▶ EngineEngine Manufacturer Yanmar John Deere Engine Model 4TNV86CHT-MJT PowerTech 4045 PWL Engine Type Turbocharged 4-cylinder Diesel Diesel, turbocharged, air-to-air aftercooled No. of Cylinders 4 4 Displacement 127.6 in³ 276 in³ Rated Engine Speed 2600 rpm 2200 rpm Engine Power (Gross) 74.3 hp 89.2 hp PTO Power 60 hp 75 hp @ 100 rpm Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Cool-Gard II coolant Air Cleaner Dry type with electronic restriction indicator Primary and secondary air cleaner elements Fuel System High pressure common-rail direct injection High pressure common rail; electronic fuel control Alternator 75 A OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V ▶ HydraulicsPump Type Dual Independent Tandem gear pump Implement Flow Not Published 18.4 gpm Steering Flow Not Published 6.3 gpm Total Hydraulic Flow 15.9 gpm 24.7 gpm Overall Hydraulic Pump Flow 15.9 gpm 24.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 (rear, Dual SCV) No. of Optional Remote Valves 3/4/5 optional Up to 1 additional rear valve (3 total with Triple SCV); up to 3 mid SCVs (XI, XII, XIII) for loader functions ▶ Fluid CapacityFuel Tank Capacity 14.7 gal OOS: 29.6 gal; OOS (High Capacity): 37.2 gal; Cab: 37 gal; Cab (High Capacity): 44.9 gal Coolant Capacity 8.0 qt OOS: 5.2 gal; Cab: 5.8 gal Crankcase Capacity 5.7 qt 3.4 gal Transmission / Hydraulic System Capacity Not Published 10.4 gal Front Axle Fluid Capacity Not Published Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal ▶ PTO & HitchPTO Type Independent (wet disc clutch) Independent rear PTO, electro-hydraulic actuation: 540/540E standard, 540/540E/1000 optional PTO Rear 540 rpm 540/540E rpm standard; 1000 rpm optional Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category I Category II (convertible to I) Hitch Lift Capacity 3,130 lb 5,305 lb; 6,114 lb, at hitch ball throughout lift range Hitch Lift Capacity (at 24”) 2,500 lb 5,159 lb standard; 5,954 lb optional Lift Control Type Position control Mechanical or electrohydraulic (draft control) ▶ Transmission & DrivetrainTransmission Type Standard: eHydro (3F/3R hydrostatic); Optional: 12F/12R PowrReverser PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo or 12F/4R SyncShuttle Plus No. of Speeds eHydro: 3F/3R; PowrReverser: 12F/12R 16F/16R (standard PowrReverser); 12F/4R (optional SyncShuttle Plus); 32F/16R (optional PowrReverser Hi-Lo) Max Travel Speed (Forward) 18.7 mph 16F/16R PowrReverser, top gear (D-4): 30K config: 18.6 mph; 40K config: 21.7 mph Max Travel Speed (Reverse) Not Published 16F/16R PowrReverser, top gear (D-4): 30K config: 20.5 mph; 40K config: 23.9 mph Clutch Wet disc (PowrReverser); n/a (eHydro) Wet Differential Lock & Limited Slip Options Yes, mechanical rear differential lock Electro-hydraulic rear differential lock, engage on the go ▶ Chassis, Steering & ControlsFrame Type ComfortGard cab (standard) Cast iron mid-frame Steering Power steering Not Published Brakes Wet disc Not Published Seat Suspension & Adjustability Not Published OOS: isolated mechanical seat, mechanical seat, or air suspension seat (fore/aft, weight and lumbar adjustment); Cab: mechanical suspension seat or air suspension seat; adjustable weight range 88-330 lb Front Axle Type Mechanical front wheel drive (MFWD) - Standard MFWD (standard); 2WD (optional) Front Axle Rating 3,307 lb 6,613 lb (MFWD, max permissible front axle load) Drawbar Capacity Not Published Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb ▶ Dimensions & ManeuverabilityOverall Width 78.3 in Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in Wheelbase 73 in 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 102.1 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 97.4 in 102.9 in Overall Length 133.4 in 149.5 in (including draft links) ▶ WeightTractor Weight (Base) 4,828 lb (operating weight) 2WD, OOS: 8,140 lb; 2WD, Cab: 8,580 lb; MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (shipping weight, less weights) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front 8-16 (6PR) 12.4R24 (320/85R24) R1W Radial R1 Agricultural - Rear 13.6-28 18.4R30 (460/85R30) R1W Radial R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 440R 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) Loader Lift Height Not Published 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in Loader Lift Capacity (Full Height) 440R NSL: 2,539 lb; 440R MSL: 2,213 lb (at pivot pin, 4R Series figures) 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) Loader Breakout Force Not Published 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 6 years or 2,000 hours Not Published
