| Engine Manufacturer | John Deere | FPT |
|---|
| Engine Model | PowerTech 3029 (2.9L) EWR | R753 |
|---|
| Engine Type | Diesel, turbocharged | Turbocharged 3-cylinder diesel |
|---|
| No. of Cylinders | 3 | 3 |
|---|
| Displacement | 179 in³ | 136 in³ |
|---|
| Rated Engine Speed | 2100 rpm | 2600 rpm |
|---|
| Engine Power (Gross) | 60 hp | 60 hp |
|---|
| PTO Power | PR/TSS OOS: 48.3 hp; PR/TSS Cab: 46.3 hp; eHydro: 38.3 hp | 51 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4B Final |
|---|
| Cooling System Type | Liquid cooled | Not Published |
|---|
| Air Cleaner | Dry type with safety element | 2-stage |
|---|
| Fuel System | Electronically controlled, high-pressure common rail | Direct injection / Common rail |
|---|
| Alternator | 110 A | 75 A |
|---|
|
|---|
| Pump Type | PR/TSS: tandem gear pump (implement + steering); eHydro: three pumps | Dual hydraulic pumps; open center, fixed displacement gear pump |
|---|
| Implement Flow | 11.4 gpm | 12 gpm |
|---|
| Steering Flow | 6.8 gpm | 5.5 gpm |
|---|
| Total Hydraulic Flow | PR/TSS: 18.2 gpm; eHydro: 29.6 gpm | 17.5 gpm |
|---|
| Overall Hydraulic Pump Flow | PR/TSS: 18.2 gpm; eHydro: 29.6 gpm | 17.5 gpm |
|---|
| Hydraulic System Type | Open Center | Open center |
|---|
| Rear Remote Hydraulic Flow | 11.4 gpm at a single rear SCV | Not Published |
|---|
| No. of Standard Remote Valves | 1 | 1 |
|---|
| No. of Optional Remote Valves | 2 | 2 |
|---|
|
|---|
| Fuel Tank Capacity | OOS: 19 gal; Cab: 21 gal | 17.2 gal |
|---|
| Coolant Capacity | Not Published | Not Published |
|---|
| Crankcase Capacity | 9.0 qt (with filter) | Not Published |
|---|
| Transmission / Hydraulic System Capacity | Not Published | Not Published |
|---|
| Front Axle Fluid Capacity | DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side | Not Published |
|---|
|
|---|
| PTO Type | Independent | Independent |
|---|
| PTO Rear | 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) | 540 rpm (540E optional) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II, convertible to I | Category II/I |
|---|
| Hitch Lift Capacity | 3,968 lb | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 3,192 lb | 2,701 lb |
|---|
| Lift Control Type | Position control, draft control, adjustable rate of drop | Position control with mechanical draft control |
|---|
|
|---|
| Transmission Type | SyncShuttle (standard); PowrReverser or eHydro (optional) | 8x8 synchronized shuttle |
|---|
| No. of Speeds | 9F/3R (SyncShuttle); 12F/12R (PowrReverser) | 8F/8R |
|---|
| Max Travel Speed (Forward) | 15.5 mph (SyncShuttle) | Not Published |
|---|
| Max Travel Speed (Reverse) | Not Published | Not Published |
|---|
| Clutch | SyncShuttle: dry; PowrReverser: wet; eHydro: hydrostatic | Dry, 11 in diameter, organic plate |
|---|
| Differential Lock & Limited Slip Options | Mechanical, rear | Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Hydrostatic power steering | Not Published |
|---|
| Brakes | Hydraulically actuated wet disc brakes, self-equalizing and self-adjusting | Individual mechanically actuated wet disc |
|---|
| Seat Suspension & Adjustability | Not Published | Deluxe contoured suspension seat, adjusts to operator height |
|---|
| Front Axle Type | 2WD or MFWD | 4WD: limited-slip front axle with front differential lock, mechanical engagement |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | 1,675 lb (fully extended); 2,470 lb (short position) | Not Published |
|---|
|
|---|
| Overall Width | Not Published | 67.5 in (shipping width) |
|---|
| Wheelbase | 80.7 in | ROPS 4WD: 77.6 in |
|---|
| Ground Clearance | Not Published | Not Published |
|---|
| Min. Turn Radius without Brakes | 11.5 ft (2WD); 15.3 ft (MFWD) | Not Published |
|---|
| Height to Top of ROPS | Not Published | ROPS 4WD: 97.6 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | Not Applicable |
|---|
| Overall Length | 144.5 in | ROPS 4WD: 134 in |
|---|
|
|---|
| Tractor Weight (Base) | 5,445 to 6,702 lb (shipping weight) | ROPS 2WD: 4,442 lb (shipping weight); ROPS 4WD: 5,059 lb (shipping weight) |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Applicable |
|---|
|
|---|
| Tire Size & Options | Not Published | R1 agricultural, R3 turf, R4 industrial |
|---|
| R1 Agricultural - Front | MFWD: 9.5-24; 11.2-24; 12.4-24 | Not Published |
|---|
| R1 Agricultural - Rear | 14.9-28 | 14.9x28 R1 |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | 18.4x24 R4 |
|---|
|
|---|
| Quick Attach Loader System | 520M and H240 loaders (Loader Prep Package includes loader mounting frames and hood guard); not compatible with the 512 loader | 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) |
|---|
| Loader Model | 500E, 500M or 520M | 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) |
|---|
| Loader Lift Height | 500M: 124 in | 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in |
|---|
| Loader Lift Capacity (Full Height) | 500M: 3,225 lb (at pivot, full height) | Not Published |
|---|
| Loader Breakout Force | 500M: 4,354 lb (at pivot) | 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in in front of pivot pin) |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
