▶ EngineEngine Manufacturer YANMAR YANMAR Engine Model 4TNV98C 4TNV88C Engine Type 4-cylinder, naturally aspirated diesel 4-cylinder, naturally aspirated diesel No. of Cylinders 4 4 Displacement 202.5 in³ 133.5 in³ Rated Engine Speed 2500 rpm 2800 rpm Engine Power (Gross) 58.9 hp 46 hp PTO Power 52 hp 39.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid cooled Air Cleaner Dual stage cyclonic (resin 6.5") Dual stage cyclonic (resin 5.5") Fuel System Common rail direct injection Common rail direct injection Alternator 55 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.4 gpm 10.1 gpm Steering Flow 5.3 gpm 5.7 gpm Total Hydraulic Flow 14.7 gpm (9.4 + 5.3, computed) 15.8 gpm (10.1 + 5.7, computed) Overall Hydraulic Pump Flow 14.7 gpm (9.4 + 5.3, computed) 15.8 gpm (10.1 + 5.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 12.7 gal 12.7 gal Coolant Capacity 7.8 qt 6.2 qt Crankcase Capacity 8.0 qt 7.0 qt Transmission / Hydraulic System Capacity 7.7 gal 7.7 gal Front Axle Fluid Capacity 2.4 gal 2.4 gal ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Independent (electro-hydraulic) PTO Rear 540 rpm 540 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,307 lb 3,307 lb Hitch Lift Capacity (at 24”) 2,756 lb 2,756 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type I-HMT (Integrated Hydro Mechanical Transmission) I-HMT (Integrated Hydro Mechanical Transmission) No. of Speeds 3 ranges (variable speed) 3 ranges (variable speed) Max Travel Speed (Forward) 18 mph (with R1 tires) 18 mph (with R1 tires) Max Travel Speed (Reverse) 18 mph (with R1 tires) 18 mph (with R1 tires) Clutch Clutch-less shifting (i-HMT) Clutch-less shifting (i-HMT) Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Rear differential lock (foot pedal engagement) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Fully hydraulic power steering Fully hydraulic power steering Brakes Mechanical wet disc Mechanical wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 2WD/4WD selectable engagement 2WD/4WD selectable engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 132.1 in 130.9 in Overall Width 70.6 in (with R4 tires) 70.6 in (with R4 tires) Wheelbase 77.4 in 75.9 in Ground Clearance 12.8 in (with R4 tires) 12.8 in (with R4 tires) Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 95.7 in (with R4 tires) 95.7 in (with R4 tires) Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 4,039 lb (with ROPS, R4 tires, full fluid) 3,880 lb (with ROPS, R4 tires, full fluid) Weight with ROPS and Loader 5,135 lb 4,976 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural - Front 8-16 8-16 R1 Agricultural - Rear 14.9-24 14.9-24 R3 Turf - Front 27x10.5-15 27x10.5-15 R3 Turf - Rear 44x18-20 44x18-20 R4 Industrial - Front 10-16.5 10-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System YL610: Skid-steer-style loader quick attachment system YL610: Skid-steer-style loader quick attachment system Loader Model YL610 YL610 Loader Lift Height YL610: 113 in (to bucket pivot pin) YL610: 113 in (to bucket pivot pin) Loader Lift Capacity (Full Height) YL610: 2,500 lb at pivot pins YL610: 2,500 lb at pivot pins Loader Breakout Force YL610: 3,969 lb at pivot pins YL610: 3,969 lb at pivot pins ▶ WarrantyWarranty Length & Coverage Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
