▶ EngineEngine Manufacturer Yanmar John Deere Engine Model 4TNV86CHT-MJT PowerTech 3-cylinder (2.9 L) EWX Engine Type Turbocharged 4-cylinder Diesel Diesel, turbocharged, aftercooled No. of Cylinders 4 3 Displacement 127.6 in³ 177 in³ Rated Engine Speed 2600 rpm 2200 rpm Engine Power (Gross) 65 hp 73.8 hp PTO Power 58 hp 57.7 hp @ 100 rpm Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled (Cool-Gard II coolant) Air Cleaner Dual element (dry type with safety element) Not Published Fuel System High-pressure common rail direct injection Not Published Alternator 75 A, 12 V OOS: 90 A; Cab: 120 A ▶ HydraulicsPump Type Dual Independent Tandem gear pump Implement Flow 10.2 gpm 18.4 gpm Steering Flow 5.7 gpm 6.3 gpm Total Hydraulic Flow 15.9 gpm 24.7 gpm Overall Hydraulic Pump Flow 15.9 gpm 24.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 (rear); 2 (mid) No. of Optional Remote Valves 3rd, 4th, and 5th optional (up to 5 total) Up to 3 total (rear); up to 3 total (mid) ▶ Fluid CapacityFuel Tank Capacity 13 gal OOS: 39.2 gal; OOS (High Capacity): 47.1 gal; Cab: 43.7 gal; Cab (High Capacity): 52 gal Coolant Capacity 1.5 gal OOS: 3.6 gal; Cab: 4.2 gal Crankcase Capacity 1.4 gal (with filter) 2.2 gal Transmission / Hydraulic System Capacity 12.5 gal 10.4 gal Front Axle Fluid Capacity 5.3 qt Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal ▶ PTO & HitchPTO Type Independent, 540 rpm (wet disc clutch) Independent rear PTO, electro-hydraulic wet disc clutch: 540/540E standard, 540/540E/1000 optional PTO Rear 540 rpm 540/540E rpm standard; 1000 rpm optional Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I Category II (convertible to I) Hitch Lift Capacity 3,130 lb 5,305 lb standard; 6,114 lb optional Hitch Lift Capacity (at 24”) 2,500 lb 5,150 lb standard; 5,950 lb optional Lift Control Type Position control Mechanical or Electrohydraulic ▶ Transmission & DrivetrainTransmission Type Standard: 12F/12R PowrReverser; Optional: eHydro (3-range hydrostatic) PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo No. of Speeds 12F/12R 16F/16R (standard PowrReverser); 32F/16R (optional PowrReverser Hi-Lo) Max Travel Speed (Forward) 18.6 mph 24 mph Max Travel Speed (Reverse) 18.6 mph 16F/16R PowrReverser, top gear D-4: 20.5 mph (30K gearing); 23.9 mph (40K gearing), with 480/70R28 rear tires at 2200 rpm Clutch Wet disc Wet Differential Lock & Limited Slip Options Differential lock Electrohydraulic rear differential lock ▶ Chassis, Steering & ControlsFrame Type ROPS - Foldable Cast iron mid-frame Steering Power Not Published Brakes Wet disc Hydraulically actuated wet disc brakes Seat Suspension & Adjustability Adjustable vinyl seat with retractable seat belt; optional premium seat kit with mechanical suspension base OOS: isolated mechanical seat standard (fore/aft, weight, lumbar adjust) or air suspension seat optional; Cab: mechanical seat standard or air suspension seat optional; adjustable weight range 88-330 lb Front Axle Type Mechanical front wheel drive (MFWD) - Standard MFWD Front Axle Rating (Continuous) 3,307 lb 6,613 lb max permissible front axle load Drawbar Capacity Max vertical load 1,103 lb Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb ▶ Dimensions & ManeuverabilityOverall Width 78.2 in Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in Wheelbase 73.0 in 92.5 in Ground Clearance Front axle: 15.6 in Not Published Min. Turn Radius without Brakes 17.1 ft 13.1 ft Height to Top of ROPS 100.2 in 102.1 in (with standard rear tires) Height to Top of ROPS (folded) 80.5 in Not Published Height to Top of Cab Model Not Published 102.9 in (with standard rear tires) Overall Length 130.6 in (with 3-point hitch) 149.5 in (including draft links) ▶ WeightTractor Weight (Base) 3,770 lb (operating weight) 2WD OOS: 8,140 lb; 2WD Cab: 8,580 lb; MFWD OOS: 8,765 lb; MFWD Cab: 9,185 lb (approximate ship weight, less weights) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Bar, R3 Turf, R4 Industrial Not Published R1 Agricultural - Front 8-16 (6PR) 12.4R24 (320/85R24) R1W Radial R1 Agricultural - Rear 13.6-28 18.4R30 (460/85R30) R1W Radial R3 Turf - Front 27X10.50-15 Not Published R3 Turf - Rear 44X18.00-20 (4PR) Not Published R4 Industrial - Front 10-16.5 (6PR) Not Published R4 Industrial - Rear 16.9-24 (6PR) Not Published ▶ Loader & AttachmentsQuick Attach Loader System Quik-Park easy-to-attach/detach loader Not Published Loader Model 400E 520M (4WD only); 540M NSL; 540M MSL; 540R; 600M NSL; 600M MSL Loader Lift Height 400E: 112 in (to pivot pin) 520M: 130-132 in; 540M NSL: 137-141 in; 540M MSL: 138-141 in; 540R: 141.85 in; 600M NSL: 148.8-152.8 in; 600M MSL: 148-153 in Loader Lift Capacity (Full Height) 400E: 2,396 lb (at pivot, full height) 520M NSL: 3,335-3,612 lb; 520M MSL: 2,460-2,661 lb; 540M NSL: 2,394-2,666 lb; 540M MSL: 3,117-3,309 lb; 540R: 3,406 lb; 600M NSL: 3,104-3,236 lb; 600M MSL: 3,891-4,085 lb Loader Breakout Force 400E: 3,853 lbf at pivot; 2,902 lbf at 500 mm forward of pivot 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot; H310 for MFWD tractors) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours Not Published
