| Engine Manufacturer | John Deere | Mahindra |
|---|
| Engine Model | PowerTech 4045 PWL | NE 479 TCI |
|---|
| Engine Type | 4-cylinder in-line turbocharged and aftercooled diesel, electronic fuel control | Four Stroke, Turbo Charged, Intercooled, Direct Injection, Water Cooled Diesel Engine |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 275 in³ | 203.2 in³ |
|---|
| Rated Engine Speed | 2400 rpm | 2300 rpm |
|---|
| Engine Power (Gross) | 90 hp | 83 hp |
|---|
| PTO Power | 76.7 hp | 70 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 3 |
|---|
| Cooling System Type | Liquid-cooled | Not Published |
|---|
| Air Cleaner | Dry type with safety element | Dry type with safety cartridge & dust unloader valve |
|---|
| Fuel System | High pressure common rail, electronic fuel control | Rotary FIP with KSB Unit MICO (BOSCH) |
|---|
| Alternator | 90 A | 55 A, 12 V |
|---|
|
|---|
| Pump Type | Tandem gear pump, two engine-mounted pumps | Independent fully 'live' hydraulic pump |
|---|
| Implement Flow | 15.9 gpm | 17 gpm |
|---|
| Steering Flow | 6.6 gpm | 5.3 gpm |
|---|
| Total Hydraulic Flow | 22.5 gpm | 22.3 gpm |
|---|
| Overall Hydraulic Pump Flow | 22.5 gpm | Not Published |
|---|
| Hydraulic System Type | Open center | Independent fully live hydraulic pump with Vary-Touch draft and position controls |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 2 rear; 0 mid | 2 |
|---|
| No. of Optional Remote Valves | 3 rear; up to 3 mid | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | 25 gal (open operator station); 30 gal (cab) | 19.28 gal |
|---|
| Coolant Capacity | 2.5 gal (open operator station and low-profile); 3 gal (cab) | 2.58 gal |
|---|
| Crankcase Capacity | 3.2 gal | 9.48 qt |
|---|
| Transmission / Hydraulic System Capacity | 11.5 gal | 8.59 gal |
|---|
| Front Axle Fluid Capacity | 1.3 gal (MFWD differential housing); 0.74 qt (each wheel hub) | 1.79 gal |
|---|
|
|---|
| PTO Type | Independent, electro-hydraulic engagement, wet PTO clutch | Rear independent PTO shaft |
|---|
| PTO Rear | 540/540E standard; 540/1000 optional | Not Published |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category 2, convertible to Category 1 | Category II ball joints with adjustable outside lateral stabilizer |
|---|
| Hitch Lift Capacity | 5159 lb (maximum lift force at hitch ball); 3846 lb throughout lift range | 5500 lb |
|---|
| Hitch Lift Capacity (at 24”) | 4630 lb (electrohydraulic hitch) | 3850 lb |
|---|
| Lift Control Type | Electrohydraulic (EH) hitch with electronic quick raise-lower (premium cab); top-link draft sensing | Position and draft control |
|---|
|
|---|
| Transmission Type | PowrReverser 12F/12R standard; PowrReverser Hi-Lo 24F/12R optional | Not Published |
|---|
| No. of Speeds | 12 forward, 12 reverse (standard); 24 forward, 12 reverse (Hi-Lo) | 12F / 12R |
|---|
| Max Travel Speed (Forward) | 21.7 mph (electronically limited; 12/12 transmission, 460/85R30 rear tires) | Not Published |
|---|
| Max Travel Speed (Reverse) | 21.7 mph (electronically limited; C-4 reverse calculates to 23.8 mph) | Not Published |
|---|
| Clutch | Wet | Dry Dual Clutch (normally disengaged PTO clutch) |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock | Not Published |
|---|
|
|---|
| Frame Type | Foldable ROPS (open operator station); standard or premium cab; MFWD | Not Published |
|---|
| Steering | Hydrostatic power steering | Hydrostatic (Power Steering) |
|---|
| Brakes | Hydraulic wet disk, self-equalizing and self-adjusting, dual stage | Oil immersed, foot operated, independent with interlock for simultaneous operation; hand brake for parking |
|---|
| Seat Suspension & Adjustability | Mechanical seat standard; air-suspension seat optional for cab | Not Published |
|---|
| Front Axle Type | MFWD | Not Published |
|---|
| Front Axle Rating | 6615 lb (max front axle load); 13230 lb (max rear axle load); 11510 lb (max permissible weight) | Not Published |
|---|
| Drawbar Capacity | 2755 lb (standard drawbar, 9.8 in extended); 2425 lb (standard, 350 and 15.7 in extended); 3195 lb (heavy duty, 9.8 in); 2645 lb (heavy duty, 350 and 15.7 in) | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 159.13 in | 162.04 in |
|---|
| Overall Width | 83.6 in (minimum, 16.9-30 R1 tires); 85.1 in (minimum, 18.4-30 R1 tires) | 77.3 in |
|---|
| Wheelbase | 92.5 in | 2WD: 85.31 in; 4WD: 85.8 in |
|---|
| Ground Clearance | 17 in (front axle) | Not Published |
|---|
| Min. Turn Radius without Brakes | 11.6 ft (MFWD) | 2WD: 157 in; 4WD: 180 in |
|---|
| Height to Top of ROPS | 101.1 in | 2WD: 89.5 in; 4WD: 94.5 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 102.4 in | Not Published |
|---|
|
|---|
| Tractor Weight (Base) | 7275 lb (MFWD open operator station); 8150 lb (MFWD cab) | 2WD: 6878 lb; 4WD: 7297 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | 18.4-30 R1 bias rear standard; 16.9-30 R1 also listed | Not Published |
|---|
| R1 Agricultural - Front | 12.4-24 | Not Published |
|---|
| R1 Agricultural - Rear | 18.4-30 R1 bias | Not Published |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | Quick attach option with integrated parking stand (520M and 540M MSL or NSL) | Not Published |
|---|
| Loader Model | 520M (NSL and MSL); 540M (NSL) | Not Published |
|---|
| Loader Lift Height | 520M NSL: 133 in; 520M MSL: 133 in | Not Published |
|---|
| Loader Lift Capacity (Full Height) | 520M NSL: 3644 lb; 520M MSL: 2687 lb (to maximum height at pivot point) | Not Published |
|---|
| Loader Breakout Force | 520M NSL: 4511 lbf; 520M MSL: 4691 lbf (at pivot point) | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | 5-year / 2,000-hour powertrain warranty (whichever comes first), as sold new | Not Published |
|---|
