Which has more horsepower, the Case IH Farmall 75A or the TYM T754?

They are effectively tied: both machines are rated at 74 hp hp for engine hp.

Which has more PTO horsepower, the Case IH Farmall 75A or the TYM T754?

The TYM T754 leads on pto hp at 64.1 hp hp, compared to 60 hp hp for the Case IH Farmall 75A.

Which has more three-point hitch lift capacity, the Case IH Farmall 75A or the TYM T754?

The Case IH Farmall 75A leads on 3-pt lift (24 in) at 4,299 lb lb, compared to 3,418 lb lb for the TYM T754.

Case IH Farmall 75A vs TYM T754

Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.

Across 4 measurable specs, the TYM T754 leads 2 categories to 1 (1 tied). Machine pages: Case IH Farmall 75A and TYM T754.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Spec	Case IH Farmall 75A	TYM T754
Engine HP (hp)	74 hp	74 hp
PTO HP (hp)	60 hp	▲ 64.1 hp
Weight (lb)	—	7,904 lb
Loader Lift (lb)	—	3,325 lb
3-Pt Lift (24 in) (lb)	▲ 4,299 lb	3,418 lb
Lift Height (in)	—	133.8 in
Breakout Force (lbf)	—	5,485 lbf
Hydraulic Flow (gpm)	12.6 gpm	▲ 16.1 gpm
Travel Speed (mph)	—	24.1 mph

The headline numbers at a glance.

Case IH Farmall 75ATYM T754

Engine HPhp

▲74 hp

PTO HPhp

60 hp

▲64.1 hp

Weightlb

—

7,904 lb

Loader Liftlb

—

3,325 lb

3-Pt Lift (24 in)lb

▲4,299 lb

3,418 lb

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Case IHFarmall 75A	TYMT754


PTO Power	60 hp	64.1 hp
Alternator	Not Published	95 A, 12 V
Air Cleaner	Not Published	Dual dry
Engine Type	Diesel, turbocharged	4-cylinder, turbocharged diesel
Fuel System	Not Published	CRDI
Displacement	177 in³	177 in³
No. of Cylinders	3	4
Rated Engine Speed	2300 rpm	2200 rpm
Cooling System Type	Not Published	Not Published
Engine Manufacturer	FPT Industrial	Deutz
Engine Power (Gross)	74 hp	74 hp
Engine Emissions Constraints	Tier 4	Diesel Oxidation Catalyst (DOC)

Weight with ROPS and Loader	Not Published	Not Applicable
Weight with Cab and Loader	Not Published	7,904 lb

Warranty Length & Coverage	Not Published	Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.

Pump Type	Not Published	Dual gear pump
Steering Flow	Not Published	5.8 gpm
Implement Flow	12.6 gpm	10.3 gpm
Total Hydraulic Flow	Not Published	16.1 gpm
Hydraulic System Type	Open center	Not Published
Rear Remote Hydraulic Flow	Not Published	Not Published
Overall Hydraulic Pump Flow	Not Published	16.1 gpm
No. of Optional Remote Valves	3	Not Published
No. of Standard Remote Valves	2	2

PTO Rear	540 / 540/540E	540/750 rpm; 540/1,000 rpm (Opt)
PTO Type	Not Published	Independent
Lift Control Type	Mechanical Draft Control (MDC) top link sensing	Position/Draft/Elec
Hitch Lift Capacity	Not Published	5,115 lb
Mid-PTO Availability	Not Published	Not Published
Category, 3-Point Hitch	Category 1/2	Category II
Hitch Lift Capacity (at 24”)	4,299 lb (standard); 4,740 lb (optional) @ 24 in behind pin	3,418 lb

R3 Turf - Rear	Not Published	Not Published
R3 Turf - Front	Not Published	Not Published
Tire Size & Options	Not Published	R1 Agricultural, R4 Industrial
R4 Industrial - Rear	Not Published	Xtra Grip 18.4-24 NHS TL 8PR
R4 Industrial - Front	Not Published	Trac Chief 15-19.5 NHS TL 6PR
R1 Agricultural - Rear	Not Published	FSTR 420/85R30 TL (16.9R30)
R1 Agricultural - Front	Not Published	FSTR 280/85R24 TL (11R24)

Coolant Capacity	Not Published	10.6 qt
Crankcase Capacity	Not Published	8.5 qt
Fuel Tank Capacity	21.7 gal	23.8 gal
Front Axle Fluid Capacity	Not Published	17.3 qt
Transmission / Hydraulic System Capacity	Not Published	18.0 gal

Loader Lift Height	Not Published	133.8 in
Loader Breakout Force	Not Published	5,485 lb
Quick Attach Loader System	Not Published	TX75SL: Quick attachment (Skid/Euro type)
Loader Lift Capacity (Full Height)	Not Published	3,325 lb

Clutch	Dry clutch (8x8 mechanical shuttle); wet clutch (12x12 power shuttle)	M: Dry Single Plate; PS: Wet Multi Plate
No. of Speeds	Not Published	F16 x R16 (Creep interlock)
Transmission Type	8x8 mechanical shuttle (dry clutch) (standard); 12x12 power shuttle (wet clutch) or 12x12 with creeper (optional)	Synchro-shuttle
Max Travel Speed (Forward)	Not Published	24.1 mph
Max Travel Speed (Reverse)	Not Published	Not Published
Differential Lock & Limited Slip Options	Mechanical differential lock; MFD engagement electrohydraulic	Not Published

Brakes	Not Published	Wet disc
Steering	Not Published	Hydrostatic
Frame Type	Not Published	Not Published
Front Axle Type	2WD or MFD with limited slip	Not Published
Drawbar Capacity	Not Published	Not Published
Front Axle Rating	Not Published	Not Published
Seat Suspension & Adjustability	Not Published	Suspension seat

Wheelbase	81.2 in (2WD); 81.8 in (MFD)	86.1 in
Overall Width	Not Published	76.4 in
Ground Clearance	Not Published	18.3 in
Height to Top of ROPS	Not Published	Not Applicable
Height to Top of Cab Model	100 in	103.3 in
Height to Top of ROPS (folded)	67.7 in	Not Applicable
Min. Turn Radius without Brakes	Not Published	162.8 in
Overall Length with 3-Point Hitch	151.8 in	155.7 in
