Case IH Farmall 55C vs Case IH Farmall 65A
Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.
Across 8 measurable specs, the Case IH Farmall 65A leads 7 categories to 1. Machine pages: Case IH Farmall 55C and Case IH Farmall 65A.
Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.
Category Verdict
| Spec | Case IH Farmall 55C | Case IH Farmall 65A |
|---|---|---|
| Engine HP (hp) | 55 hp | ▲ 64 hp |
| PTO HP (hp) | 44 hp | ▲ 50 hp |
| Weight (lb) | 4,453 lb | ▲ 6,834 lb |
| Loader Lift (lb) | 1,830 lb | ▲ 3,153 lb |
| 3-Pt Lift (24 in) (lb) | 2,756 lb | ▲ 4,300 lb |
| Lift Height (in) | 112 in | ▲ 120 in |
| Breakout Force (lbf) | 3,114 lbf | n/a |
| Hydraulic Flow (gpm) | ▲ 13.5 gpm | 12.6 gpm |
| Travel Speed (mph) | 17.9 mph | ▲ 18.6 mph |
Full Spec Sheet
Every published spec, side by side, including the details the graphs above don't chart.
| Spec | Case IHFarmall 55C | Case IHFarmall 65A |
|---|
| Engine Manufacturer | LS Mtron | FPT |
|---|---|---|
| Engine Model | L3C19-T | S8000 |
| Engine Type | Diesel, 3-cylinder, turbocharged | 3-cylinder, Tier 4 B/Final, FPT turbocharged & aftercooled |
| No. of Cylinders | 3 | 3 |
| Displacement | 115.9 in³ | 178.8 in³ |
| Rated Engine Speed | 2600 rpm | 2300 rpm |
| Engine Power (Gross) | 55 hp | 64 hp |
| PTO Power | 44 hp | 50 hp |
| Engine Emissions Constraints | Tier 4 | Tier 4 |
| Cooling System Type | Liquid-cooled | Liquid-cooled |
| Air Cleaner | Replaceable dry element | Not Published |
| Fuel System | Common rail direct injection | Electronic high pressure common rail |
| Alternator | 70 A | 120 A |
Case IH Farmall 55C vs Case IH Farmall 65A: Quick Answers
- Which has more horsepower, the Case IH Farmall 55C or the Case IH Farmall 65A?
- The Case IH Farmall 65A leads on engine hp at 64 hp hp, compared to 55 hp hp for the Case IH Farmall 55C.
- Which has more PTO horsepower, the Case IH Farmall 55C or the Case IH Farmall 65A?
- The Case IH Farmall 65A leads on pto hp at 50 hp hp, compared to 44 hp hp for the Case IH Farmall 55C.
- Which is heavier, the Case IH Farmall 55C or the Case IH Farmall 65A?
- The Case IH Farmall 65A leads on weight at 6,834 lb lb, compared to 4,453 lb lb for the Case IH Farmall 55C.
- Which has more loader lift capacity, the Case IH Farmall 55C or the Case IH Farmall 65A?
- The Case IH Farmall 65A leads on loader lift at 3,153 lb lb, compared to 1,830 lb lb for the Case IH Farmall 55C.
- Which has more three-point hitch lift capacity, the Case IH Farmall 55C or the Case IH Farmall 65A?
- The Case IH Farmall 65A leads on 3-pt lift (24 in) at 4,300 lb lb, compared to 2,756 lb lb for the Case IH Farmall 55C.
