Case IH Farmall 75C vs New Holland Workmaster 75
Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.
Across 7 measurable specs, the New Holland Workmaster 75 leads 4 categories to 2 (1 tied). Machine pages: Case IH Farmall 75C and New Holland Workmaster 75.
Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.
Category Verdict
| Spec | Case IH Farmall 75C | New Holland Workmaster 75 |
|---|---|---|
| Engine HP (hp) | 74 hp | 74 hp |
| PTO HP (hp) | ▲ 61 hp | 60 hp |
| Weight (lb) | 6,548 lb | ▲ 6,800 lb |
| Loader Lift (lb) | 2,734 lb | ▲ 3,153 lb |
| 3-Pt Lift (24 in) (lb) | ▲ 3,956 lb | 3,500 lb |
| Lift Height (in) | 105 in | ▲ 131.3 in |
| Breakout Force (lbf) | 3,527 lbf | n/a |
| Hydraulic Flow (gpm) | 19.8 gpm | ▲ 20.2 gpm |
| Travel Speed (mph) | n/a | 25 mph |
Full Spec Sheet
Every published spec, side by side, including the details the graphs above don't chart.
| Spec | Case IHFarmall 75C | New HollandWorkmaster 75 |
|---|
| Engine Manufacturer | FPT | FPT |
|---|---|---|
| Engine Model | F5DFL463A*F017 | S8000 |
| Engine Type | Turbocharged diesel | Turbocharged 3-cylinder diesel |
| No. of Cylinders | 4 | 3 |
| Displacement | 207 in³ | 179 in³ |
| Rated Engine Speed | 2300 rpm | 2300 rpm |
| Engine Power (Gross) | 74 hp | 74 hp |
| PTO Power | 61 hp | 60 hp |
| Engine Emissions Constraints | Tier 4 | Tier 4 |
| Cooling System Type | Not Published | Not Published |
| Air Cleaner | Not Published | PowerCore dry air cleaner |
| Fuel System | Common rail | Bosch electronic high-pressure common rail |
| Alternator | Not Published | 120 A |
Case IH Farmall 75C vs New Holland Workmaster 75: Quick Answers
- Which has more horsepower, the Case IH Farmall 75C or the New Holland Workmaster 75?
- They are effectively tied: both machines are rated at 74 hp hp for engine hp.
- Which has more PTO horsepower, the Case IH Farmall 75C or the New Holland Workmaster 75?
- The Case IH Farmall 75C leads on pto hp at 61 hp hp, compared to 60 hp hp for the New Holland Workmaster 75.
- Which is heavier, the Case IH Farmall 75C or the New Holland Workmaster 75?
- The New Holland Workmaster 75 leads on weight at 6,800 lb lb, compared to 6,548 lb lb for the Case IH Farmall 75C.
- Which has more loader lift capacity, the Case IH Farmall 75C or the New Holland Workmaster 75?
- The New Holland Workmaster 75 leads on loader lift at 3,153 lb lb, compared to 2,734 lb lb for the Case IH Farmall 75C.
- Which has more three-point hitch lift capacity, the Case IH Farmall 75C or the New Holland Workmaster 75?
- The Case IH Farmall 75C leads on 3-pt lift (24 in) at 3,956 lb lb, compared to 3,500 lb lb for the New Holland Workmaster 75.
