▶ EngineEngine Manufacturer FPT John Deere Engine Model Not Published PowerTech 3-cylinder (2.9 L) EWX Engine Type Turbocharged diesel Diesel, turbocharged, aftercooled No. of Cylinders 4 3 Displacement 207.5 in³ 177 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 74 hp 73.8 hp PTO Power 61 hp 57.7 hp @ 100 rpm Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled (Cool-Gard II coolant) Air Cleaner Not Published Not Published Fuel System Common rail Not Published Alternator Not Published OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Dual gear pumps Tandem gear pump Implement Flow 12.9 gpm 18.4 gpm Steering Flow 7.3 gpm 6.3 gpm Total Hydraulic Flow Not Published 24.7 gpm Overall Hydraulic Pump Flow Not Published 24.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 (rear); 2 (mid) No. of Optional Remote Valves 1 Up to 3 total (rear); up to 3 total (mid) ▶ Fluid CapacityFuel Tank Capacity 23.8 gal OOS: 39.2 gal; OOS (High Capacity): 47.1 gal; Cab: 43.7 gal; Cab (High Capacity): 52 gal Coolant Capacity Not Published OOS: 3.6 gal; Cab: 4.2 gal Crankcase Capacity Not Published 2.2 gal Transmission / Hydraulic System Capacity Not Published 10.4 gal Front Axle Fluid Capacity Not Published Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal ▶ PTO & HitchPTO Type Independent Independent rear PTO, electro-hydraulic wet disc clutch: 540/540E standard, 540/540E/1000 optional PTO Rear 540 rpm (540/540E optional) 540/540E rpm standard; 1000 rpm optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I/II Category II (convertible to I) Hitch Lift Capacity Not Published 5,305 lb standard; 6,114 lb optional Hitch Lift Capacity (at 24”) 3,956 lb 5,150 lb standard; 5,950 lb optional Lift Control Type Mechanical draft control (MDC), top link sensing Mechanical or Electrohydraulic ▶ Transmission & DrivetrainTransmission Type Standard: 12x12 power shuttle (wet clutch); Optional: 12x12 power shuttle (wet clutch) with creeper (20x20) PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo No. of Speeds Standard: 12 forward and 12 reverse; Optional creeper: 20 forward and 20 reverse 16F/16R (standard PowrReverser); 32F/16R (optional PowrReverser Hi-Lo) Max Travel Speed (Forward) Not Published 24 mph Max Travel Speed (Reverse) Not Published 16F/16R PowrReverser, top gear D-4: 20.5 mph (30K gearing); 23.9 mph (40K gearing), with 480/70R28 rear tires at 2200 rpm Clutch Wet clutch Wet Differential Lock & Limited Slip Options Mechanical; MFD front axle with limited slip Electrohydraulic rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Cast iron mid-frame Steering Hydrostatic power steering Not Published Brakes Hydraulic wet disc Hydraulically actuated wet disc brakes Seat Suspension & Adjustability Not Published OOS: isolated mechanical seat standard (fore/aft, weight, lumbar adjust) or air suspension seat optional; Cab: mechanical seat standard or air suspension seat optional; adjustable weight range 88-330 lb Front Axle Type MFD with limited slip; electrohydraulic engagement MFWD Front Axle Rating Not Published 6,613 lb max permissible front axle load Drawbar Capacity Not Published Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb ▶ Dimensions & ManeuverabilityOverall Width 76 in Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in Wheelbase 84 in 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 13.1 ft Height to Top of ROPS Not Applicable 102.1 in (with standard rear tires) Height to Top of ROPS (folded) Not Applicable Not Published Height to Top of Cab Model 98 in 102.9 in (with standard rear tires) Overall Length 145.8 in 149.5 in (including draft links) ▶ WeightTractor Weight (Base) 6,548 lb (weight w/o ballast) 2WD OOS: 8,140 lb; 2WD Cab: 8,580 lb; MFWD OOS: 8,765 lb; MFWD Cab: 9,185 lb (approximate ship weight, less weights) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18.4R34 rear Not Published R1 Agricultural - Front Not Published 12.4R24 (320/85R24) R1W Radial R1 Agricultural - Rear Not Published 18.4R30 (460/85R30) R1W Radial R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System L565 Not Published Loader Model L565 520M (4WD only); 540M NSL; 540M MSL; 540R; 600M NSL; 600M MSL Loader Lift Height L565: 105 in 520M: 130-132 in; 540M NSL: 137-141 in; 540M MSL: 138-141 in; 540R: 141.85 in; 600M NSL: 148.8-152.8 in; 600M MSL: 148-153 in Loader Lift Capacity (Full Height) L565: 2,734 lb 520M NSL: 3,335-3,612 lb; 520M MSL: 2,460-2,661 lb; 540M NSL: 2,394-2,666 lb; 540M MSL: 3,117-3,309 lb; 540R: 3,406 lb; 600M NSL: 3,104-3,236 lb; 600M MSL: 3,891-4,085 lb Loader Breakout Force L565: 3,527 lb 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot; H310 for MFWD tractors) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
