5,620 lb (7,351 lb with optional auxiliary lift ram)
Lift Control Type
Mechanical draft control (MDC), top link sensing (12x12); electronic draft control (EDC), lower link sensing (Hi-Lo cab)
Mechanical draft and position control (12x12 models); Electronic Draft Control (EDC) with fender switches (Dual Command cab models); Lift-O-Matic Plus single-lever control (optional on 12x12, standard on Dual Command ROPS)
Transmission Type
Not Published
12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command Hi-Lo powershift with electrohydraulic power shuttle, or 40x40 Dual Command with creeper (optional)
No. of Speeds
12F/12R (20F/20R creeper, 24F/24R Hi-Lo or 40F/40R Hi-Lo creeper optional)
12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional)
Max Travel Speed (Forward)
Not Published
20 mph (12x12 and 20x20 creeper, standard; 25 mph transport option); 25 mph (24x24 and 40x40 Dual Command)
Max Travel Speed (Reverse)
Not Published
Not Published
Clutch
Wet clutch (power shuttle and Hi-Lo)
Not Published
Differential Lock & Limited Slip Options
Mechanical rear differential lock (12x12); electrohydraulic (Hi-Lo); MFD front axle with limited slip
Air suspension seat with 15-degree swivel (optional); instructional seat (optional)
Cab: fabric mechanical-suspension seat or fabric air-suspension seat with swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests
Front Axle Type
HD 2WD, MFD or HD MFD with limited slip (12x12); HD MFD with limited slip (Hi-Lo)
Heavy-duty electronically engaged 4WD front axle (standard); standard-duty electronically or mechanically engaged 4WD, or heavy-duty 2WD front axle (optional)
Front Axle Rating
Not Published
9,479 lb (standard-duty 4WD, in-action capacity at 4 mph); 10,361 lb (heavy-duty 4WD, in-action capacity at 4 mph)
Drawbar Capacity
Not Published
Not Published
Overall Length with 3-Point Hitch
160 in (MFD cab)
163.1 in (2WD); 160.9 in (4WD)
Overall Width
76 in (across standard fenders)
75.7 in
Wheelbase
90 in (MFD)
92.2 in (2WD); 89.9 in (4WD)
Ground Clearance
Not Published
Not Published
Min. Turn Radius without Brakes
Not Published
134 in (2WD heavy-duty front axle)
Height to Top of ROPS
106 in (18.4R34 rear tires)
106.5 in
Height to Top of ROPS (folded)
82.9 in (18.4R34 rear tires)
Not Published
Height to Top of Cab Model
102 in
102.1 in
Tractor Weight (Base)
Not Published
6,988 lb (2WD ROPS); 7,672 lb (4WD ROPS)
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
R1 agricultural or turf, radial or bias; 18.4R34 rear reference tire
Ag: 16.9-30 rear with 11.2-24 front; 16.9-34 rear with 13.6-24 front; 18.4-30 rear with 12.4-24 front; 18.4-34 rear with 14.9-24 front. Turf: 16.9-24 rear with 13.6-16.1 front. Industrial: 19.5L24 rear with 12.5/80-18 front
R1 Agricultural - Front
7.50-16 (2WD); 11.2R24 or 14.9R24 (4WD)
4WD: 11.2-24, 13.6-24, 12.4-24 or 14.9-24 (paired with 16.9-30, 16.9-34, 18.4-30 or 18.4-34 rears)
R1 Agricultural - Rear
18.4R34 (reference tire)
16.9-30, 16.9-34, 18.4-30 or 18.4-34
R3 Turf - Front
Not Published
13.6-16.1
R3 Turf - Rear
Not Published
16.9-24
R4 Industrial - Front
Not Published
12.5/80-18
R4 Industrial - Rear
Not Published
19.5L24
Quick Attach Loader System
Not Published
Skid-steer-style or Euro-style quick attach faceplate
Loader Model
L620; L630
Factory-fit: 655TL (NSL or MSL), 665TL (NSL or MSL); field-fit: 632TL (NSL), 637TL (MSL)
Loader Lift Height
L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL)
