| Engine Manufacturer | John Deere | Fiat Powertrain Technologies (FPT) |
|---|
| Engine Model | PowerTech 4045 PWL | F36 |
|---|
| Engine Type | Diesel, turbocharged, air-to-air aftercooled | 4-cylinder diesel, turbocharged and aftercooled |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 276 in³ | 220 in³ |
|---|
| Rated Engine Speed | 2200 rpm | 2300 rpm |
|---|
| Engine Power (Gross) | 113.9 hp | 115.3 hp |
|---|
| PTO Power | 100 hp @ 100 rpm | Not Published |
|---|
| Engine Emissions Constraints | Tier 4 | Stage V Compliant with ECOBlue Compact HI-eSCR + Light CEGR |
|---|
| Cooling System Type | Liquid-cooled (Cool-Gard II coolant) | Not Published |
|---|
| Air Cleaner | Dry air cleaner, primary and secondary elements | Not Published |
|---|
| Fuel System | High pressure common rail (HPCR); electronic fuel control | Common rail fuel injection |
|---|
| Alternator | OOS: 90 A; Cab: 120 A; Field-installed option: 200 A, 12 V | Not Published |
|---|
|
|---|
| Pump Type | Tandem gear pump | Open center, dual pumps: implement pump plus dedicated steering pump |
|---|
| Implement Flow | 18.4 gpm | 21.7 gpm |
|---|
| Steering Flow | 6.3 gpm | 9.7 gpm |
|---|
| Total Hydraulic Flow | 24.7 gpm | 31.4 gpm (21.7 + 9.7, computed) |
|---|
| Overall Hydraulic Pump Flow | 24.7 gpm | 31.4 gpm (21.7 + 9.7, computed) |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 2 (rear, Dual SCV) | 2 rear remotes (four couplers) |
|---|
| No. of Optional Remote Valves | 3 rear valves total (3rd rear SCV optional); up to 3 mid SCVs (XI, XII, XIII) for loader functions | 1 (3rd rear remote, optional); 3rd rear remote with 1 diverter (optional) |
|---|
|
|---|
| Fuel Tank Capacity | OOS: 37.2 gal; Cab: 44.9 gal | 34.3 gal |
|---|
| Coolant Capacity | OOS: 5.2 gal; Cab: 5.8 gal | Not Published |
|---|
| Crankcase Capacity | 3.4 gal | Not Published |
|---|
| Transmission / Hydraulic System Capacity | 10.4 gal | Not Published |
|---|
| Front Axle Fluid Capacity | Differential housing (MFWD): 1.3 gal; Wheel hub (each): 0.2 gal | Not Published |
|---|
|
|---|
| PTO Type | Independent rear PTO, electro-hydraulic wet disc clutch: 540/540E standard, 540/540E/1000 optional | Fully-independent, electrohydraulic, wet-clutch |
|---|
| PTO Rear | 540/540E rpm standard; 1000 rpm optional | 540/1000 rpm (standard, interchangeable) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II (convertible to I) | Category II |
|---|
| Hitch Lift Capacity | 5,305 lb standard; 6,114 lb optional | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 5,159 lb standard; 5,954 lb optional | 4,123 lb (standard); 6,938 lb (with 2 aux rams, optional) |
|---|
| Lift Control Type | Mechanical or electrohydraulic; lower-link draft sensing | 12x12: mechanical draft control; Dual Command: electronic draft control |
|---|
|
|---|
| Transmission Type | PowrReverser 16F/16R (base); optional 32F/16R PowrReverser Hi-Lo; PowrQuad PLUS 16F/16R and Powr8 32F/16R also offered | 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (all available); column-mounted electronic power shuttle |
|---|
| No. of Speeds | 16F/16R standard (PowrReverser); 32F/16R optional (PowrReverser Hi-Lo); 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) | 12x12, 20x20 with creeper, or 24x24 Dual Command (all available) |
|---|
| Max Travel Speed (Forward) | 16F/16R PowrReverser, top gear (D-4), 40K config: 21.72 mph (480/70R28 Mitas rear tires, 2200 rpm) | 25 mph |
|---|
| Max Travel Speed (Reverse) | 16F/16R PowrReverser, top gear (D-4), 40K config: 23.94 mph (480/70R28 Mitas rear tires, 2200 rpm) | Not Published |
|---|
| Clutch | Wet | Not Published |
|---|
| Differential Lock & Limited Slip Options | Electro-hydraulic rear differential lock, engage on the go | Electrohydraulic differential lock |
|---|
|
|---|
| Frame Type | Cast iron mid-frame | Not Published |
|---|
| Steering | Not Published | Not Published |
|---|
| Brakes | Not Published | Not Published |
|---|
| Seat Suspension & Adjustability | OOS: isolated mechanical seat (fore/aft, weight, and lumbar adjustment); Cab: mechanical suspension seat standard, air suspension seat optional; adjustable weight range 88-330 lb | Air-suspension cloth seat |
|---|
| Front Axle Type | MFWD | 4WD heavy-duty, class 1.5 front axle (standard) |
|---|
| Front Axle Rating | 6,613 lb (MFWD, max permissible front axle load) | Not Published |
|---|
| Drawbar Capacity | Standard drawbar: 2,756 lb; 2,425 lb; 2,205 lb. Heavy-duty drawbar: 3,197 lb; 2,646 lb | Not Published |
|---|
|
|---|
| Overall Width | Cab, with fender extension: 85.6 in; Cab, without fender extension: 74 in; OOS, with fender extension: 69.1 in; OOS, without fender extension: 51.7 in | 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) |
|---|
| Wheelbase | 92.5 in | 92.5 in |
|---|
| Ground Clearance | Not Published | Not Published |
|---|
| Min. Turn Radius without Brakes | Not Published | Not Published |
|---|
| Height to Top of ROPS | 102.1 in | Not Published |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 102.9 in | 103.6 in |
|---|
| Overall Length | 149.5 in | 158.2 in |
|---|
|
|---|
| Tractor Weight (Base) | MFWD, OOS: 8,765 lb; MFWD, Cab: 9,185 lb (shipping weight, less weights; 2WD not offered) | 10,240 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Not Published | 420/85R38 rear (reference tire for weight and dimensions); rear tires as large as R38 available |
|---|
| R1 Agricultural - Front | 12.4R24 (320/85R24) R1W Radial | Not Published |
|---|
| R1 Agricultural - Rear | 18.4R30 (460/85R30) R1W Radial | Not Published |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | Not Published | Skid-steer-style or Euro-style quick attach faceplate (available, 650LU and 655LU) |
|---|
| Loader Model | 540M NSL; 540M SL; 540R NSL; 540R SL; H310 NSL (MFWD required for H310) | 650LU (NSL); 655LU (MSL) |
|---|
| Loader Lift Height | 540M NSL: 138 in; 540M SL: 138 in; 540R NSL: 141 in; 540R SL: 141 in; H310 NSL: 149 in | 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) |
|---|
| Loader Lift Capacity (Full Height) | 540M NSL: 3,674 lb; 540M SL: 3,058 lb; 540R NSL: 4,246 lb; 540R SL: 3,395 lb; H310 NSL: 4,644 lb (measured at pivot) | 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) |
|---|
| Loader Breakout Force | 540M NSL: 6,686 lbf; 540M SL: 5,513 lbf; 540R NSL: 4,945 lbf; 540R SL: 5,291 lbf; H310 NSL: 6,767 lbf (measured at pivot) | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
