| Engine Manufacturer | John Deere | LS Mtron |
|---|
| Engine Model | Not Published | L4C25-T2 |
|---|
| Engine Type | Diesel, turbocharged | In-line vertical, Water cooled 4-cycle diesel, CRDI |
|---|
| No. of Cylinders | 3 | 4 |
|---|
| Displacement | 179 in³ | 152.86 in³ |
|---|
| Rated Engine Speed | 2100 rpm | 2500 rpm |
|---|
| Engine Power (Gross) | 67.6 hp | 68 hp |
|---|
| PTO Power | OOS: 53 hp; Cab: 49 hp | 60 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Not Published |
|---|
| Cooling System Type | Liquid cooled with overflow reservoir | Water-cooled |
|---|
| Air Cleaner | Dry type with safety element | Dry |
|---|
| Fuel System | Electronically controlled, high-pressure common rail | CRDI |
|---|
| Alternator | OOS: 70 A; Cab: 110 A | 70 A, 12 V |
|---|
|
|---|
| Pump Type | Tandem gear pump (implement + steering) | Gear type, engine drive |
|---|
| Implement Flow | 11.4 gpm | 9.9 gpm |
|---|
| Steering Flow | 6.8 gpm | 4.6 gpm |
|---|
| Total Hydraulic Flow | 18.2 gpm | 14.5 gpm |
|---|
| Overall Hydraulic Pump Flow | 18.2 gpm | Not Published |
|---|
| Hydraulic System Type | Open Center | Open center |
|---|
| Rear Remote Hydraulic Flow | 11.4 gpm at a single rear SCV | Not Published |
|---|
| No. of Standard Remote Valves | 1 | 2 |
|---|
| No. of Optional Remote Valves | 2 | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | OOS: 19.6 gal; Cab: 21.6 gal | 21.1 gal |
|---|
| Coolant Capacity | Open operator station: 2.85 gal; Cab: 3.08 gal | 2.4 gal |
|---|
| Crankcase Capacity | 9.0 qt (with filter) | 1.8 gal |
|---|
| Transmission / Hydraulic System Capacity | 8.36 gal (9x3); 9.46 gal (12x12) | 12.4 gal |
|---|
| Front Axle Fluid Capacity | DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side | 2.6 gal |
|---|
|
|---|
| PTO Type | Independent | Independent |
|---|
| PTO Rear | 540 rpm (SyncShuttle); 540/540E rpm (PowrReverser) | 540 (standard); 540 / 750 / 1,000 (optional 3-speed) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II, convertible to I | Category II |
|---|
| Hitch Lift Capacity | 3,968 lb | 4,079 lb |
|---|
| Hitch Lift Capacity (at 24”) | 3,192 lb | 3,483 lb |
|---|
| Lift Control Type | Position control, draft control, adjustable rate of drop | Position and draft control |
|---|
|
|---|
| Transmission Type | SyncShuttle (standard); PowrReverser (optional) | Synchro-shuttle (standard); Power shuttle (optional) |
|---|
| No. of Speeds | 9F/3R (SyncShuttle); 12F/12R (PowrReverser) | F16 x R16 (F32 x R16 with creeper, optional) |
|---|
| Max Travel Speed (Forward) | 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) | 17.99 mph |
|---|
| Max Travel Speed (Reverse) | 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) | 14.81 mph |
|---|
| Clutch | Dual clutch, 11 in (PowrReverser) | Dry single clutch (mechanical); wet clutch disks (power shuttle) |
|---|
| Differential Lock & Limited Slip Options | Mechanical, rear | Mechanical pedal type differential lock |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Hydrostatic power steering | Hydrostatic |
|---|
| Brakes | Hydraulically actuated wet disk brakes, self-equalizing and self-adjusting | Wet disc |
|---|
| Seat Suspension & Adjustability | Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment | Not Published |
|---|
| Front Axle Type | 2WD or MFWD | Not Published |
|---|
| Front Axle Rating | Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) | Not Published |
|---|
| Drawbar Capacity | Adjustable drawbar with interchangeable hitch balls | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 143.3 in | 138.6 in |
|---|
| Overall Width | Not Published | 70 in |
|---|
| Wheelbase | 80.7 in | 80.3 in |
|---|
| Ground Clearance | Not Published | Not Published |
|---|
| Min. Turn Radius without Brakes | 137.8 in (2WD); 183.1 in (4WD) | 10.8 ft (with brake applied) |
|---|
| Height to Top of ROPS | Not Published | 103 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | 100.6 in |
|---|
|
|---|
| Tractor Weight (Base) | 5,555 to 6,812 lb | Roll-bar: 4,586 lb; Cabin: 5,049 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | R1 Ag / R3 Turf / R4 Industrial / Snow | Ag 9.5-20 / 16.9-24; Industrial 10.5/80-18 / 19.5L-24; Turf 36x13.5-15 / 16.9-24 |
|---|
| R1 Agricultural - Front | 11L-15 | 9.5-20 |
|---|
| R1 Agricultural - Rear | 16.9-28 | 16.9-24 |
|---|
| R3 Turf - Front | 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) | 36x13.5-15 |
|---|
| R3 Turf - Rear | 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) | 16.9-24 |
|---|
| R4 Industrial - Front | 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 | 10.5/80-18 |
|---|
| R4 Industrial - Rear | 17.5L-24 8PR R4; 19.5L-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 | 19.5L-24 |
|---|
|
|---|
| Quick Attach Loader System | 512 or 520M | Not Published |
|---|
| Loader Model | 512 or 520M | LL5106 |
|---|
| Loader Lift Height | 512: 113 in; 520M: 132 in | LL5106: 116 in |
|---|
| Loader Lift Capacity (Full Height) | 512: 2,453 lb; 520M: 3,523 lb | Not Published |
|---|
| Loader Breakout Force | 512: 4,781 lb; 520M: 4,641 lb | LL5106: 4,556 lb |
|---|
|
|---|
| Warranty Length & Coverage | 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) | 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty |
|---|
