▶ EngineEngine Manufacturer John Deere FPT Engine Model PowerTech 4045 PWL F36 Engine Type Diesel, turbocharged, air-to-air aftercooled 4-cylinder diesel, turbocharged and aftercooled No. of Cylinders 4 4 Displacement 276 in³ 219.7 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 89.2 hp 88.5 hp PTO Power 75 hp @ 100 rpm Not Published Engine Emissions Constraints Tier 4 Stage V (ECOBlue Compact HI-eSCR + Light CEGR) Cooling System Type Cool-Gard II coolant Not Published Air Cleaner Primary and secondary air cleaner elements Not Published Fuel System High pressure common rail; electronic fuel control Common rail fuel injection Alternator OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V Not Published ▶ HydraulicsPump Type Tandem gear pump Open center, dual pumps: implement pump plus dedicated steering pump Implement Flow 18.4 gpm 21.7 gpm Steering Flow 6.3 gpm 9.7 gpm Total Hydraulic Flow 24.7 gpm 31.4 gpm (21.7 + 9.7, computed) Overall Hydraulic Pump Flow 24.7 gpm 31.4 gpm (21.7 + 9.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear, Dual SCV) 2 rear remotes (four couplers) No. of Optional Remote Valves Up to 1 additional rear valve (3 total with Triple SCV); up to 3 mid SCVs (XI, XII, XIII) for loader functions 1 (3rd rear remote); 1 with diverter (3rd rear remote with 1 diverter) ▶ Fluid CapacityFuel Tank Capacity OOS: 29.6 gal; OOS (High Capacity): 37.2 gal; Cab: 37 gal; Cab (High Capacity): 44.9 gal 34.3 gal Coolant Capacity OOS: 5.2 gal; Cab: 5.8 gal Not Published Crankcase Capacity 3.4 gal Not Published Transmission / Hydraulic System Capacity 10.4 gal Not Published Front Axle Fluid Capacity Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal Not Published ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic actuation: 540/540E standard, 540/540E/1000 optional Fully independent electrohydraulic PTO, wet clutch PTO Rear 540/540E rpm standard; 1000 rpm optional 540/1000 rpm (interchangeable, standard) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to I) Category II Hitch Lift Capacity 5,305 lb; 6,114 lb, at hitch ball throughout lift range Not Published Hitch Lift Capacity (at 24”) 5,159 lb standard; 5,954 lb optional 4,123 lb Lift Control Type Mechanical or electrohydraulic (draft control) Electronic draft control (Dual Command); single-lever Lift-O-Matic PLUS (standard) ▶ Transmission & DrivetrainTransmission Type PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo or 12F/4R SyncShuttle Plus 24x24 Dual Command hi-lo power shuttle, column-mounted No. of Speeds 16F/16R (standard PowrReverser); 12F/4R (optional SyncShuttle Plus); 32F/16R (optional PowrReverser Hi-Lo) 24F/24R (Dual Command) Max Travel Speed (Forward) 16F/16R PowrReverser, top gear (D-4): 30K config: 18.6 mph; 40K config: 21.7 mph 25 mph Max Travel Speed (Reverse) 16F/16R PowrReverser, top gear (D-4): 30K config: 20.5 mph; 40K config: 23.9 mph Not Published Clutch Wet Not Published Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock, engage on the go Electrohydraulic rear differential lock ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame Not Published Steering Not Published Not Published Brakes Not Published Not Published Seat Suspension & Adjustability OOS: isolated mechanical seat, mechanical seat, or air suspension seat (fore/aft, weight and lumbar adjustment); Cab: mechanical suspension seat or air suspension seat; adjustable weight range 88-330 lb Air-suspension cloth seat Front Axle Type MFWD (standard); 2WD (optional) Heavy-duty class 1.5 4WD front axle Front Axle Rating 6,613 lb (MFWD, max permissible front axle load) Not Published Drawbar Capacity Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb Not Published ▶ Dimensions & ManeuverabilityOverall Width Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) Wheelbase 92.5 in 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 102.1 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.9 in 103.6 in Overall Length 149.5 in (including draft links) 158.2 in ▶ WeightTractor Weight (Base) 2WD, OOS: 8,140 lb; 2WD, Cab: 8,580 lb; MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (shipping weight, less weights) 10,240 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 420/85R38 (reference tire for weight and dimensions); rear tires as large as R38 available R1 Agricultural - Front 12.4R24 (320/85R24) R1W Radial Not Published R1 Agricultural - Rear 18.4R30 (460/85R30) R1W Radial Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer-style or Euro-style quick attach faceplate (available, both LU loaders) Loader Model 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) 650LU (NSL); 655LU (MSL) Loader Lift Height 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in 650LU: 149.7 in; 655LU: 149.7 in Loader Lift Capacity (Full Height) 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) Loader Breakout Force 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
