▶ EngineEngine Manufacturer John Deere FPT Engine Model PowerTech 4045 PWL F36 Engine Type 4-cylinder in-line turbocharged and air-to-air aftercooled diesel, electronic fuel control 4-cylinder No. of Cylinders 4 4 Displacement 276 in³ Not Published Rated Engine Speed 2200 rpm Not Published Engine Power (Gross) 90 hp 90 hp PTO Power 75 hp 75 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Dry type with safety element Not Published Fuel System High pressure common rail, 4 valve, electronic fuel control Not Published Alternator 200 A Not Published ▶ HydraulicsPump Type Tandem gear pump (open center); variable axial piston implement pump (pressure-and-flow compensated, optional) Not Published Implement Flow 19.3 gpm (open center); 30.9 gpm (PFC) Not Published Steering Flow 6.2 gpm (open center) Not Published Total Hydraulic Flow 25.6 gpm (open center) 21 gpm Overall Hydraulic Pump Flow 25.5 gpm (open center); 31 gpm (PFC) Not Published Hydraulic System Type Open center (standard); closed center PFC (optional) Not Published Rear Remote Hydraulic Flow 19.3 gpm (open center); 26.4 gpm (PFC) Not Published No. of Standard Remote Valves 2 rear and 2 mid (stackable) Not Published No. of Optional Remote Valves Mid and front SCVs optional; up to 3 rear Not Published ▶ Fluid CapacityFuel Tank Capacity 38 gal 34.3 gal Coolant Capacity 4.25 gal Not Published Crankcase Capacity 3.1 gal Not Published Transmission / Hydraulic System Capacity 11.75 gal (open center); 12.5 gal (closed center PFC) Not Published Front Axle Fluid Capacity 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft Not Published PTO Rear 540/540E/1000 rpm Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (telescoping draft links with Category II balls) Not Published Hitch Lift Capacity 7158 lb; 8157 lb throughout lift range at hitch ball; 11122 lb / 12515 lb maximum Not Published Hitch Lift Capacity (at 24”) 6975 lb; 7868 lb throughout lift range Not Published Lift Control Type Electro-hydraulic hitch with fender controls, lower link draft sensing Not Published ▶ Transmission & DrivetrainTransmission Type CommandQuad manual 16F/16R standard (electronic range and gear shifting, AutoClutch); CommandQuad manual with creeper optional; Command8 32F/16R optional 12x12 electronic power shuttle No. of Speeds 16 forward, 16 reverse (CommandQuad); 32 forward, 16 reverse (Command8) 12 forward / 12 reverse Max Travel Speed (Forward) 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires); limited to 24.9 mph Not Published Max Travel Speed (Reverse) 18.6 mph (limited to 18.6 mph) Not Published Clutch Wet traction clutch with AutoClutch Not Published Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Cab standard with air conditioning; four-wheel drive Not Published Steering Hydrostatic power steering Not Published Brakes Hydraulic wet disk, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Not Published Seat Suspension & Adjustability Not Published Air ride seat (standard); instructor seat available Front Axle Type Mechanical front wheel drive (MFWD), electro-hydraulic engagement, planetary final drives Class 1.0 HD heavy-duty front axle Front Axle Rating Not Published Not Published Drawbar Capacity 2756 lb (standard drawbar, 9.8 in extended); 2205 lb (standard, 350 and 15.7 in); 3197 lb (heavy duty, 9.8 in); 2646 lb (heavy duty, 350 and 15.7 in) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 147.8 in Not Published Overall Width 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) Not Published Wheelbase 88.6 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 12.1 ft Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 106.1 in Not Published ▶ WeightTractor Weight (Base) 9811 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 Not Published R1 Agricultural - Front 12.4R24 Not Published R1 Agricultural - Rear 18.4R30 Not Published R3 Turf - Front 44x18-20 Not Published R3 Turf - Rear 23.1-26 Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 19.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Global carrier in base; John Deere 500-style carrier optional (540R) Not Published Loader Model 540R (non self-leveling and mechanical self-leveling) 630LU; 635LU Loader Lift Height 540R: 141.9 in 143.9 in (630LU and 635LU) Loader Lift Capacity (Full Height) 540R: 4529 lb (full at pin) 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, 31.5 in forward of the bucket pivot point) Loader Breakout Force 540R: 4934 lbf (at pin) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
