Bobcat CT4050 vs Kioti DK5320

Across 9 measurable specs, the Kioti DK5320 leads 4 categories to 3 (2 tied). Machine pages: Bobcat CT4050 and Kioti DK5320.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	BobcatCT4050	KiotiDK5320

▶Engine
Engine Manufacturer	Daedong	KIOTI (Daedong)
Engine Model	3FT-TL4-U	3HT-TH4C
Engine Type	Turbocharged diesel	3-cylinder, liquid-cooled diesel
No. of Cylinders	3	3
Displacement	111.4 in³	111.4 in³
Rated Engine Speed	2600 rpm	2600 rpm
Engine Power (Gross)	50.3 hp	50.3 hp
PTO Power	45.6 hp	39.3 hp
Engine Emissions Constraints	Tier 4	Tier 4
Cooling System Type	Water-cooled	Liquid-cooled
Air Cleaner	Dry type, replaceable	Dry element
Fuel System	Common rail direct injection (CRDI)	Not Published
Alternator	75 A, 12 V	Not Published
▶Hydraulics
Pump Type	Not Published	Gear
Implement Flow	9.6 gpm	9.62 gpm
Steering Flow	4.5 gpm	6.87 gpm
Total Hydraulic Flow	14.1 gpm	16.5 gpm
Overall Hydraulic Pump Flow	14.1 gpm	16.5 gpm
Hydraulic System Type	Open center	Not Published
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	None standard; 2 pairs optional	2
No. of Optional Remote Valves	2 pairs	Not Published
▶Fluid Capacity
Fuel Tank Capacity	11.9 gal	12.7 gal
Coolant Capacity	3.5 qt	2.1 gal
Crankcase Capacity	7.8 qt	1.95 gal
Transmission / Hydraulic System Capacity	11.4 gal	11.4 gal
Front Axle Fluid Capacity	5.9 qt	1.48 gal
▶PTO & Hitch
PTO Type	Independent	Independent
PTO Rear	540 rpm	540 rpm
Mid-PTO Availability	Not Published	Optional (2,000 rpm)
Category, 3-Point Hitch	Category 1	Category I
Hitch Lift Capacity	Not Published	2,998 lb
Hitch Lift Capacity (at 24”)	2716 lb	2,716 lb
Lift Control Type	Hydraulic position control	Position
▶Transmission & Drivetrain
Transmission Type	8F x 8R synchro shuttle (SST)	Hydrostatic (HST)
No. of Speeds	HST: Infinite (3 ranges); SST: 8 forward, 8 reverse	3 ranges (hydrostatic, infinite speeds)
Max Travel Speed (Forward)	17.5 mph	18.45 mph
Max Travel Speed (Reverse)	17.1 mph	12.92 mph
Clutch	Not Published	None (hydrostatic transmission)
Differential Lock & Limited Slip Options	Rear differential lock, standard	Rear differential lock (standard)
▶Chassis, Steering & Controls
Frame Type	Not Published	Not Published
Steering	Hydrostatic power steering	Hydrostatic power steering
Brakes	Wet multi-disc	Wet multi-disc
Seat Suspension & Adjustability	Adjustable seat (standard)	Deluxe suspension seat
Front Axle Type	4WD with hydraulic multi-disc clutch engagement	Mechanical 4WD
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	1653 lb	1,655 lb (max. drawbar vertical load)
▶Dimensions & Maneuverability
Overall Length with 3-Point Hitch	125.5 in	125.5 in
Overall Width	70.3 in	62.8 in
Wheelbase	71.2 in	71.3 in
Ground Clearance	15.3 in	14.5 in
Min. Turn Radius without Brakes	103.5 in (with brake applied)	102.8 in (with brake applied)
Height to Top of ROPS	97.4 in	96.8 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	n/a (open-station ROPS model)	93.0 in
▶Weight
Tractor Weight (Base)	3745 lb	3,523 lb (DK5320SEH); 4,043 lb (DK5320SEH CAB)
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	n/a (open-station ROPS model)	Not Published
▶Tire Options
Tire Size & Options	Agricultural (R1), Turf (R3), Industrial (R4)	R1 Agricultural, R3 Turf, R4 Industrial, R14
R1 Agricultural - Front	8-16	8-16
R1 Agricultural - Rear	13.6-24	13.6-24
R3 Turf - Front	29x12.5-15NHS	29-12.5-15
R3 Turf - Rear	44x18.0-20	21.5L-16.1
R4 Industrial - Front	10-16.5	10-16.5
R4 Industrial - Rear	17.5L-24	14.9-24
▶Loader & Attachments
Quick Attach Loader System	Standard quick attach mounting system	Quick attach (QA) bucket, 66 in or 72 in
Loader Model	FL9	KL5520; KL5521 (Cab models)
Loader Lift Height	103.2 in	KL5520: 107.7 in; KL5521: 107.7 in
Loader Lift Capacity (Full Height)	1795 lb	KL5520: 2,474 lb; KL5521: 2,474 lb
Loader Breakout Force	4136 lb	KL5520: 3,895 lb; KL5521: 3,895 lb
▶Warranty
Warranty Length & Coverage	24 months or 1,500 hours, whichever occurs first (defects in material and workmanship)	Non-commercial: 24 months, unlimited hours, parts and labor, 0% deductible; non-commercial powertrain (engine and driveline): 72 months, unlimited hours
▶ITC Company Accessories
Accessories that fit	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection	Kioti DK10/20 & CK10/20 with 6 bolt Grill Guard Brush Screen Insert $250.00

Find a dealer near you→Find a KIOTI dealer near you→

Bobcat CT4050 vs Kioti DK5320: Quick Answers

Which has more horsepower, the Bobcat CT4050 or the Kioti DK5320?

They are effectively tied: both machines are rated at 50.3 hp hp for engine hp.

Which has more PTO horsepower, the Bobcat CT4050 or the Kioti DK5320?

The Bobcat CT4050 leads on pto hp at 45.6 hp hp, compared to 39.3 hp hp for the Kioti DK5320.

Which is heavier, the Bobcat CT4050 or the Kioti DK5320?

The Bobcat CT4050 leads on weight at 3,745 lb lb, compared to 3,523 lb lb for the Kioti DK5320.

Which has more loader lift capacity, the Bobcat CT4050 or the Kioti DK5320?

The Kioti DK5320 leads on loader lift at 2,474 lb lb, compared to 1,795 lb lb for the Bobcat CT4050.

Which has more three-point hitch lift capacity, the Bobcat CT4050 or the Kioti DK5320?

They are effectively tied: both machines are rated at 2,716 lb lb for 3-pt lift (24 in).
