| Engine Manufacturer | John Deere | John Deere |
|---|
| Engine Model | PowerTech 3029 (2.9L) EWR | CD3029DLV50 |
|---|
| Engine Type | Diesel, turbocharged | 3-cylinder, naturally aspirated, direct injection, liquid-cooled diesel |
|---|
| No. of Cylinders | 3 | 3 |
|---|
| Displacement | 179 in³ | 179 in³ |
|---|
| Rated Engine Speed | 2100 rpm | 2400 rpm |
|---|
| Engine Power (Gross) | 50 hp | 53 hp |
|---|
| PTO Power | 38 hp | 45 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Not Published |
|---|
| Cooling System Type | Liquid cooled with overflow reservoir | Liquid-cooled |
|---|
| Air Cleaner | Dry type with safety element | Dry type with safety element |
|---|
| Fuel System | Electronically controlled, high-pressure common rail | Direct injection, rotary injection pump, electric shutoff |
|---|
| Alternator | 70 A | 40 A |
|---|
|
|---|
| Pump Type | Tandem gear pump (implement + steering) | Tandem gear pump |
|---|
| Implement Flow | 11.4 gpm | 11.4 gpm |
|---|
| Steering Flow | 6.8 gpm | 6.8 gpm |
|---|
| Total Hydraulic Flow | 18.2 gpm | 18.2 gpm |
|---|
| Overall Hydraulic Pump Flow | 18.2 gpm | 18.2 gpm |
|---|
| Hydraulic System Type | Open Center | Open center |
|---|
| Rear Remote Hydraulic Flow | 11.4 gpm at a single rear SCV | 11.4 gpm |
|---|
| No. of Standard Remote Valves | 1 | Not Published |
|---|
| No. of Optional Remote Valves | Not Published | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | 19 gal | 18 gal (open station); 22 gal (cab) |
|---|
| Coolant Capacity | Not Published | 10 qt |
|---|
| Crankcase Capacity | 9.0 qt (with filter) | 9 qt |
|---|
| Transmission / Hydraulic System Capacity | Not Published | 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) |
|---|
| Front Axle Fluid Capacity | MFWD (Dana axle): 1.18 gal differential; 0.21 gal each wheel hub | 5.3 qt (MFWD differential housing); 0.63 qt (each wheel hub) |
|---|
|
|---|
| PTO Type | Independent, mechanical engagement | Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever-operated clutch |
|---|
| PTO Rear | 540 rpm | 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II, convertible to I | Category I and II |
|---|
| Hitch Lift Capacity | 3,968 lb | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 3,192 lb | 3,374 lb |
|---|
| Lift Control Type | Position control, draft control, adjustable rate of drop | Position and depth control, top link draft sensing |
|---|
|
|---|
| Transmission Type | SyncShuttle | CollarShift standard; SyncShuttle optional; PowrReverser optional |
|---|
| No. of Speeds | 9F/3R | 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) |
|---|
| Max Travel Speed (Forward) | Not Published | 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) |
|---|
| Max Travel Speed (Reverse) | Not Published | 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) |
|---|
| Clutch | Dry | Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) |
|---|
| Differential Lock & Limited Slip Options | Mechanical, rear | Not Published |
|---|
|
|---|
| Frame Type | Not Published | Two-post ROPS; cab optional; two-wheel drive or MFWD |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering |
|---|
| Brakes | Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting | Wet disk, self-equalizing, self-adjusting |
|---|
| Seat Suspension & Adjustability | Deluxe adjustable vinyl seat with retractable seat belt | Not Published |
|---|
| Front Axle Type | 2WD or MFWD | Two-wheel drive or mechanical front wheel drive (MFWD) |
|---|
| Front Axle Rating | Not Published | 2,720 to 4,700 lb (2WD, by front tire, no loader); 2,760 to 4,620 lb (MFWD, by front tire, without loader) |
|---|
| Drawbar Capacity | 1,675 lb (fully extended); 2,470 lb (short position) | 1,675 lb (maximum permissible static vertical load, drawbar fully extended) |
|---|
|
|---|
| Overall Width | Not Published | 94.6 in (maximum) |
|---|
| Wheelbase | 80.7 in | 80.7 in |
|---|
| Ground Clearance | Not Published | 19 in (2WD front axle); 17 in (MFWD front axle); 14.3 in (drawbar) |
|---|
| Min. Turn Radius without Brakes | 11.5 ft (2WD); 15.3 ft (MFWD) | 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) |
|---|
| Height to Top of ROPS | Not Published | 88.7 in (extended) |
|---|
| Height to Top of ROPS (folded) | Not Published | 76.7 in |
|---|
| Height to Top of Cab Model | Not Published | 97 in |
|---|
| Overall Length | 144.5 in | 122.6 in (2WD); 125.9 in (MFWD) (less drawbar and front weights) (without 3-point hitch) |
|---|
|
|---|
| Tractor Weight (Base) | 5,335 to 5,809 lb (shipping weight) | 4,370 lb (2WD); 4,730 lb (MFWD); add 1,000 lb with cab |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Not Published | Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 18.4-16.1 |
|---|
| R1 Agricultural - Front | MFWD: 9.5-24; 11.2-24; 12.4-24 | 8.3-24 (MFWD) |
|---|
| R1 Agricultural - Rear | 14.9-28 | 13.6-28 |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader | Not Published |
|---|
| Loader Model | 500E, 500M or 520M | 521; 541; 541 self-leveling; 542; 542 self-leveling |
|---|
| Loader Lift Height | 500M: 124 in | 521: 122 in; 541: 126 in; 541 self-leveling: 130 in |
|---|
| Loader Lift Capacity (Full Height) | 500M: 3,225 lb (at pivot, full height) | 521: 2,500 lb; 541: 2,500 lb; 541 self-leveling: 2,800 lb (full at pin) |
|---|
| Loader Breakout Force | 500M: 4,354 lb (at pivot) | 521: 3,485 lbf; 541: 3,484 lbf; 541 self-leveling: 4,125 lbf (at pin) |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
