▶ EngineEngine Manufacturer FPT FPT Engine Model Not Published F5C Engine Type Turbocharged diesel 4-cylinder diesel, turbocharged No. of Cylinders 4 4 Displacement 207.5 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 61 hp 65 hp Engine Emissions Constraints Tier 4 US EPA Tier 4B Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry Fuel System Common rail Common rail fuel injection Alternator Not Published 120 A ▶ HydraulicsPump Type Dual gear pumps Open center, dual pumps: implement pump plus dedicated steering and services pump Implement Flow 12.5 gpm 12.5 gpm Steering Flow 7.3 gpm 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) Total Hydraulic Flow Not Published 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Overall Hydraulic Pump Flow Not Published 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves 1 Up to 3 rear remotes ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 23.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Fully independent PTO Rear 540 rpm (540/540E optional) 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I/II Category II / I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,956 lb 3,664 lb Lift Control Type Mechanical draft control (MDC), top link sensing Mechanical draft control; top link draft sensing ▶ Transmission & DrivetrainTransmission Type Standard: 12x12 power shuttle (wet clutch); Optional: 12x12 power shuttle (wet clutch) with creeper (20x20) 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions No. of Speeds Standard: 12 forward and 12 reverse; Optional creeper: 20 forward and 20 reverse 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) Max Travel Speed (Forward) Not Published 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) Max Travel Speed (Reverse) Not Published 20.1 mph Clutch Not Published Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Differential Lock & Limited Slip Options Mechanical Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic wet disc Hydraulic wet disc Seat Suspension & Adjustability Not Published Optional deluxe air suspension seat with fully integrated armrest and 10° swivel to the right; full-size instructor seat with seatbelt Front Axle Type 2WD Heavy-duty 2WD front axle; electronic 4WD front axle (optional) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 76 in Not Published Wheelbase 85.8 in 85.8 in (2WD); 83.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 134 in (2WD front axle) Height to Top of ROPS 104.5 in Not Published Height to Top of ROPS (folded) Not Published 76 to 78.9 in Height to Top of Cab Model Not Applicable 94.8 to 97.8 in Overall Length 145.8 in 151 in ▶ WeightTractor Weight (Base) Not Published 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18.4R34 rear Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer-style or Euro-style quick attach faceplate Loader Model L565 Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) Loader Lift Height L565: 105 in 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in Loader Lift Capacity (Full Height) L565: 2,734 lb 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (to max height, at 31.5 in from pivot point) Loader Breakout Force L565: 3,527 lb 655TL NSL: 3,739 lb; 655TL MSL: 4,665 lb; 622TL: 3,042 lb; 627TL: 3,307 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
