Case IH Farmall 75A vs New Holland Workmaster 75
Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.
Across 8 measurable specs, the New Holland Workmaster 75 leads 3 categories to 2 (3 tied). Machine pages: Case IH Farmall 75A and New Holland Workmaster 75.
Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.
Category Verdict
| Spec | Case IH Farmall 75A | New Holland Workmaster 75 |
|---|---|---|
| Engine HP (hp) | 74 hp | 74 hp |
| PTO HP (hp) | 60 hp | 60 hp |
| Weight (lb) | ▲ 6,834 lb | 6,800 lb |
| Loader Lift (lb) | 3,153 lb | 3,153 lb |
| 3-Pt Lift (24 in) (lb) | ▲ 4,300 lb | 3,500 lb |
| Lift Height (in) | 130.3 in | ▲ 131.3 in |
| Hydraulic Flow (gpm) | 12.6 gpm | ▲ 20.2 gpm |
| Travel Speed (mph) | 18.6 mph | ▲ 25 mph |
Full Spec Sheet
Every published spec, side by side, including the details the graphs above don't chart.
| Spec | Case IHFarmall 75A | New HollandWorkmaster 75 |
|---|
| Engine Manufacturer | FPT | FPT |
|---|---|---|
| Engine Model | S8000 | S8000 |
| Engine Type | 3-cylinder, FPT turbocharged & aftercooled diesel, Tier 4 B/Final | Turbocharged 3-cylinder diesel |
| No. of Cylinders | 3 | 3 |
| Displacement | 178.8 in³ | 179 in³ |
| Rated Engine Speed | 2300 rpm | 2300 rpm |
| Engine Power (Gross) | 74 hp | 74 hp |
| PTO Power | 60 hp | 60 hp |
| Engine Emissions Constraints | Tier 4 | Tier 4 |
| Cooling System Type | Liquid-cooled | Not Published |
| Air Cleaner | Not Published | PowerCore dry air cleaner |
| Fuel System | Electronic high pressure common rail | Bosch electronic high-pressure common rail |
| Alternator | 120 A | 120 A |
Case IH Farmall 75A vs New Holland Workmaster 75: Quick Answers
- Which has more horsepower, the Case IH Farmall 75A or the New Holland Workmaster 75?
- They are effectively tied: both machines are rated at 74 hp hp for engine hp.
- Which has more PTO horsepower, the Case IH Farmall 75A or the New Holland Workmaster 75?
- They are effectively tied: both machines are rated at 60 hp hp for pto hp.
- Which is heavier, the Case IH Farmall 75A or the New Holland Workmaster 75?
- The Case IH Farmall 75A leads on weight at 6,834 lb lb, compared to 6,800 lb lb for the New Holland Workmaster 75.
- Which has more loader lift capacity, the Case IH Farmall 75A or the New Holland Workmaster 75?
- They are effectively tied: both machines are rated at 3,153 lb lb for loader lift.
- Which has more three-point hitch lift capacity, the Case IH Farmall 75A or the New Holland Workmaster 75?
- The Case IH Farmall 75A leads on 3-pt lift (24 in) at 4,300 lb lb, compared to 3,500 lb lb for the New Holland Workmaster 75.
