▶ EngineEngine Manufacturer FPT FPT Engine Model Not Published F5D Engine Type 4-cylinder diesel, electronic high-pressure common rail 4-cylinder diesel No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 105 hp 106 hp PTO Power 91 hp 91 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Electronic high-pressure common rail Not Published Alternator 120 A 120 A ▶ HydraulicsPump Type Not Published Gear pumps Implement Flow 17.2 gpm (22.2 gpm optional) T5.105: 16.1 gpm (21.1 gpm optional); T5.105 Electro Command: 21.1 gpm (16.1 gpm optional) Steering Flow 10 gpm (11.4 gpm optional) T5.105: 10.0 gpm (11.4 gpm optional); T5.105 Electro Command: 11.4 gpm (10.0 gpm optional) Total Hydraulic Flow 27.2 gpm (17.2 + 10, computed) T5.105: 26.1 gpm (16.1 + 10.0, computed); T5.105 Electro Command: 32.5 gpm (21.1 + 11.4, computed) Overall Hydraulic Pump Flow 27.2 gpm (17.2 + 10, computed) T5.105: 26.1 gpm (16.1 + 10.0, computed); T5.105 Electro Command: 32.5 gpm (21.1 + 11.4, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 (3 optional) No. of Optional Remote Valves 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 37 gal 37 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic clutch PTO Rear Not Published 540/1000 Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 6,393 lb T5.105: 6,393 lb (10,452 lb with 2 optional rams); T5.105 Electro Command: 6,393 lb (8,809 lb with 1 optional ram, 10,452 lb with 2) Lift Control Type Electronic draft control (EDC) with rear fender switch Electronic draft control ▶ Transmission & DrivetrainTransmission Type Not Published T5.105: 12x12 power shuttle (standard), 20x20 power shuttle with creeper or 24x24 Dual Command power shuttle (optional); T5.105 Electro Command: 16x16 power shuttle (standard), 32x32 power shuttle with creeper (optional) No. of Speeds 12F/12R (20F/20R or 24F/24R optional) T5.105: 12F/12R (20F/20R or 24F/24R optional); T5.105 Electro Command: 16F/16R (32F/32R optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet disc, electro-hydraulic power shuttle Not Published Differential Lock & Limited Slip Options Not Published Electro-hydraulic rear differential lock; limited slip front ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Hydraulic wet disc Hydraulic wet disc Seat Suspension & Adjustability Heated air suspension seat with 15-degree swivel (optional) Numerous seat options including a premium low-frequency heated air-suspension seat; full-size instructor seat available Front Axle Type MFD (four-wheel drive) Heavy-duty 4WD front axle (standard) Front Axle Rating Not Published 4,500 lb (in-action capacity at 4 mph) Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 164 in (16.9R-34 rear tires) T5.105: 163.8 in; T5.105 Electro Command: 165.0 in Overall Width 75 in (minimum) 82.6 in Wheelbase 92.5 in 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103 in (16.9R-34 rear tires) T5.105: 105.4 in; T5.105 Electro Command: 105.6 in (non-suspended cab), 107.2 in (suspended cab) ▶ WeightTractor Weight (Base) 9,370 lb (cab, MFD, 16.9R-34 rear tires) T5.105: 9,370 lb; T5.105 Electro Command: 9,700 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural; 16.9R-34 rear reference tire; 38 in rear tires available Not Published R1 Agricultural - Front 14.9R24 Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quick-Latch loader mounting with Quick-Attach faceplate Skid-steer-style or European-style Loader Model L735 (NSL or MSL); L745 (NSL or MSL) 825TL; 835TL (each NSL or MSL) Loader Lift Height L735: 135 in (11 ft 3 in); L745: 146.75 in (12 ft 2.75 in) 825TL: 138 in; 835TL: 146 in Loader Lift Capacity (Full Height) L735: 2,844 lb (NSL) / 2,954 lb (MSL); L745: 3,616 lb (NSL) / 3,814 lb (MSL) (at 31.5 in forward of pivot pin, max height) 825TL NSL: 2,843 lb; 825TL MSL: 2,954 lb; 835TL NSL: 3,483 lb; 835TL MSL: 3,681 lb Loader Breakout Force L735: 2,976 lb (NSL) / 3,285 lb (MSL); L745: 3,858 lb (NSL) / 4,254 lb (MSL) (boom breakout at 31.5 in) 825TL NSL: 2,976 lb; 825TL MSL: 3,284 lb; 835TL NSL: 3,725 lb; 835TL MSL: 4,100 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
