▶ EngineEngine Manufacturer John Deere John Deere Engine Model PowerTech 4045 PWL PowerTech 4045 EWL Engine Type Diesel, turbocharged, air-to-air aftercooled Diesel, turbocharged with intercooler, 4-valve HPCR No. of Cylinders 4 4 Displacement 276 in³ 276 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 113.9 hp 130 hp PTO Power 100 hp @ 100 rpm 115 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled (Cool-Gard II coolant) Not Published Air Cleaner Dry air cleaner, primary and secondary elements Dry type air cleaner with safety (secondary) element Fuel System High Pressure Common Rail (HPCR) electronic fuel injection High Pressure Common Rail (HPCR) electronic fuel injection, 4-valve Alternator OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V 120 A, 12 V ▶ HydraulicsPump Type Tandem gear pump Tandem gear pump Implement Flow 18.4 gpm 18.4 gpm Steering Flow 6.3 gpm 6.3 gpm Total Hydraulic Flow 24.7 gpm 25.6 gpm Overall Hydraulic Pump Flow 24.7 gpm 25.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear, Dual SCV) 2 (rear); 2 (mid) No. of Optional Remote Valves Up to 1 additional rear (3 total, Deluxe Triple SCV); mid SCVs up to 3 (XI, XII, XIII) for loader functions Up to 3 total (rear); up to 3 total (mid) ▶ Fluid CapacityFuel Tank Capacity OOS: 37.2 gal; Cab: 44.9 gal 42.4 gal (Standard Cab) Coolant Capacity OOS: 5.2 gal; Cab: 5.8 gal Not Published Crankcase Capacity 3.4 gal Not Published Transmission / Hydraulic System Capacity 10.4 gal Not Published Front Axle Fluid Capacity Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal Not Published ▶ PTO & HitchPTO Type Independent rear PTO (electro-hydraulic wet disc clutch): 540/540E standard; 540/540E/1000 optional Independent rear PTO, electro-hydraulic clutch PTO Rear 540/540E rpm standard; 1000 rpm optional 540 rpm standard; 540/1000 rpm optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 2 (convertible to 1) Category 2 (convertible to 1) Hitch Lift Capacity 5,305 lb standard; 6,114 lb optional 6,975 lb standard; 7,868 lb optional Hitch Lift Capacity (at 24”) 5,159 lb standard; 5,954 lb optional 6,975 lb standard; 7,868 lb optional Lift Control Type Mechanical or electrohydraulic (draft control) Electrohydraulic ▶ Transmission & DrivetrainTransmission Type PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo or 12F/4R SyncShuttle Plus PowrQuad PLUS 16F/16R or Powr8 32F/16R (cab only) No. of Speeds 16F/16R (standard PowrReverser); 12F/4R (optional SyncShuttle Plus); 32F/16R (optional PowrReverser Hi-Lo) 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) Max Travel Speed (Forward) 16F/16R PowrReverser, top gear (D-4): 30K config: 18.6 mph; 40K config: 21.7 mph 24.9 mph; PowrQuad PLUS 16F/16R (standard) or Powr8 32F/16R (optional) Max Travel Speed (Reverse) 16F/16R PowrReverser, top gear (D-4): 30K config: 20.5 mph; 40K config: 23.9 mph Not Published Clutch Wet Electro-hydraulic Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock, engage on the go Electro-hydraulic rear differential lock ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame Cast iron mid-frame design Steering Not Published Power steering Brakes Not Published Hydraulic wet disk brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability OOS: isolated mechanical seat standard (fore/aft, weight, lumbar adjust) or air suspension seat optional; Cab: mechanical seat standard or air suspension seat optional; adjustable weight range 88-330 lb Mechanical suspension seat standard; air suspension seat optional; premium air suspension seat (heated, low-frequency) optional Front Axle Type MFWD MFWD Front Axle Rating 6,613 lb (MFWD, max permissible front axle load) Not Published Drawbar Capacity Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb 3,197 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 149.5 in Not Published Overall Width Cab, with fender extension: 85.6 in; Cab, without fender extension: 74.0 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in Not Published Wheelbase 92.5 in 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 102.1 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.9 in Not Published ▶ WeightTractor Weight (Base) MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (2WD not offered on 5115M) 9,185 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural R1 Agricultural - Front 12.4R24 (320/85R24) R1W Radial 12.4R24 R1 Agricultural - Rear 18.4R30 (460/85R30) R1W Radial 18.4R30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 in, 12PR R4 Bias R4 Industrial - Rear Not Published 19.5L-24 in, 10PR R4 Bias ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) 520M (4WD only); 540M; 540R; 600M Loader Lift Height 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in 520M: NSL/MSL 130-132 in; 540M: NSL 137-141 in, MSL 138-141 in; 540R: 141.85 in; 600M: NSL 148.8-152.8 in, MSL 148-153 in Loader Lift Capacity (Full Height) 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) 520M (4WD): NSL 3,334.9-3,611.6 lb, MSL 2,460.1-2,661 lb; 540M: NSL 2,394-2,666 lb, MSL 3,117.3-3,309.1 lb; 540R: 3,406 lb; 600M: NSL 3,104-3,236 lb, MSL 3,891-4,085 lb Loader Breakout Force 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) Not Published ▶ WarrantyWarranty Length & Coverage 24 Months or 2000 Hours, Whichever Comes First (whole-machine, standard Agricultural Equipment tractor term) 24 Months or 2000 Hours, Whichever Comes First (whole-machine, standard Agricultural Equipment tractor term)
