Case IH Farmall 60A vs John Deere 5060E
Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.
Across 8 measurable specs, the John Deere 5060E leads 5 categories to 2 (1 tied). Machine pages: Case IH Farmall 60A and John Deere 5060E.
Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.
Category Verdict
| Spec | Case IH Farmall 60A | John Deere 5060E |
|---|---|---|
| Engine HP (hp) | 60 hp | 60 hp |
| PTO HP (hp) | ▲ 51 hp | 45.6 hp |
| Weight (lb) | 5,060 lb | ▲ 5,445 lb |
| Loader Lift (lb) | ▲ 2,734 lb | 2,453 lb |
| 3-Pt Lift (24 in) (lb) | 2,701 lb | ▲ 3,192 lb |
| Lift Height (in) | 106 in | ▲ 113 in |
| Breakout Force (lbf) | 3,527 lbf | ▲ 4,781 lbf |
| Hydraulic Flow (gpm) | 17.4 gpm | ▲ 18.2 gpm |
| Travel Speed (mph) | n/a | 15.5 mph |
Full Spec Sheet
Every published spec, side by side, including the details the graphs above don't chart.
| Spec | Case IHFarmall 60A | John Deere5060E |
|---|
| Engine Manufacturer | FPT | John Deere |
|---|---|---|
| Engine Model | R 753 IE4 | 3029H |
| Engine Type | 3-cylinder, FPT turbocharged & aftercooled | Diesel, turbocharged |
| No. of Cylinders | 3 | 3 |
| Displacement | 135.9 in³ | 179 in³ |
| Rated Engine Speed | 2600 rpm | 2100 rpm |
| Engine Power (Gross) | 60 hp | 60 hp |
| PTO Power | 51 hp | OOS: 45.6 hp; Cab: 42.9 hp |
| Engine Emissions Constraints | Tier 4 | Tier 4 |
| Cooling System Type | Liquid-cooled | Liquid-cooled |
| Air Cleaner | Dry | Dry type with safety element |
| Fuel System | Electronic high pressure common rail | Electronically controlled, high-pressure common rail |
| Alternator | 75 A | OOS: 70 A; Cab: 110 A |
Case IH Farmall 60A vs John Deere 5060E: Quick Answers
- Which has more horsepower, the Case IH Farmall 60A or the John Deere 5060E?
- They are effectively tied: both machines are rated at 60 hp hp for engine hp.
- Which has more PTO horsepower, the Case IH Farmall 60A or the John Deere 5060E?
- The Case IH Farmall 60A leads on pto hp at 51 hp hp, compared to 45.6 hp hp for the John Deere 5060E.
- Which is heavier, the Case IH Farmall 60A or the John Deere 5060E?
- The John Deere 5060E leads on weight at 5,445 lb lb, compared to 5,060 lb lb for the Case IH Farmall 60A.
- Which has more loader lift capacity, the Case IH Farmall 60A or the John Deere 5060E?
- The Case IH Farmall 60A leads on loader lift at 2,734 lb lb, compared to 2,453 lb lb for the John Deere 5060E.
- Which has more three-point hitch lift capacity, the Case IH Farmall 60A or the John Deere 5060E?
- The John Deere 5060E leads on 3-pt lift (24 in) at 3,192 lb lb, compared to 2,701 lb lb for the Case IH Farmall 60A.
