 rpm 2600 rpm Engine Power (Gross) 58.9 hp 60 hp PTO Power 52 hp 48.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Dual stage cyclonic (resin 6.5") Dry type element Fuel System Common rail direct injection Common Rail Direct Injection (CRDI) Alternator 55 A, 12 V Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow 9.4 gpm 9.6 gpm Steering Flow 5.3 gpm 8.2 gpm Total Hydraulic Flow 14.7 gpm (9.4 + 5.3, computed) 17.9 gpm Overall Hydraulic Pump Flow 14.7 gpm (9.4 + 5.3, computed) 17.9 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 12.7 gal 14.8 gal Coolant Capacity 7.8 qt 2.0 gal Crankcase Capacity 8.0 qt 1.58 gal Transmission / Hydraulic System Capacity 7.7 gal 11.89 gal Front Axle Fluid Capacity 2.4 gal 1.8 gal ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I & II Hitch Lift Capacity 3,307 lb 3,538 lb Hitch Lift Capacity (at 24”) 2,756 lb 3,177 lb Lift Control Type Position control Position with Draft Control ▶ Transmission & DrivetrainTransmission Type I-HMT (Integrated Hydro Mechanical Transmission) Hydrostatic No. of Speeds 3 ranges (variable speed) 3 Range Max Travel Speed (Forward) 18 mph (with R1 tires) 18.26 mph Max Travel Speed (Reverse) 18 mph (with R1 tires) 18.26 mph Clutch Clutch-less shifting (i-HMT) Not Published Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Differential Lock: Rear (Standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Fully hydraulic power steering Hydrostatic Power Steering Brakes Mechanical wet disc Wet Multi Disc Seat Suspension & Adjustability Not Published Adjustable Seat Front Axle Type 2WD/4WD selectable engagement Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,655 lb (max. drawbar vertical load) ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.1 in 139.6 in Overall Width 70.6 in (with R4 tires) 65.7 in Wheelbase 77.4 in 75.6 in Ground Clearance 12.8 in (with R4 tires) 15.7 in Min. Turn Radius without Brakes Not Published 10.0 ft Height to Top of ROPS 95.7 in (with R4 tires) 103.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 94.1 in ▶ WeightTractor Weight (Base) 4,039 lb (with ROPS, R4 tires, full fluid) NX6010H: 4,198 lb; NX6010HC: 4,529 lb Weight with ROPS and Loader 5,135 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-16 9.5-16 R1 Agricultural - Rear 14.9-24 16.9-24 R3 Turf - Front 27x10.5-15 29-12.5-15 R3 Turf - Rear 44x18-20 21.5L-16.1 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 17.5L-24 17.5-24 ▶ Loader & AttachmentsQuick Attach Loader System YL610: Skid-steer-style loader quick attachment system Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator Loader Model YL610 KL6010 Loader Lift Height YL610: 113 in (to bucket pivot pin) KL6010: 108.3 in (to pivot pin) Loader Lift Capacity (Full Height) YL610: 2,500 lb at pivot pins KL6010: 2,761 lb (at pivot pin, max height) Loader Breakout Force YL610: 3,969 lb at pivot pins KL6010: 3,727 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor
