Single-plate wet clutch with easy shift knob and electrohydraulic power shuttle lever
Differential Lock & Limited Slip Options
Electro-hydraulic rear differential lock, engage on the go
Rear differential lock engaged via electrohydraulic rocker switch; Hydra-Lock hydraulic front axle differential lock on 4WD
Frame Type
Cast iron mid-frame
Not Published
Steering
Not Published
Power steering; cab: tilt and telescopic column, platform: tilt column
Brakes
Not Published
Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals
Seat Suspension & Adjustability
OOS: isolated mechanical seat standard (fore/aft, weight, lumbar adjust) or air suspension seat optional; Cab: mechanical seat standard or air suspension seat optional; adjustable weight range 88-330 lb
Cab: air-ride swivel seat; platform: mechanical spring suspension seat with armrests
Front Axle Type
MFWD
Heavy-duty 4WD front axle: cast steel, fixed, center drive line, planetary final drives
Cab, with fender extension: 85.6 in; Cab, without fender extension: 74.0 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in
64.8 in
Wheelbase
92.5 in
98.4 in
Ground Clearance
Not Published
Not Published
Min. Turn Radius without Brakes
Not Published
Not Published
Height to Top of ROPS
102.1 in
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
102.9 in
Not Published
Tractor Weight (Base)
MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (2WD not offered on 5115M)
