▶ EngineEngine Manufacturer John Deere FPT (Fiat Power Train) Engine Model PowerTech 3-cylinder (2.9 L) EWX F34 Engine Type Diesel, turbocharged, aftercooled 4-cylinder, CRDI, water-cooled No. of Cylinders 3 4 Displacement 177 in³ 206.7 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 73.8 hp 73.7 hp PTO Power 57.7 hp @ 100 rpm 65.6 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled (Cool-Gard II coolant) Water-cooled Air Cleaner Not Published Not Published Fuel System Not Published Not Published Alternator OOS: 90 A; Cab: 120 A Not Published ▶ HydraulicsPump Type Tandem gear pump Gear pump type, engine drive Implement Flow 18.4 gpm 15.7 gpm Steering Flow 6.3 gpm 6.5 gpm Total Hydraulic Flow 24.7 gpm 22.2 gpm Overall Hydraulic Pump Flow 24.7 gpm 22.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear); 2 (mid) 3 Pairs (Front), 2 Pairs (Rear) No. of Optional Remote Valves Up to 3 total (rear); up to 3 total (mid) Not Published ▶ Fluid CapacityFuel Tank Capacity OOS: 39.2 gal; OOS (High Capacity): 47.1 gal; Cab: 43.7 gal; Cab (High Capacity): 52 gal 30.4 gal Coolant Capacity OOS: 3.6 gal; Cab: 4.2 gal Not Published Crankcase Capacity 2.2 gal Not Published Transmission / Hydraulic System Capacity 10.4 gal 14.5 gal Front Axle Fluid Capacity Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal Not Published ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic wet disc clutch: 540/540E standard, 540/540E/1000 optional Independent PTO Rear 540/540E rpm standard; 1000 rpm optional 540 / 750 / 1,000 Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to I) Category II Hitch Lift Capacity 5,305 lb standard; 6,114 lb optional 7,275 lb Hitch Lift Capacity (at 24”) 5,150 lb standard; 5,950 lb optional 5,181 lb Lift Control Type Mechanical or Electrohydraulic Position & Draft ▶ Transmission & DrivetrainTransmission Type PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo Power Shuttle No. of Speeds 16F/16R (standard PowrReverser); 32F/16R (optional PowrReverser Hi-Lo) 24 X 24 Max Travel Speed (Forward) 24 mph 20.8 mph Max Travel Speed (Reverse) 16F/16R PowrReverser, top gear D-4: 20.5 mph (30K gearing); 23.9 mph (40K gearing), with 480/70R28 rear tires at 2200 rpm Not Published Clutch Wet Wet disks Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Electro-Hydraulic Differential lock (EHD) ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame Not Published Steering Not Published Hydrostatic Brakes Hydraulically actuated wet disc brakes Wet, Multi-disc Seat Suspension & Adjustability OOS: isolated mechanical seat standard (fore/aft, weight, lumbar adjust) or air suspension seat optional; Cab: mechanical seat standard or air suspension seat optional; adjustable weight range 88-330 lb Air suspension seat Front Axle Type MFWD Not Published Front Axle Rating 6,613 lb max permissible front axle load Not Published Drawbar Capacity Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in 78.7 in Wheelbase 92.5 in 90 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 13.1 ft Not Published Height to Top of ROPS 102.1 in (with standard rear tires) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.9 in (with standard rear tires) 105 in Overall Length 149.5 in (including draft links) 152.2 in (frame to link) ▶ WeightTractor Weight (Base) 2WD OOS: 8,140 lb; 2WD Cab: 8,580 lb; MFWD OOS: 8,765 lb; MFWD Cab: 9,185 lb (approximate ship weight, less weights) 7,827 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 9,487 lb (7,827 + 1,660, computed; LL8100 loader without bucket) ▶ Tire OptionsTire Size & Options Not Published Ag 11.2-24 / 16.9-30; R14 320/85R24 / 460/85R30 R1 Agricultural - Front 12.4R24 (320/85R24) R1W Radial 11.2-24 R1 Agricultural - Rear 18.4R30 (460/85R30) R1W Radial 16.9-30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 520M (4WD only); 540M NSL; 540M MSL; 540R; 600M NSL; 600M MSL LL8100 Loader Lift Height 520M: 130-132 in; 540M NSL: 137-141 in; 540M MSL: 138-141 in; 540R: 141.85 in; 600M NSL: 148.8-152.8 in; 600M MSL: 148-153 in LL8100: 139.9 in Loader Lift Capacity (Full Height) 520M NSL: 3,335-3,612 lb; 520M MSL: 2,460-2,661 lb; 540M NSL: 2,394-2,666 lb; 540M MSL: 3,117-3,309 lb; 540R: 3,406 lb; 600M NSL: 3,104-3,236 lb; 600M MSL: 3,891-4,085 lb LL8100: 5,139 lb (at pivot pin) Loader Breakout Force 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot; H310 for MFWD tractors) LL8100: 5,313 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 750 hours; powertrain 5 years or 1,500 hours
