▶ EngineEngine Manufacturer FPT FPT Engine Model Not Published F5D Engine Type 4-cylinder diesel Turbocharged and intercooled 4-cylinder diesel No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 99 hp 98 hp PTO Power 85 hp 82 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dual dry element Fuel System High-pressure common rail electronic direct injection Electronic high-pressure common rail direct injection Alternator Not Published 120 A ▶ HydraulicsPump Type Not Published Dual engine-driven pumps (open center) Implement Flow 16.9 gpm 12.5 gpm (16.9 gpm optional) Steering Flow 9.7 gpm 7.3 gpm Total Hydraulic Flow 26.6 gpm (16.9 + 9.7, computed) 19.8 gpm (12.5 + 7.3, computed) Overall Hydraulic Pump Flow 26.6 gpm (16.9 + 9.7, computed) 19.8 gpm (12.5 + 7.3, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves 3 (3rd through Parts) 2 (3rd remote available through Parts Division) ▶ Fluid CapacityFuel Tank Capacity 42.3 gal 30.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent, mechanical engagement PTO Rear Not Published 540/1000 (base); 540 (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II with flex link ends Category II (ball ends convert to Category I) Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,339 lb (5,620 lb with auxiliary lift ram) 5,620 lb Lift Control Type Mechanical draft control (MDC), top link sensing (12x12); electronic draft control (EDC), lower link sensing (Hi-Lo cab) Single-lever position control with draft-sensing top link ▶ Transmission & DrivetrainTransmission Type Not Published Not Published No. of Speeds 12F/12R (20F/20R creeper, 24F/24R Hi-Lo or 40F/40R Hi-Lo creeper optional) 12F/12R (20F/12R or 20F/20R with creeper optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch (power shuttle and Hi-Lo) Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock (12x12); electrohydraulic (Hi-Lo); MFD front axle with limited slip Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet disc (mechanical on ROPS, hydraulic on cab) Seat Suspension & Adjustability Air suspension seat with 15-degree swivel (optional); instructional seat (optional) Air suspension seat with 15-degree swivel (optional, cab) Front Axle Type HD 2WD, MFD or HD MFD with limited slip (12x12); HD MFD with limited slip (Hi-Lo) 2WD or MFD (mechanical front drive) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 160 in (MFD cab) 149 in (MFD cab, 16.9R-34 rear tires) Overall Width 76 in (across standard fenders) 83 in Wheelbase 90 in (MFD) 89 in (MFD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 106 in (18.4R34 rear tires) 103 in Height to Top of ROPS (folded) 82.9 in (18.4R34 rear tires) Not Published Height to Top of Cab Model 102 in 100 in ▶ WeightTractor Weight (Base) Not Published 7,937 lb (MFD cab, 16.9R-34 rear tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural or turf, radial or bias; 18.4R34 rear reference tire Not Published R1 Agricultural - Front 7.50-16 (2WD); 11.2R24 or 14.9R24 (4WD) Not Published R1 Agricultural - Rear 18.4R34 (reference tire) 16.9R-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid steer-style quick attach (hydraulic coupler) Loader Model L620; L630 L620; L630; L735 Loader Lift Height L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL) L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL); L735: 137 in Loader Lift Capacity (Full Height) L620: 2,478 lb (NSL) / 3,179 lb (MSL); L630: 2,632 lb (NSL) / 3,428 lb (MSL) (at 31.5 in forward of pivot pin) L620: 3,461 lb (NSL) / 3,573 lb (MSL); L630: 3,849 lb (NSL) / 4,204 lb (MSL); L735: 4,034 lb (NSL) / 3,505 lb (MSL) Loader Breakout Force Not Published L620: 5,530 lb (NSL) / 5,483 lb (MSL); L630: 6,649 lb (NSL) / 6,767 lb (MSL); L735: 4,960 lb (NSL) / 4,122 lb (MSL) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
