▶ EngineEngine Manufacturer John Deere FPT Engine Model PowerTech PWL 4045 F5D Engine Type Diesel, turbocharged, liquid-cooled 4-cylinder diesel No. of Cylinders 4 4 Displacement 276 in³ 207 in³ Rated Engine Speed 2400 rpm Not Published Engine Power (Gross) 100 hp 98 hp PTO Power 85 hp 82 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry type with safety element Not Published Fuel System High Pressure Common Rail Common rail fuel injection Alternator 90 A Not Published ▶ HydraulicsPump Type Tandem gear pump (implement + steering) Not Published Implement Flow 15.9 gpm 16.9 gpm Steering Flow 6.6 gpm 9.7 gpm Total Hydraulic Flow 22.5 gpm 26.6 gpm (16.9 + 9.7, computed) Overall Hydraulic Pump Flow 22.5 gpm 26.6 gpm (16.9 + 9.7, computed) Hydraulic System Type Open Center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 (3 with DIA option) No. of Optional Remote Valves 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 30 gal 30.3 gal Coolant Capacity Cab: 3.0 gal; OOS and Low-Profile: 2.5 gal Not Published Crankcase Capacity 3.2 gal (with filter) Not Published Transmission / Hydraulic System Capacity 11.5 gal Not Published Front Axle Fluid Capacity MFWD differential housing: 1.3 gal; MFWD wheel hub (each): 0.74 qt Not Published ▶ PTO & HitchPTO Type Independent, electrohydraulic engagement Not Published PTO Rear 540/540E rpm 540 (12x12 base); 540/540E or 540/1000 (12x12 optional); 540/540E (24x24 Dual Command base); 540/1000 (24x24 Dual Command optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,213 lb 5,620 lb (7,351 lb with optional ram) Lift Control Type Position control with top link draft sensing Not Published ▶ Transmission & DrivetrainTransmission Type PowrReverser 12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command or 40x40 Dual Command with creeper (optional) No. of Speeds 12F/12R (standard); 24F/12R (optional) 12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional) Max Travel Speed (Forward) 12F/12R: 21.8 mph; 24F/12R: 26.0 mph Not Published Max Travel Speed (Reverse) 12F/12R: 23.8 mph; 24F/12R: 23.9 mph Not Published Clutch Wet traction clutch Not Published Differential Lock & Limited Slip Options Mechanical Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Not Published Brakes Hydraulic wet disk brakes, self-equalizing and self-adjusting Not Published Seat Suspension & Adjustability Not Published Cab: fabric mechanical-suspension seat (standard) or fabric air-suspension seat with 15 degree swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests Front Axle Type MFWD (4-wheel drive only) Standard-duty electronically engaged 4WD front axle (standard); mechanically engaged standard-duty 4WD, heavy-duty electronically engaged 4WD, or 2WD front axle (optional) Front Axle Rating 6,615 lb 4,700 lb (standard-duty 4WD, in-action capacity); 5,100 lb (heavy-duty 4WD, in-action capacity) Drawbar Capacity Standard: 2,755 lb; 2,425 lb (350/15.7 in extended). Heavy-Duty: 3,195 lb; 2,645 lb (350/15.7 in extended) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 154.5 in 2WD: 161 in; 4WD: 158 in Overall Width 69.6 in 75.7 in Wheelbase 90.6 in 2WD: 90.2 in; 4WD: 87.9 in Ground Clearance ROPS: 17 in; Cab: 15.2 in Not Published Min. Turn Radius without Brakes Not Published 132 in (2WD front axle) Height to Top of ROPS 100.8 in 106.5 in Height to Top of ROPS (folded) 78.6 in Not Published Height to Top of Cab Model 101.2 in 102.1 in ▶ WeightTractor Weight (Base) OOS and Low-Profile: 7,055 lb; MFWD Cab: 7,937 lb ROPS/2WD: 6,768 lb; ROPS/4WD: 7,451 lb; Cab/2WD: 7,253 lb; Cab/4WD: 7,936 lb Weight with ROPS and Loader 7,055 lb Not Published Weight with Cab and Loader 7,937 lb Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front 12.4-24 Not Published R1 Agricultural - Rear 18.4-30 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 19.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System H260 Skid-steer or Euro-style quick attach faceplate Loader Model H260NSL 655TL, 665TL (factory installed, NSL or MSL); 825TL, 835TL, 640TL (dealer installed, NSL or MSL) Loader Lift Height 137 in 655TL NSL: 126 in; 655TL MSL: 125 in; 665TL NSL: 134 in; 665TL MSL: 135 in; 825TL: 135 in; 835TL: 143 in; 640TL: 137 in Loader Lift Capacity (Full Height) 3,879 lb 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 665TL NSL: 2,632 lb; 665TL MSL: 3,428 lb (at 31.5 in from pivot point); 825TL NSL: 2,755 lb; 825TL MSL: 2,888 lb; 835TL NSL: 3,395 lb; 835TL MSL: 3,571 lb; 640TL NSL: 2,226 lb; 640TL MSL: 2,733 lb (at max height) Loader Breakout Force 6,521 lb 655TL NSL: 3,739 lb; 655TL MSL: 3,860 lb; 665TL NSL: 4,455 lb; 665TL MSL: 5,661 lb (at 31.5 in from bucket pivot point); 825TL NSL: 2,910 lb; 825TL MSL: 3,196 lb; 835TL NSL: 3,615 lb; 835TL MSL: 3,990 lb; 640TL NSL: 3,747 lb; 640TL MSL: 3,306 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
