Bad Boy Tractors 5045 vs New Holland Boomer 55

Across 9 measurable specs, the New Holland Boomer 55 leads 5 categories to 4. Machine pages: Bad Boy Tractors 5045 and New Holland Boomer 55.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors5045	New HollandBoomer 55

▶Engine
Engine Manufacturer	TYM	LS Mtron
Engine Model	A2300N2	L3CRV-T7
Engine Type	4 cylinder water-cooled diesel, naturally aspirated	3-cylinder, turbocharged, liquid-cooled diesel
No. of Cylinders	4	3
Displacement	139.5 in³	114.7 in³
Rated Engine Speed	2600 rpm	2600 rpm
Engine Power (Gross)	48 hp	55 hp
PTO Power	38.4 hp	Gear: 46.7 hp; HST: 44 hp
Engine Emissions Constraints	Tier 4	Tier 4B (final)
Cooling System Type	Water-cooled	Liquid cooled
Air Cleaner	Dry element	Replaceable primary and inner elements
Fuel System	Not Published	Electronically controlled common rail direct injection
Alternator	50 A, 12 V	ROPS: 70 A; Cab: 85 A
▶Hydraulics
Pump Type	Not Published	Gear
Implement Flow	10.7 gpm	8.2 gpm
Steering Flow	5 gpm	Gear: 4.2 gpm; HST: 5.3 gpm
Total Hydraulic Flow	15.7 gpm	Gear: 12.4 gpm; HST: 13.5 gpm
Overall Hydraulic Pump Flow	15.7 gpm	Gear: 12.4 gpm; HST: 13.5 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	Not Published	1
No. of Optional Remote Valves	Up to 4 ports	Up to 2 (second valve optional)
▶Fluid Capacity
Fuel Tank Capacity	11.8 gal	ROPS: 10.5 gal; Cab: 12.4 gal
Coolant Capacity	2.08 gal	2.3 gal
Crankcase Capacity	1.20 gal	5.8 qt
Transmission / Hydraulic System Capacity	10.04 gal	11.4 gal
Front Axle Fluid Capacity	1.90 gal	2.2 gal
▶PTO & Hitch
PTO Type	Independent	Independent, electro-hydraulic engagement
PTO Rear	540 / 540E rpm	540 rpm
Mid-PTO Availability	Not Published	Standard (2000 rpm)
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	3,306 lb	2,756 lb
Hitch Lift Capacity (at 24”)	2,425 lb	2,116 lb
Lift Control Type	Position control	Position control (draft control optional)
▶Transmission & Drivetrain
Transmission Type	Hydrostatic (HST), 4-range	Gear: 16x16 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal
No. of Speeds	4 range (HST)	Gear: 16F/16R; HST: 3-range
Max Travel Speed (Forward)	19.5 mph	Gear: 17.0 mph; HST: 17.9 mph
Max Travel Speed (Reverse)	19.5 mph	Gear: 15.3 mph; HST: 11.37 mph
Clutch	None (HST)	Gear: dry single disc (10.8 in); HST: n/a
Differential Lock & Limited Slip Options	Rear differential lock (standard)	Mechanical rear differential lock (pedal)
▶Chassis, Steering & Controls
Frame Type	Compact utility tractor, 4WD	Not Published
Steering	Hydrostatic power steering	Power steering
Brakes	Wet, multi-disc	Wet multi-disc
Seat Suspension & Adjustability	Deluxe suspension seat	ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth suspension seat with weight control, fore/aft adjustment and adjustable armrests
Front Axle Type	Selectable 4WD	Four-wheel drive (FWD)
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Short position: 2,317 lb; Regular position: 1,598 lb; Extended position: 1,091 lb
▶Dimensions & Maneuverability
Overall Width	64.9 in	69.1 in
Wheelbase	71.1 in	73.2 in
Ground Clearance	15.5 in	15 in
Min. Turn Radius without Brakes	9.18 ft (with brake applied)	111.8 in (right turn); 123.2 in (left turn) (with brake applied)
Height to Top of ROPS	98.4 in	97.1 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	Not Applicable	94 in
Overall Length	127.4 in (with 3-point hitch)	128.1 in
▶Weight
Tractor Weight (Base)	3,831 lb	ROPS Gear: 3,424 lb; ROPS HST: 3,490 lb; Cab: 4,194 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	9.5-16 front / 12.4-28 rear (ag)	R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural - Front	9.5-16	9.5-16
R1 Agricultural - Rear	12.4-28	13.6-24
R3 Turf - Front	Not Published	28x8.50-15
R3 Turf - Rear	Not Published	41x14.00-20
R4 Industrial - Front	Not Published	12x16.5
R4 Industrial - Rear	Not Published	17.5Lx24
▶Loader & Attachments
Quick Attach Loader System	SSQA	Tool-free loader mount; optional skid-steer quick-attach plates
Loader Model	BBL500	260TLA
Loader Lift Height	106.6 in	260TLA: 109 in (at pivot pin)
Loader Lift Capacity (Full Height)	2,700 lb (at pivot pin)	260TLA: 2,371 lb (at bucket pivot pin, max height)
Loader Breakout Force	3,660 lb	260TLA: 4,081 lb (at bucket pivot pin)
▶Warranty
Warranty Length & Coverage	Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours	Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total)
▶ITC Company Accessories
Accessories that fit	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00	None tagged yet

Find a Bad Boy dealer near you→Find a New Holland dealer near you→

Bad Boy Tractors 5045 vs New Holland Boomer 55: Quick Answers

Which has more horsepower, the Bad Boy Tractors 5045 or the New Holland Boomer 55?

The New Holland Boomer 55 leads on engine hp at 55 hp hp, compared to 48 hp hp for the Bad Boy Tractors 5045.

Which has more PTO horsepower, the Bad Boy Tractors 5045 or the New Holland Boomer 55?

The New Holland Boomer 55 leads on pto hp at 46.7 hp hp, compared to 38.4 hp hp for the Bad Boy Tractors 5045.

Which is heavier, the Bad Boy Tractors 5045 or the New Holland Boomer 55?

The New Holland Boomer 55 leads on weight at 4,194 lb lb, compared to 3,831 lb lb for the Bad Boy Tractors 5045.

Which has more loader lift capacity, the Bad Boy Tractors 5045 or the New Holland Boomer 55?

The Bad Boy Tractors 5045 leads on loader lift at 2,700 lb lb, compared to 2,371 lb lb for the New Holland Boomer 55.

Which has more three-point hitch lift capacity, the Bad Boy Tractors 5045 or the New Holland Boomer 55?

The Bad Boy Tractors 5045 leads on 3-pt lift (24 in) at 2,425 lb lb, compared to 2,116 lb lb for the New Holland Boomer 55.
