Open center, full-live hydraulic with position control
Rear Remote Hydraulic Flow
Not Published
Not Published
No. of Standard Remote Valves
Not Published
Not Published
No. of Optional Remote Valves
Not Published
Single or dual
Fuel Tank Capacity
5.8 gal
5.8 gal
Coolant Capacity
0.95 gal
Not Published
Crankcase Capacity
0.71 gal
Not Published
Transmission / Hydraulic System Capacity
3.83 gal
Not Published
Front Axle Fluid Capacity
0.85 gal
Not Published
PTO Type
Independent
Live
PTO Rear
540 rpm
540 rpm @ 2376 rpm
Mid-PTO Availability
Standard, 2,000 rpm
2500 rpm @ 2500 rpm
Category, 3-Point Hitch
Category I (N)
CAT I with telescoping stabilizers
Hitch Lift Capacity
1,323 lb
Not Published
Hitch Lift Capacity (at 24”)
1,101 lb
1760 lb
Lift Control Type
Position control
Not Published
Transmission Type
Hydrostatic (HST) with mechanical H/L constant-mesh range
HST, 3 range
No. of Speeds
2 range (H/L)
Infinite
Max Travel Speed (Forward)
10.5 mph (H range, Ag tires)
Not Published
Max Travel Speed (Reverse)
Not Published
Not Published
Clutch
None (HST)
Not Published
Differential Lock & Limited Slip Options
Rear differential lock (bevel gears with diff-lock)
Not Published
Frame Type
Sub-compact tractor; selectable 4WD
Not Published
Steering
Hydrostatic power steering
Hydrostatic power
Brakes
Wet disc, foot operated
Two pedal
Seat Suspension & Adjustability
Not Published
Not Published
Front Axle Type
Selectable 4WD
Not Published
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Length with 3-Point Hitch
104 in
112.7 in
Overall Width
45.8 in
54.4 in
Wheelbase
57.5 in
Not Published
Ground Clearance
9.4 in
Not Published
Min. Turn Radius without Brakes
Not Published
8.2 ft
Height to Top of ROPS
91.3 in
93.6 in
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
Not Published
84.4 in
Tractor Weight (Base)
1,610 lb
2123 OS: 2101 lb; 2123/2126 Cab: 2607 lb
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
Not Published
R1 Agricultural - Front
6-12
Not Published
R1 Agricultural - Rear
9.5-16
Not Published
R3 Turf - Front
20x8-10
8.5 x 14
R3 Turf - Rear
29x12.5-15
13.5 - 16
R4 Industrial - Front
23x8.5-12
8.5 x 14
R4 Industrial - Rear
12-16.5
12.4 - 16
Quick Attach Loader System
Quick attach front loader
Not Published
Loader Model
BBL105
L21
Loader Lift Height
75.5 in
L21: 77 in
Loader Lift Capacity (Full Height)
992 lb
L21: 1477 lb
Loader Breakout Force
1,531 lbf
L21: 2160 lb
Warranty Length & Coverage
Engine and powertrain: 84 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours
