Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
YanmarYT359C
No photo
—
TYM5835
Comparison loaded for 2 tractors.
Spec
YanmarYT359C
TYM5835
PTO Power
52.0 hp (38.3 kW)
48 hp (35 kW)
Alternator
12 V, 55 A
12 V, 70 A
Air Cleaner
Dual stage cyclonic (resin 6.5")
Dry element
Engine Type
4-cylinder, naturally aspirated diesel
4-cylinder, turbocharged diesel
Fuel System
Common rail direct injection
IDI
Displacement
202.5 in³ (3,318 cc)
139.5 in³ (2,286 cc)
No. of Cylinders
4
4
Rated Engine Speed
2,500 rpm
2,600 rpm
Cooling System Type
Liquid cooled
Not Published
Engine Manufacturer
YANMAR
TYM
Engine Emissions Constraints
Tier 4
Tier 4
Engine Power (Gross vs. Net HP)
Gross: 58.9 hp (43.9 kW)
Gross: 58 hp (42.5 kW)
Tractor Weight with Loader
5,538 lb (2,512 kg)
Not Published
Weight with Cab and Loader
5,538 lb (2,512 kg)
Not Applicable
Weight with ROPS and Loader
Not Applicable
Not Published
Pump Type
Not Published
Single gear pump
Steering Flow
20.1 L/min (5.3 gpm)
19.4 L/min (5.2 gpm)
Implement Flow
35.5 L/min (9.4 gpm)
43.2 L/min (11.4 gpm)
Total Hydraulic Flow
55.6 L/min (14.7 gpm)
62.6 L/min (16.5 gpm)
Hydraulic System Type
Open center
Not Published
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
55.6 L/min (14.7 gpm)
62.6 L/min (16.5 gpm)
No. of Optional Remote Valves
1
Not Published
No. of Standard Remote Valves
2
Loader: 4; Rear: 2
R3 Turf - Rear
44 x 18 - 20.0
Not Published
R3 Turf - Front
27.0 - 10.5
Not Published
Tire Size & Options
R1 Agricultural; R3 Turf; R4 Industrial
R1 Agricultural, R4 Industrial
R4 Industrial - Rear
17.5L - 24.0
16.9–24
R4 Industrial - Front
10.0 - 16.5
10.5/80-18
R1 Agricultural - Rear
14.9 - 24.0
14.9–28
R1 Agricultural - Front
8.0 - 16.0
9.5–20
PTO Rear
540 rpm
540 rpm
PTO Type
Independent (electro-hydraulic)
Independent
Lift Control Type
Position control
Mechanical
Hitch Lift Capacity
3,307 lb (1,500 kg)
4,409 lb (2,000 kg)
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category I
Category II
Hitch Lift Capacity (at 24”)
2,756 lb (1,250 kg)
3,748 lb (1,700 kg)
Rear 3-Point Hitch Lift Capacity
3,307 lb (1,500 kg)
4,409 lb (2,000 kg)
Coolant Capacity
7.8 qt (7.4 L)
6.2 qt (5.9 L)
Crankcase Capacity
8.0 qt (7.6 L)
4.8 qt (4.5 L)
Fuel Tank Capacity
12.7 gal (48 L)
15.3 gal (58 L)
Front Axle Fluid Capacity
2.4 gal (9 L)
6.8 qt (6.4 L)
Transmission / Hydraulic System Capacity
7.7 gal (29 L)
11.6 gal (44 L)
Loader Lift Height
113 in (2,870 mm)
117.5 in (2,984 mm)
Loader Breakout Force
3,969 lb (1,800 kg)
4,742 lb (2,151 kg)
Price for Backhoe Option
B90: $17,560
BH350
Price for Mid-Mount Mower
Not Published
Not Published
Quick Attach Loader System
YL610: Skid-steer-style loader quick attachment system
BL350: Quick attachment assembly
Loader Lift Capacity (Full Height)
2,500 lb (1,134 kg)
3,437 lb (1,559 kg)
Clutch
Clutch-less shifting (i-HMT)
Wet, multi-disc
No. of Speeds
3 ranges (variable speed)
F12 x R12
Transmission Type
I-HMT (Integrated Hydro Mechanical Transmission)
Power shuttle
Max Travel Speed (Forward)
18 mph (29 km/h)
19.9 mph (32 km/h)
Max Travel Speed (Reverse)
18 mph (29 km/h)
Not Published
Differential Lock & Limited Slip Options
Rear differential lock (foot pedal engagement)
Not Published
Brakes
Mechanical wet disc
Wet, multi-disc
Steering
Fully hydraulic power steering
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
Selectable 2WD/4WD engagement
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Suspension seat
Wheelbase
77.4 in (1,967 mm)
78.7 in (2,000 mm)
Overall Width
70.6 in (1,793 mm)
68.9 in (1,750 mm)
Ground Clearance
12.8 in (326 mm)
18.1 in (460 mm)
Height to Top of ROPS
Not Applicable
102.8 in (2,611 mm)
Height to Top of Cab Model
89.5 in (2,274 mm)
Not Applicable
Height to Top of ROPS (folded)
Not Published
Not Published
Min. Turn Radius without Brakes
Not Published
L: 124.4 in (3,160 mm); R: 124.0 in (3,150 mm)
Overall Length with 3-Point Hitch
132.1 in (3,355 mm)
136.4 in (3,465 mm)
Financing Options
See Exclusive Offers (promotions vary)
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
Not Applicable
Not Published
Warranty Length & Coverage
Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
