| Engine Manufacturer | FPT | John Deere |
|---|
| Engine Model | F5DFL463B*G001 | 3029T |
|---|
| Engine Type | Turbocharged diesel | 3-cylinder liquid-cooled diesel, turbocharged, direct injection |
|---|
| No. of Cylinders | 4 | 3 |
|---|
| Displacement | 207 in³ | 179 in³ |
|---|
| Rated Engine Speed | 2300 rpm | 2400 rpm |
|---|
| Engine Power (Gross) | 64 hp | 64 hp |
|---|
| PTO Power | 50 hp | 55 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Not Published |
|---|
| Cooling System Type | Not Published | Liquid-cooled |
|---|
| Air Cleaner | Not Published | Dry type with safety element |
|---|
| Fuel System | Common rail | Direct injection, rotary injection pump with electric shutoff |
|---|
| Alternator | Not Published | 40 A |
|---|
|
|---|
| Pump Type | Dual gear pumps | Tandem gear pump |
|---|
| Implement Flow | 12.9 gpm | 11.4 gpm |
|---|
| Steering Flow | 7.3 gpm | 6.8 gpm |
|---|
| Total Hydraulic Flow | Not Published | 18.2 gpm |
|---|
| Overall Hydraulic Pump Flow | Not Published | 18.2 gpm |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | 11.4 gpm |
|---|
| No. of Standard Remote Valves | 2 | Not Published |
|---|
| No. of Optional Remote Valves | 3 | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | 23.8 gal | 18 gal (open station); 23 gal (cab) |
|---|
| Coolant Capacity | Not Published | 10 qt |
|---|
| Crankcase Capacity | Not Published | 9 qt |
|---|
| Transmission / Hydraulic System Capacity | Not Published | 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) |
|---|
| Front Axle Fluid Capacity | Not Published | 5.2 qt (MFWD axle housing); 0.6 qt (each wheel hub); 5.7 qt (MFWD assembly) |
|---|
|
|---|
| PTO Type | Independent | Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever operated clutch |
|---|
| PTO Rear | 540 rpm (540/540E optional) | 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category I/II | Category I and II |
|---|
| Hitch Lift Capacity | Not Published | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 3,956 lb | 3374 lb |
|---|
| Lift Control Type | Mechanical draft control (MDC), top link sensing | Position and depth control, top link draft sensing |
|---|
|
|---|
| Transmission Type | Standard: 12x12 power shuttle (wet clutch); Optional: 12x12 power shuttle (wet clutch) with creeper (20x20) | CollarShift standard; SyncShuttle optional; PowrReverser optional |
|---|
| No. of Speeds | Standard: 12 forward / 12 reverse; Optional creeper: 20 forward / 20 reverse | 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) |
|---|
| Max Travel Speed (Forward) | Not Published | 15.62 mph (CollarShift and SyncShuttle, gear C-3); 15.52 mph (PowrReverser, gear C-4) |
|---|
| Max Travel Speed (Reverse) | Not Published | 13.33 mph (CollarShift and SyncShuttle, gear C-R); 17.95 mph (PowrReverser, gear C-4 reverse) |
|---|
| Clutch | Wet clutch | Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) |
|---|
| Differential Lock & Limited Slip Options | Mechanical rear differential lock; limited-slip MFD front axle | Not Published |
|---|
|
|---|
| Frame Type | Not Published | Two-post ROPS; cab optional; two-wheel drive or MFWD |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering |
|---|
| Brakes | Hydraulic wet disc | Wet disk, self-equalizing, self-adjusting |
|---|
| Seat Suspension & Adjustability | Not Published | Not Published |
|---|
| Front Axle Type | 2WD: 2WD front axle; MFD: MFD with limited slip, electrohydraulic engagement | Two-wheel drive or mechanical front wheel drive (MFWD) |
|---|
| Front Axle Rating | Not Published | 2720 to 4700 lb (2WD, by front tire, no loader); 2760 to 4620 lb (MFWD, by front tire, without loader) |
|---|
| Drawbar Capacity | Not Published | 1675 lb |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 145.8 in | 123.6 in (2WD); 128.1 in (MFWD) (w/o 3P, less hitch, drawbar and front weights) (without 3-point hitch) |
|---|
| Overall Width | 76 in | 66.7 in |
|---|
| Wheelbase | 2WD: 85.8 in; MFD: 84 in | 80.7 in |
|---|
| Ground Clearance | Not Published | 18.1 in (2WD front axle); 14.8 in (MFWD front axle); 15.8 in (2WD drawbar); 16.3 in (MFWD drawbar) |
|---|
| Min. Turn Radius without Brakes | Not Published | 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) |
|---|
| Height to Top of ROPS | Not Published | 88.7 in |
|---|
| Height to Top of ROPS (folded) | Not Published | 75.5 in |
|---|
| Height to Top of Cab Model | 98 in | 97.9 in |
|---|
|
|---|
| Tractor Weight (Base) | Cab 2WD: 6,063 lb; Cab MFD: 6,548 lb | 4350 lb (2WD); 4750 lb (MFWD); add approximately 1000 lb with cab |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | 18.4R34 rear | Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 16.9-30, 18.4-16.1 |
|---|
| R1 Agricultural - Front | Not Published | 7.50-16 (2WD); 9.5-24 (MFWD) |
|---|
| R1 Agricultural - Rear | Not Published | 14.9-28 |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | Compatible with L565 loader | Not Published |
|---|
| Loader Model | L565 | 521; 541; 541 self-leveling |
|---|
| Loader Lift Height | 105 in | 521: 122 in; 541: 126 in; 541 self-leveling: 130 in |
|---|
| Loader Lift Capacity (Full Height) | 2,734 lb | 521: 2500 lb; 541: 2500 lb; 541 self-leveling: 2800 lb (full at pin) |
|---|
| Loader Breakout Force | 3,527 lb | 521: 3485 lbf; 541: 3484 lbf; 541 self-leveling: 4125 lbf (at pin) |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
