▶ EngineEngine Manufacturer John Deere KIOTI (Daedong) Engine Model PowerTech 4045 PWL 4J243TA-TP5B Engine Type 4-cylinder in-line turbocharged and air-to-air aftercooled diesel, electronic fuel control In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4J243TA-TP5B) No. of Cylinders 4 4 Displacement 276 in³ 233.9 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 90 hp 90 hp PTO Power 75 hp 70 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry type with safety element Dry element with evacuator valve Fuel System High pressure common rail, 4 valve, electronic fuel control Common Rail Direct Injection (CRDI) Alternator 200 A Not Published ▶ HydraulicsPump Type Tandem gear pump (open center); variable axial piston implement pump (pressure-and-flow compensated, optional) Gear Implement Flow 19.3 gpm (open center); 30.9 gpm (PFC) 19.8 gpm Steering Flow 6.2 gpm (open center) 12.2 gpm Total Hydraulic Flow 25.6 gpm (open center) 32 gpm Overall Hydraulic Pump Flow 25.5 gpm (open center); 31 gpm (PFC) 32 gpm Hydraulic System Type Open center (standard); closed center PFC (optional) Open Center Rear Remote Hydraulic Flow 19.3 gpm (open center); 26.4 gpm (PFC) Not Published No. of Standard Remote Valves 2 rear and 2 mid (stackable) 3 No. of Optional Remote Valves Mid and front SCVs optional; up to 3 rear 1 ▶ Fluid CapacityFuel Tank Capacity 38 gal 47.6 gal Coolant Capacity 4.25 gal 4.6 gal Crankcase Capacity 3.1 gal 3.9 gal Transmission / Hydraulic System Capacity 11.75 gal (open center); 12.5 gal (closed center PFC) 20.34 gal Front Axle Fluid Capacity 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) 2.6 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft Independent PTO Rear 540/540E/1000 rpm 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (telescoping draft links with Category II balls) Category II Hitch Lift Capacity 7158 lb; 8157 lb throughout lift range at hitch ball; 11122 lb / 12515 lb maximum 8,079 lb Hitch Lift Capacity (at 24”) 6975 lb; 7868 lb throughout lift range 8,002 lb Lift Control Type Electro-hydraulic hitch with fender controls, lower link draft sensing Electronic control ▶ Transmission & DrivetrainTransmission Type CommandQuad manual 16F/16R standard (electronic range and gear shifting, AutoClutch); CommandQuad manual with creeper optional; Command8 32F/16R optional Power Shuttle w/ Hi-Lo Shift No. of Speeds 16 forward, 16 reverse (CommandQuad); 32 forward, 16 reverse (Command8) 24 forward / 24 reverse Max Travel Speed (Forward) 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires); limited to 24.9 mph 23.83 mph Max Travel Speed (Reverse) 18.6 mph (limited to 18.6 mph) 23.67 mph Clutch Wet traction clutch with AutoClutch Wet Multi Disc Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock Mechanical rear differential lock (standard); front limited-slip differential ▶ Chassis, Steering & ControlsFrame Type Cab standard with air conditioning; four-wheel drive Not Published Steering Hydrostatic power steering Hydrostatic Power Steering Brakes Hydraulic wet disk, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Wet Multi Disc Seat Suspension & Adjustability Not Published Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Front Axle Type Mechanical front wheel drive (MFWD), electro-hydraulic engagement, planetary final drives 4WD with outboard planetary final drives and limited-slip differential Front Axle Rating Not Published Not Published Drawbar Capacity 2756 lb (standard drawbar, 9.8 in extended); 2205 lb (standard, 350 and 15.7 in); 3197 lb (heavy duty, 9.8 in); 2646 lb (heavy duty, 350 and 15.7 in) Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 147.8 in 170.8 in Overall Width 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) 88.6 in Wheelbase 88.6 in 94.9 in Ground Clearance Not Published 18.9 in Min. Turn Radius without Brakes 12.1 ft 12.7 ft (with brake applied) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 106.1 in 111.9 in ▶ WeightTractor Weight (Base) 9811 lb 10,230 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) R1 Agricultural - Front 12.4R24 13.6-24 R1 Agricultural - Rear 18.4R30 18.4-34 R3 Turf - Front 44x18-20 Not Published R3 Turf - Rear 23.1-26 Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 19.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Global carrier in base; John Deere 500-style carrier optional (540R) KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Loader Model 540R (non self-leveling and mechanical self-leveling) KL1155 Loader Lift Height 540R: 141.9 in KL1155: 150.6 in (to pivot pin) Loader Lift Capacity (Full Height) 540R: 4529 lb (full at pin) KL1155: 4,216 lb (at pivot pins) Loader Breakout Force 540R: 4934 lbf (at pin) KL1155: 8,554 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage Not Published Tractors (Non-Commercial): 24 months parts & labor, unlimited hours, 0% deductible; powertrain (engine and driveline): 48 months unlimited hours on HX Series
