John Deere 4052M vs John Deere 4052M Heavy Duty
Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.
Across 9 measurable specs, the John Deere 4052M Heavy Duty leads 3 categories to 2 (4 tied). Machine pages: John Deere 4052M and John Deere 4052M Heavy Duty.
Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.
Category Verdict
| Spec | John Deere 4052M | John Deere 4052M Heavy Duty |
|---|---|---|
| Engine HP (hp) | 50.8 hp | 50.8 hp |
| PTO HP (hp) | ▲ 42.2 hp | 40.8 hp |
| Weight (lb) | 3,770 lb | ▲ 4,255 lb |
| Loader Lift (lb) | 2,396 lb | ▲ 2,539 lb |
| 3-Pt Lift (24 in) (lb) | 2,500 lb | 2,500 lb |
| Lift Height (in) | ▲ 112 in | 110 in |
| Breakout Force (lbf) | 3,853 lbf | ▲ 4,027 lbf |
| Hydraulic Flow (gpm) | 15.9 gpm | 15.9 gpm |
| Travel Speed (mph) | 18.6 mph | 18.6 mph |
Full Spec Sheet
Every published spec, side by side, including the details the graphs above don't chart.
| Spec | John Deere4052M | John Deere4052M Heavy Duty |
|---|
| Engine Manufacturer | Yanmar | Yanmar |
|---|---|---|
| Engine Model | 4TNV86CT-MJT | 4TNV86CT-MJT |
| Engine Type | Turbocharged 4-cylinder Diesel | Turbocharged 4-cylinder Diesel |
| No. of Cylinders | 4 | 4 |
| Displacement | 127.6 in³ | 127.6 in³ |
| Rated Engine Speed | 2600 rpm | 2600 rpm |
| Engine Power (Gross) | 50.8 hp | 50.8 hp |
| PTO Power | 42.2 hp | 40.8 hp |
| Engine Emissions Constraints | Tier 4 | Tier 4 |
| Cooling System Type | Liquid-cooled | Liquid |
| Air Cleaner | Dual element (dry type with safety element) | Dual element |
| Fuel System | High-pressure common rail direct injection | High-pressure common rail direct injection |
| Alternator | 75 A | 75 A |
John Deere 4052M vs John Deere 4052M Heavy Duty: Quick Answers
- Which has more horsepower, the John Deere 4052M or the John Deere 4052M Heavy Duty?
- They are effectively tied: both machines are rated at 50.8 hp hp for engine hp.
- Which has more PTO horsepower, the John Deere 4052M or the John Deere 4052M Heavy Duty?
- The John Deere 4052M leads on pto hp at 42.2 hp hp, compared to 40.8 hp hp for the John Deere 4052M Heavy Duty.
- Which is heavier, the John Deere 4052M or the John Deere 4052M Heavy Duty?
- The John Deere 4052M Heavy Duty leads on weight at 4,255 lb lb, compared to 3,770 lb lb for the John Deere 4052M.
- Which has more loader lift capacity, the John Deere 4052M or the John Deere 4052M Heavy Duty?
- The John Deere 4052M Heavy Duty leads on loader lift at 2,539 lb lb, compared to 2,396 lb lb for the John Deere 4052M.
- Which has more three-point hitch lift capacity, the John Deere 4052M or the John Deere 4052M Heavy Duty?
- They are effectively tied: both machines are rated at 2,500 lb lb for 3-pt lift (24 in).
