| PTO Power | 57.6 hp | 65 hp |
|---|
| Alternator | 60 A, 12 V | Not Published |
|---|
| Air Cleaner | Dry type air cleaner with safety element | Not Published |
|---|
| Engine Type | Diesel, turbocharged and aftercooled | Turbocharged intercooled diesel |
|---|
| Fuel System | Electronically controlled, high-pressure common rail | High pressure Common Rail |
|---|
| Displacement | 179 in³ | 207 in³ |
|---|
| No. of Cylinders | 3 | 4 |
|---|
| Rated Engine Speed | 2100 rpm | 2300 rpm |
|---|
| Cooling System Type | Liquid-cooled | Liquid-cooled |
|---|
| Engine Manufacturer | John Deere PowerTech 3029 EWR | FPT Industrial |
|---|
| Engine Power (Gross) | 74.8 hp @ 100 rpm | 75 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4A / Stage IIIB CEGR |
|---|
|
|---|
| Weight with ROPS and Loader | Not Published | Not Applicable |
|---|
| Weight with Cab and Loader | Not Published | Not Applicable |
|---|
|
|---|
| Warranty Length & Coverage | 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine) | Not Published |
|---|
|
|---|
| Pump Type | Tandem gear pump (implement + steering) | Not Published |
|---|
| Steering Flow | 6.8 gpm | Not Published |
|---|
| Implement Flow | 11.4 gpm | 9.4 gpm |
|---|
| Total Hydraulic Flow | 18.2 gpm | Not Published |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | 11.4 gpm at a single rear SCV | Not Published |
|---|
| Overall Hydraulic Pump Flow | 18.2 gpm | Not Published |
|---|
| No. of Optional Remote Valves | 2 | 4 |
|---|
| No. of Standard Remote Valves | 1 | Not Published |
|---|
|
|---|
| PTO Rear | 540 @ 2083 engine rpm; 540E @ 1588 engine rpm | 540/540E (Std); 540/1000 (Opt) |
|---|
| PTO Type | Independent PTO: 540 (SyncShuttle); 540/540E (PowrReverser) | Fully independent |
|---|
| Lift Control Type | Position and draft control; adjustable rate of drop | Lift-O-Matic |
|---|
| Hitch Lift Capacity | 3,968 lb @ hitch points | 7,793 lb |
|---|
| Mid-PTO Availability | Not Applicable | Not Applicable |
|---|
| Category, 3-Point Hitch | Category II; convertible to Category I | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 3,197 lb @ 24 in behind hitch balls | Not Published |
|---|
|
|---|
| R3 Turf - Rear | 41X14.00-20 4PR R3; 44X18.00-20 4PR R3 (Premium) | Not Applicable |
|---|
| R3 Turf - Front | 33X15.50-15 6PR R3; 33X12.50-15 6PR R3; 29X12.5-15 4PR R3 (Premium) | Not Applicable |
|---|
| Tire Size & Options | R1 Ag / R3 Turf / R4 Industrial / Snow | Not Applicable |
|---|
| R4 Industrial - Rear | 4.6 gal-24 8PR R4; 5.2 gal-24 8PR R4; 16.9-30 10PR R4; 43X16.00-20 R4; 43X16.00-20 R4 (Premium); 18.4-30 10PR R4 | Not Applicable |
|---|
| R4 Industrial - Front | 27/12LL-15 6PR R4; 10-16.5 8PR R4; 28X8.50-15 8PR R4; 12.5/80-18 12PR R4 | Not Applicable |
|---|
| R1 Agricultural - Rear | 14.9-28 6PR R1; 16.9-28 6PR R1; 16.9-30 6PR R1; 18.4-30 6PR R1; 460/85R30 R1; 460/85R30 R1W | Not Applicable |
|---|
| R1 Agricultural - Front | 9.5-24 10PR R1; 12.4-24 8PR R1; 320/85R24 R1; 320/85R24 R1W | Not Applicable |
|---|
|
|---|
| Coolant Capacity | Open operator station: 2.85 gal; Cab: 3.08 gal | Not Published |
|---|
| Crankcase Capacity | 9.0 qt (with filter) | Not Published |
|---|
| Fuel Tank Capacity | Open operator station: 15.6 ± 0.44 gal (71 ± 0.5 gal); Cab: 17.59 ± 0.44 gal (80 ± 0.5 gal) | 21.1 gal |
|---|
| Front Axle Fluid Capacity | DANA: 1.18 gal diff + 0.21 gal per hub; Carraro: 1.03 gal diff + 0.15 gal per side | Not Applicable |
|---|
| Transmission / Hydraulic System Capacity | 8.36 gal (9x3); 9.46 gal (12x12) | Not Published |
|---|
|
|---|
| Loader Lift Height | 124 in | Not Applicable |
|---|
| Loader Breakout Force | 4,354 lb (measured at pivot) | Not Applicable |
|---|
| Quick Attach Loader System | Parkable loader (parking system; no tools required for removal/installation); optional John Deere skid steer attachment carrier (tool-free attachment changes) | Not Applicable |
|---|
| Loader Lift Capacity (Full Height) | 3,225 lb (measured at pivot) | Not Applicable |
|---|
|
|---|
| Clutch | Dual clutch, 11 in (PowrReverser) | Not Published |
|---|
| No. of Speeds | 9 forward / 3 reverse (SyncShuttle); 12 forward / 12 reverse (PowrReverser) | 8F/8R |
|---|
| Transmission Type | SyncShuttle 9F/3R (standard); PowrReverser 12F/12R (optional) | Mechanical forward-reverse shuttle |
|---|
| Max Travel Speed (Forward) | 15.5 mph (SyncShuttle); 20.5 mph (PowrReverser) | 6.8 mph |
|---|
| Max Travel Speed (Reverse) | 14.2 mph (SyncShuttle); 22.3 mph (PowrReverser) | 6.8 mph |
|---|
| Differential Lock & Limited Slip Options | Mechanical differential lock (pedal) | Not Applicable |
|---|
|
|---|
| Brakes | Hydraulically actuated wet disk brakes (self-equalizing and self-adjusting) | Not Published |
|---|
| Steering | Hydrostatic power steering | Steering-O-Matic; Steering-O-Matic Plus (optional) |
|---|
| Frame Type | Not Published | Not Published |
|---|
| Front Axle Type | 2WD (standard) or MFWD (optional) | Not Applicable |
|---|
| Drawbar Capacity | 1,675 lb (fully extended); 2,470 lb (short position) | 1,323 lb vertical load |
|---|
| Front Axle Rating | Up to 9,612 lb (max permissible MFWD axle load w/ loader; varies by tire) | Not Applicable |
|---|
| Seat Suspension & Adjustability | Mechanical suspension with weight adjustment; fore/aft and backrest angle adjustment | Air suspended seat (optional) |
|---|
|
|---|
| Wheelbase | 80.7 in | 52.8 in |
|---|
| Overall Width | Not Published | 55.1-57.1 in (1400-57.1 in) |
|---|
| Ground Clearance | Not Published | Not Published |
|---|
| Height to Top of ROPS | Not Published | 94.1 in |
|---|
| Height to Top of Cab Model | Not Published | Not Applicable |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Min. Turn Radius without Brakes | 137.8 in (2WD); 183.1 in (4WD) | Not Published |
|---|
| Overall Length with 3-Point Hitch | 143.3 in | 137.6 in |
|---|
