▶ EngineEngine Manufacturer YANMAR John Deere Engine Model 4TNV98C John Deere PowerTech 3029 Engine Type 4-cylinder, naturally aspirated diesel Diesel, turbocharged, liquid-cooled No. of Cylinders 4 3 Displacement 202.5 in³ 179 in³ Rated Engine Speed 2500 rpm 2100 rpm Engine Power (Gross) 58.9 hp 59 hp PTO Power 51.4 hp 41 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid-cooled Air Cleaner Dual stage cyclonic (resin 6.5") Dry type, dual element (primary and secondary) Fuel System Common rail direct injection Not Published Alternator 55 A, 12 V 40 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.4 gpm 11.4 gpm Steering Flow 5.3 gpm 6.8 gpm Total Hydraulic Flow 14.7 gpm (9.4 + 5.3, computed) 18.2 gpm Overall Hydraulic Pump Flow 14.7 gpm (9.4 + 5.3, computed) 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 1 2 ▶ Fluid CapacityFuel Tank Capacity 12.7 gal OOS: 19.6 gal; Cab: 21.6 gal Coolant Capacity 7.8 qt 10 qt Crankcase Capacity 8.0 qt 9 qt Transmission / Hydraulic System Capacity 7.7 gal 10.3 gal Front Axle Fluid Capacity 2.4 gal Dana axle: differential housing 1.18 gal, wheel hub (each) 0.21 gal; Carraro axle: differential housing 1.03 gal, reduction gear oil (each side) 0.15 gal ▶ PTO & HitchPTO Type Continuous live independent (electric hydro) Independent; mechanical engagement (SyncShuttle); electrohydraulic engagement (PowrReverser) PTO Rear 540 rpm 540 rpm (540E optional with PowrReverser) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I Category II, convertible to I Hitch Lift Capacity 3,307 lb Not Published Hitch Lift Capacity (at 24”) 2,756 lb 3,192 lb Lift Control Type Position control Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type I-HMT (Integrated Hydro Mechanical Transmission) SyncShuttle (standard); PowrReverser (optional) No. of Speeds 3 ranges (variable speed) 9F/3R (SyncShuttle); 12F/12R (PowrReverser optional) Max Travel Speed (Forward) 18 mph (with R1 tires) Not Published Max Travel Speed (Reverse) 18 mph (with R1 tires) Not Published Clutch Clutch-less shifting (i-HMT) Dry (SyncShuttle); wet (12F/12R PowrReverser) Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Differential lock, standard; pedal-operated, mechanical ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Fully hydraulic power steering Power steering Brakes Mechanical wet disc Hydraulic wet disc brakes Seat Suspension & Adjustability Not Published Not Published Front Axle Type 2WD/4WD selectable engagement 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 1,675 lb (fully extended); 2,470 lb (short position) ▶ Dimensions & ManeuverabilityOverall Width 70.6 in (with R4 tires) 57.3 in Wheelbase 77.4 in 80.7 in Ground Clearance 12.8 in (with R4 tires) 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes Not Published 11.5 ft (2WD); 15.3 ft (4WD); 12.8 ft (4WD, Carraro axle) Height to Top of ROPS Not Published 96.4 in Height to Top of ROPS (folded) Not Published 77.1 in Height to Top of Cab Model 89.5 in (with R4 tires) 94.3 in Overall Length 132.1 in (with 3-point hitch and R4 tires) 137.8 in ▶ WeightTractor Weight (Base) 4,442 lb (cab, R4 tires, full fluid) 2WD: 4,524 lb; MFWD: 5,511 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 5,538 lb (4,442 + 1,096, computed) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial Not Published R1 Agricultural - Front 8-16 MFWD: 9.5-24; 280/85R24 (11.2R24) R1W Radial R1 Agricultural - Rear 14.9-24 14.9-28 R3 Turf - Front 27x10.5-15 9.5-16 R3 Turf - Rear 44x18-20 21.5L-16.1; 22.5LL-16.1 (Turf Special) R4 Industrial - Front 10-16.5 12.5/80-18 R4 Industrial - Rear 17.5L-24 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System YL610: Skid-steer-style loader quick attachment system 520M; H240 (NSL or MSL) Loader Model YL610 H240NSL Loader Lift Height YL610: 113 in (to bucket pivot pin) 131 in Loader Lift Capacity (Full Height) YL610: 2,500 lb at pivot pins 3,671 lb (H240NSL, at pivot) Loader Breakout Force YL610: 3,969 lb at pivot pins 4,504 lb (H240NSL, at pivot) ▶ WarrantyWarranty Length & Coverage Tractor (private individual usage) 24 months or 2,000 hours; power train 10 years or 3,000 hours; attachments 1-year limited warranty Not Published
