▶ EngineEngine Manufacturer FPT FPT Industrial Engine Model S8000 F5C Engine Type 3-cylinder, FPT turbocharged & aftercooled diesel, Tier 4 B/Final 4-cylinder diesel, turbocharged No. of Cylinders 3 4 Displacement 178.8 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 60 hp 65 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Electronic high pressure common rail Common rail fuel injection Alternator 120 A 120 A ▶ HydraulicsPump Type Fixed displacement Open-center; dual pumps (implement + dedicated steering and services pump) Implement Flow 12.6 gpm 12.5 gpm Steering Flow Not Published 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) Total Hydraulic Flow Not Published 19.8 gpm (mechanical shuttle); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Overall Hydraulic Pump Flow Not Published 19.8 gpm (mechanical shuttle); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves 3 Up to 3 rear remotes ▶ Fluid CapacityFuel Tank Capacity 21.7 gal 23.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Fully independent PTO Rear 540 (standard); 540/540E (optional) 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I/II Category II / I Hitch Lift Capacity 5,952 lb (optional hitch 6,614 lb) Not Published Hitch Lift Capacity (at 24”) 4,300 lb (optional hitch 4,740 lb) 3,664 lb Lift Control Type Mechanical Draft Control (MDC), top link sensing Mechanical draft control; top link draft sensing ▶ Transmission & DrivetrainTransmission Type MFD: 12x12 power shuttle (wet clutch); 2WD: 8x8 power shuttle (wet clutch); optional 12x12 with creeper (20x20) 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions No. of Speeds MFD: 12F/12R; 2WD: 8F/8R; optional 20F/20R creeper 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) Max Travel Speed (Forward) 18.6 mph 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) Max Travel Speed (Reverse) Not Published 20.1 mph Clutch MFD: wet clutch (12x12 power shuttle); 2WD: wet clutch (8x8 power shuttle) Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Differential Lock & Limited Slip Options Mechanical rear differential lock; MFD engagement electrohydraulic; limited-slip MFD front axle Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability Mechanical contoured seat, adjustable; optional air-ride seat Deluxe air suspension seat with integrated armrest and 10° swivel (optional, cab); full-size instructor seat with seatbelt (cab) Front Axle Type 2WD or MFD with limited slip Heavy-duty 2WD front axle; electronic 4WD front axle (optional on T4.75, standard on T4.65) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 155.3 in 151 in Overall Width Not Published Not Published Wheelbase 2WD: 82.1 in; MFD: 83.6 in 85.8 in (2WD); 83.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 134 in (2WD front axle) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) 67.7 in 76 to 78.9 in Height to Top of Cab Model 2WD: 98 in; MFD: 100 in 94.8 to 97.8 in ▶ WeightTractor Weight (Base) 2WD Cab: 6,173 lb; 2WD Non-cab: 5,622 lb; MFD Cab: 6,834 lb; MFD Non-cab: 6,283 lb 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R-1 (ag tread) bias ply standard; optional R-1W (ag tread) radial Not Published R1 Agricultural - Front 2WD: 9.5L-15; MFD: 11.2x24 Not Published R1 Agricultural - Rear 2WD: 16.9R28; MFD: 16.9x30 (optional 16.9R28) Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer-style or Euro-style quick attach faceplate Loader Model L610 Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) Loader Lift Height 130.3 in 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in Loader Lift Capacity (Full Height) NSL: 1,828 lb; MSL: 3,153 lb 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (at max height, 31.5 in forward of the bucket pivot point) Loader Breakout Force Not Published 655TL NSL: 3,739 lb; 622TL: 3,042 lb; 627TL: 3,307 lb (at 31.5 in forward of the bucket pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
