▶ EngineEngine Manufacturer FPT FPT Engine Model F5D F5D Engine Type Turbocharged and intercooled 4-cylinder diesel 4-cylinder diesel No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed 2300 rpm Not Published Engine Power (Gross) 98 hp 98 hp PTO Power 82 hp 82 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dual dry element Not Published Fuel System Electronic high-pressure common rail direct injection Common rail fuel injection Alternator 120 A Not Published ▶ HydraulicsPump Type Dual engine-driven pumps (open center) Not Published Implement Flow 12.5 gpm (16.9 gpm optional) 16.9 gpm Steering Flow 7.3 gpm 9.7 gpm Total Hydraulic Flow 19.8 gpm (12.5 + 7.3, computed) 26.6 gpm (16.9 + 9.7, computed) Overall Hydraulic Pump Flow 19.8 gpm (12.5 + 7.3, computed) 26.6 gpm (16.9 + 9.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 (3 with DIA option) No. of Optional Remote Valves 2 (3rd remote available through Parts Division) Not Published ▶ Fluid CapacityFuel Tank Capacity 30.3 gal 30.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, mechanical engagement Not Published PTO Rear 540/1000 (base); 540 (optional) 540 (12x12 base); 540/540E or 540/1000 (12x12 optional); 540/540E (24x24 Dual Command base); 540/1000 (24x24 Dual Command optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (ball ends convert to Category I) Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 5,620 lb 5,620 lb (7,351 lb with optional ram) Lift Control Type Single-lever position control with draft-sensing top link Not Published ▶ Transmission & DrivetrainTransmission Type Not Published 12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command or 40x40 Dual Command with creeper (optional) No. of Speeds 12F/12R (20F/12R or 20F/20R with creeper optional) 12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Not Published Brakes Wet disc (mechanical on ROPS, hydraulic on cab) Not Published Seat Suspension & Adjustability Air suspension seat with 15-degree swivel (optional, cab) Cab: fabric mechanical-suspension seat (standard) or fabric air-suspension seat with 15 degree swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests Front Axle Type 2WD or MFD (mechanical front drive) Standard-duty electronically engaged 4WD front axle (standard); mechanically engaged standard-duty 4WD, heavy-duty electronically engaged 4WD, or 2WD front axle (optional) Front Axle Rating Not Published 4,700 lb (standard-duty 4WD, in-action capacity); 5,100 lb (heavy-duty 4WD, in-action capacity) Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 149 in (MFD cab, 16.9R-34 rear tires) 2WD: 161 in; 4WD: 158 in Overall Width 83 in 75.7 in Wheelbase 89 in (MFD) 2WD: 90.2 in; 4WD: 87.9 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 132 in (2WD front axle) Height to Top of ROPS 103 in 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 100 in 102.1 in ▶ WeightTractor Weight (Base) 7,937 lb (MFD cab, 16.9R-34 rear tires) ROPS/2WD: 6,768 lb; ROPS/4WD: 7,451 lb; Cab/2WD: 7,253 lb; Cab/4WD: 7,936 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear 16.9R-34 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid steer-style quick attach (hydraulic coupler) Skid-steer or Euro-style quick attach faceplate Loader Model L620; L630; L735 655TL, 665TL (factory installed, NSL or MSL); 825TL, 835TL, 640TL (dealer installed, NSL or MSL) Loader Lift Height L620: 126.3 in (NSL) / 125.9 in (MSL); L630: 134 in (NSL) / 135 in (MSL); L735: 137 in 655TL NSL: 126 in; 655TL MSL: 125 in; 665TL NSL: 134 in; 665TL MSL: 135 in; 825TL: 135 in; 835TL: 143 in; 640TL: 137 in Loader Lift Capacity (Full Height) L620: 3,461 lb (NSL) / 3,573 lb (MSL); L630: 3,849 lb (NSL) / 4,204 lb (MSL); L735: 4,034 lb (NSL) / 3,505 lb (MSL) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 665TL NSL: 2,632 lb; 665TL MSL: 3,428 lb (at 31.5 in from pivot point); 825TL NSL: 2,755 lb; 825TL MSL: 2,888 lb; 835TL NSL: 3,395 lb; 835TL MSL: 3,571 lb; 640TL NSL: 2,226 lb; 640TL MSL: 2,733 lb (at max height) Loader Breakout Force L620: 5,530 lb (NSL) / 5,483 lb (MSL); L630: 6,649 lb (NSL) / 6,767 lb (MSL); L735: 4,960 lb (NSL) / 4,122 lb (MSL) 655TL NSL: 3,739 lb; 655TL MSL: 3,860 lb; 665TL NSL: 4,455 lb; 665TL MSL: 5,661 lb (at 31.5 in from bucket pivot point); 825TL NSL: 2,910 lb; 825TL MSL: 3,196 lb; 835TL NSL: 3,615 lb; 835TL MSL: 3,990 lb; 640TL NSL: 3,747 lb; 640TL MSL: 3,306 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
