| Engine Manufacturer | FPT | FPT |
|---|
| Engine Model | F5D | F36 |
|---|
| Engine Type | Turbocharged and intercooled 4-cylinder diesel | 4-cylinder diesel, turbocharged and aftercooled |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 207 in³ | 219.7 in³ |
|---|
| Rated Engine Speed | 2300 rpm | 2300 rpm |
|---|
| Engine Power (Gross) | 98 hp | 99.2 hp |
|---|
| PTO Power | 82 hp | Not Published |
|---|
| Engine Emissions Constraints | Tier 4A | Stage V (ECOBlue Compact HI-eSCR + Light CEGR) |
|---|
| Cooling System Type | Liquid-cooled | Not Published |
|---|
| Air Cleaner | Dual dry element | Not Published |
|---|
| Fuel System | Electronic high-pressure common-rail fuel injection | Common rail fuel injection |
|---|
| Alternator | 120 A | Not Published |
|---|
|
|---|
| Pump Type | Dual engine-driven pumps (open center) | Open center, dual pumps: implement pump plus dedicated steering pump |
|---|
| Implement Flow | 12.5 gpm (16.9 gpm optional) | 21.7 gpm |
|---|
| Steering Flow | 7.3 gpm | 9.7 gpm |
|---|
| Total Hydraulic Flow | 19.8 gpm (12.5 + 7.3, computed) | 31.4 gpm (21.7 + 9.7, computed) |
|---|
| Overall Hydraulic Pump Flow | 19.8 gpm (12.5 + 7.3, computed) | 31.4 gpm (21.7 + 9.7, computed) |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 1 | 2 rear remotes (four couplers) |
|---|
| No. of Optional Remote Valves | 2 (3rd remote available through Parts Division) | 1 (3rd rear remote); 1 with diverter (3rd rear remote with 1 diverter) |
|---|
|
|---|
| Fuel Tank Capacity | 30.3 gal | 34.3 gal |
|---|
| Coolant Capacity | Not Published | Not Published |
|---|
| Crankcase Capacity | Not Published | Not Published |
|---|
| Transmission / Hydraulic System Capacity | Not Published | Not Published |
|---|
| Front Axle Fluid Capacity | Not Published | Not Published |
|---|
|
|---|
| PTO Type | Independent, mechanical engagement | Fully independent electrohydraulic PTO, wet clutch |
|---|
| PTO Rear | 540/1000 (base); 540 (optional) | 540/1000 rpm (interchangeable, standard) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II (ball ends convert to Category I) | Category II |
|---|
| Hitch Lift Capacity | Not Published | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 5,620 lb | 4,123 lb |
|---|
| Lift Control Type | Single-lever position control with draft-sensing top link | 12x12 models: mechanical draft control; Dual Command models: electronic draft control; single-lever Lift-O-Matic PLUS (standard) |
|---|
|
|---|
| Transmission Type | Not Published | 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (column-mounted) |
|---|
| No. of Speeds | 12F/12R mechanical (20F/12R mechanical with creeper; 12F/12R power shuttle; 20F/20R optional) | 12F/12R; 20F/20R with creeper; 24F/24R Dual Command |
|---|
| Max Travel Speed (Forward) | Not Published | 25 mph |
|---|
| Max Travel Speed (Reverse) | Not Published | Not Published |
|---|
| Clutch | Not Published | Not Published |
|---|
| Differential Lock & Limited Slip Options | Mechanical rear differential lock | Electrohydraulic rear differential lock |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Power steering | Not Published |
|---|
| Brakes | Wet disc (mechanical on ROPS, hydraulic on cab) | Not Published |
|---|
| Seat Suspension & Adjustability | Air suspension seat with 15-degree swivel (optional, cab) | Air-suspension cloth seat |
|---|
| Front Axle Type | 2WD or MFD | Heavy-duty class 1.5 4WD front axle |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Width | 83 in | 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) |
|---|
| Wheelbase | 89 in (MFD) | 92.5 in |
|---|
| Ground Clearance | Not Published | Not Published |
|---|
| Min. Turn Radius without Brakes | Not Published | Not Published |
|---|
| Height to Top of ROPS | 103 in | Not Published |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 100 in | 103.6 in |
|---|
| Overall Length | 149 in (MFD cab, 16.9R-34 rear tires) | 158.2 in |
|---|
|
|---|
| Tractor Weight (Base) | 7,937 lb (MFD cab, 16.9R-34 rear tires) | 10,240 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Not Published | 420/85R38 (reference tire for weight and dimensions); rear tires as large as R38 available |
|---|
| R1 Agricultural - Front | Not Published | Not Published |
|---|
| R1 Agricultural - Rear | 16.9R-34 | Not Published |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | Skid steer-style quick attach (hydraulic coupler) | Skid-steer-style or Euro-style quick attach faceplate (available, both LU loaders) |
|---|
| Loader Model | L620; L630; L735 | 650LU (NSL); 655LU (MSL) |
|---|
| Loader Lift Height | L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL); L735: 137 in | 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) |
|---|
| Loader Lift Capacity (Full Height) | L620: 3,461 lb (NSL) / 3,573 lb (MSL); L630: 3,849 lb (NSL) / 4,204 lb (MSL); L735: 4,034 lb (NSL) / 3,505 lb (MSL) (maximum height at pins) | 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) |
|---|
| Loader Breakout Force | L620: 5,530 lb (NSL) / 5,483 lb (MSL); L630: 6,649 lb (NSL) / 6,767 lb (MSL); L735: 4,960 lb (NSL) / 4,122 lb (MSL) (breakout at pins) | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
