John Deere 5060E vs Massey Ferguson 1760M
Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.
Across 8 measurable specs, the John Deere 5060E leads 7 categories to 1. Machine pages: John Deere 5060E and Massey Ferguson 1760M.
Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.
Category Verdict
| Spec | John Deere 5060E | Massey Ferguson 1760M |
|---|---|---|
| Engine HP (hp) | ▲ 60 hp | 59.9 hp |
| PTO HP (hp) | ▲ 48.3 hp | 46.1 hp |
| Weight (lb) | ▲ 5,445 lb | 4,233 lb |
| Loader Lift (lb) | ▲ 3,225 lb | 2,610 lb |
| 3-Pt Lift (24 in) (lb) | 3,192 lb | ▲ 3,307 lb |
| Lift Height (in) | ▲ 124 in | 111 in |
| Breakout Force (lbf) | ▲ 4,354 lbf | 4,000 lbf |
| Hydraulic Flow (gpm) | ▲ 29.6 gpm | 12.7 gpm |
| Travel Speed (mph) | 15.5 mph | n/a |
Full Spec Sheet
Every published spec, side by side, including the details the graphs above don't chart.
| Spec | John Deere5060E | Massey Ferguson1760M |
|---|
| Engine Manufacturer | John Deere | Shibaura |
|---|---|---|
| Engine Model | PowerTech 3029 (2.9L) EWR | N4LDI-TA |
| Engine Type | Diesel, turbocharged | 4-cylinder turbocharged intercooled diesel, liquid-cooled |
| No. of Cylinders | 3 | 4 |
| Displacement | 179 in³ | 135.2 in³ |
| Rated Engine Speed | 2100 rpm | 2600 rpm |
| Engine Power (Gross) | 60 hp | 59.9 hp |
| PTO Power | PR/TSS OOS: 48.3 hp; PR/TSS Cab: 46.3 hp; eHydro: 38.3 hp | Mech: 46.1 hp; HST: 44.4 hp |
| Engine Emissions Constraints | Tier 4 | Tier 4 |
| Cooling System Type | Liquid cooled | Liquid-cooled |
| Air Cleaner | Dry type with safety element | Dry |
| Fuel System | Electronically controlled, high-pressure common rail | Common rail direct injection |
| Alternator | 110 A | Not Published |
John Deere 5060E vs Massey Ferguson 1760M: Quick Answers
- Which has more horsepower, the John Deere 5060E or the Massey Ferguson 1760M?
- The John Deere 5060E leads on engine hp at 60 hp hp, compared to 59.9 hp hp for the Massey Ferguson 1760M.
- Which has more PTO horsepower, the John Deere 5060E or the Massey Ferguson 1760M?
- The John Deere 5060E leads on pto hp at 48.3 hp hp, compared to 46.1 hp hp for the Massey Ferguson 1760M.
- Which is heavier, the John Deere 5060E or the Massey Ferguson 1760M?
- The John Deere 5060E leads on weight at 5,445 lb lb, compared to 4,233 lb lb for the Massey Ferguson 1760M.
- Which has more loader lift capacity, the John Deere 5060E or the Massey Ferguson 1760M?
- The John Deere 5060E leads on loader lift at 3,225 lb lb, compared to 2,610 lb lb for the Massey Ferguson 1760M.
- Which has more three-point hitch lift capacity, the John Deere 5060E or the Massey Ferguson 1760M?
- The Massey Ferguson 1760M leads on 3-pt lift (24 in) at 3,307 lb lb, compared to 3,192 lb lb for the John Deere 5060E.
