| Engine Manufacturer | FPT | Fiat Powertrain Technologies (FPT) |
|---|
| Engine Model | Not Published | F36 |
|---|
| Engine Type | 4-cylinder, turbocharged and aftercooled | 4-cylinder diesel, turbocharged and aftercooled |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 219.7 in³ | 220 in³ |
|---|
| Rated Engine Speed | 2300 rpm | 2300 rpm |
|---|
| Engine Power (Gross) | 117 hp | 115.3 hp |
|---|
| PTO Power | 99 hp | Not Published |
|---|
| Engine Emissions Constraints | Tier 4 | Stage V Compliant with ECOBlue Compact HI-eSCR + Light CEGR |
|---|
| Cooling System Type | Not Published | Not Published |
|---|
| Air Cleaner | Not Published | Not Published |
|---|
| Fuel System | Not Published | Common rail fuel injection |
|---|
| Alternator | Not Published | Not Published |
|---|
|
|---|
| Pump Type | Not Published | Open center, dual pumps: implement pump plus dedicated steering pump |
|---|
| Implement Flow | 21.7 gpm | 21.7 gpm |
|---|
| Steering Flow | Not Published | 9.7 gpm |
|---|
| Total Hydraulic Flow | Not Published | 31.4 gpm (21.7 + 9.7, computed) |
|---|
| Overall Hydraulic Pump Flow | Not Published | 31.4 gpm (21.7 + 9.7, computed) |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 2 | 2 rear remotes (four couplers) |
|---|
| No. of Optional Remote Valves | 3 (or 3 with diverter) | 1 (3rd rear remote, optional); 3rd rear remote with 1 diverter (optional) |
|---|
|
|---|
| Fuel Tank Capacity | 34.3 gal | 34.3 gal |
|---|
| Coolant Capacity | Not Published | Not Published |
|---|
| Crankcase Capacity | Not Published | Not Published |
|---|
| Transmission / Hydraulic System Capacity | Not Published | Not Published |
|---|
| Front Axle Fluid Capacity | Not Published | Not Published |
|---|
|
|---|
| PTO Type | Not Published | Fully-independent, electrohydraulic, wet-clutch |
|---|
| PTO Rear | Not Published | 540/1000 rpm (standard, interchangeable) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II with flex link ends | Category II |
|---|
| Hitch Lift Capacity | Not Published | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 4,123 lb (6,938 lb optional) | 4,123 lb (standard); 6,938 lb (with 2 aux rams, optional) |
|---|
| Lift Control Type | 12x12: mechanical draft control, top link sensing; Hi-Lo: electronic draft control, lower link sensing | 12x12: mechanical draft control; Dual Command: electronic draft control |
|---|
|
|---|
| Transmission Type | 12x12 electronic power shuttle (standard); 20x20 electronic power shuttle with creeper (optional) | 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (all available); column-mounted electronic power shuttle |
|---|
| No. of Speeds | 12F/12R (20F/20R with creeper optional) | 12x12, 20x20 with creeper, or 24x24 Dual Command (all available) |
|---|
| Max Travel Speed (Forward) | Not Published | 25 mph |
|---|
| Max Travel Speed (Reverse) | Not Published | Not Published |
|---|
| Clutch | Not Published | Not Published |
|---|
| Differential Lock & Limited Slip Options | Electro-hydraulic differential lock; Class 1.0 MFD front axle with limited slip | Electrohydraulic differential lock |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Not Published | Not Published |
|---|
| Brakes | Not Published | Not Published |
|---|
| Seat Suspension & Adjustability | Not Published | Air-suspension cloth seat |
|---|
| Front Axle Type | Class 1.0 MFD with limited slip | 4WD heavy-duty, class 1.5 front axle (standard) |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Width | Not Published | 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) |
|---|
| Wheelbase | 92.5 in (MFD) | 92.5 in |
|---|
| Ground Clearance | Not Published | Not Published |
|---|
| Min. Turn Radius without Brakes | Not Published | Not Published |
|---|
| Height to Top of ROPS | Not Published | Not Published |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 106.2 in | 103.6 in |
|---|
| Overall Length | 158.2 in (MFD cab) | 158.2 in |
|---|
|
|---|
| Tractor Weight (Base) | 10,240 lb (MFD, cab, without ballast) | 10,240 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Not Published | 420/85R38 rear (reference tire for weight and dimensions); rear tires as large as R38 available |
|---|
| R1 Agricultural - Front | Not Published | Not Published |
|---|
| R1 Agricultural - Rear | Not Published | Not Published |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | Not Published | Skid-steer-style or Euro-style quick attach faceplate (available, 650LU and 655LU) |
|---|
| Loader Model | L635 | 650LU (NSL); 655LU (MSL) |
|---|
| Loader Lift Height | L635: up to 149 in | 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) |
|---|
| Loader Lift Capacity (Full Height) | Not Published | 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) |
|---|
| Loader Breakout Force | Not Published | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
