▶ EngineEngine Manufacturer John Deere FPT Engine Model PowerTech 4045 EWL NEF Engine Type Diesel, turbocharged with intercooler, 4-valve HPCR 4-cylinder, 16-valve, turbocharged, air-to-air intercooled diesel with high-pressure common rail No. of Cylinders 4 4 Displacement 276 in³ 274 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 130 hp 130 hp PTO Power 115 hp 112 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Not Published Air Cleaner Dry type air cleaner with safety (secondary) element Not Published Fuel System High Pressure Common Rail (HPCR) electronic fuel injection, 4-valve High-pressure common rail fuel injection Alternator 120 A, 12 V 120 A ▶ HydraulicsPump Type Tandem gear pump Fixed displacement pumps (steering, implement, auxiliary) with combining/diverter valve Implement Flow 18.4 gpm 19 gpm (combined implement and auxiliary pump flow) Steering Flow 6.3 gpm 9 gpm Total Hydraulic Flow 25.6 gpm 28 gpm Overall Hydraulic Pump Flow 25.6 gpm 28 gpm Hydraulic System Type Open center Fixed displacement pumps with combining/diverter valve; deluxe closed-center rear remote valves with flow control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (rear); 2 (mid) Not Published No. of Optional Remote Valves Up to 3 total (rear); up to 3 total (mid) Not Published ▶ Fluid CapacityFuel Tank Capacity 42.4 gal (Standard Cab) 57.5 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent rear PTO, electro-hydraulic clutch Not Published PTO Rear 540 rpm standard; 540/1000 rpm optional 540/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (convertible to I) Category II (flex link ends) Hitch Lift Capacity 6,975 lb standard; 7,868 lb optional 3,735 lb (ASAE); 5,499 lb with one optional auxiliary lift cylinder; 7,326 lb with two Hitch Lift Capacity (at 24”) 6,975 lb standard; 7,868 lb optional Not Published Lift Control Type Electrohydraulic Not Published ▶ Transmission & DrivetrainTransmission Type PowrQuad PLUS 16F/16R or Powr8 32F/16R (cab only) 8x8 synchronized power shuttle (hydraulic, left-hand) standard; 16x8 Dual Power synchronized hydraulic shuttle with Hi-Lo (premium); 10:1 creeper optional No. of Speeds 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) 8F/8R (base); 16F/8R (premium Dual Power with Hi-Lo) Max Travel Speed (Forward) 24.9 mph; PowrQuad PLUS 16F/16R (standard) or Powr8 32F/16R (optional) 19 mph or 25 mph (25 mph 4WD only) Max Travel Speed (Reverse) Not Published Not Published Clutch Electro-hydraulic Not Published Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Cast iron mid-frame design Not Published Steering Power steering Not Published Brakes Hydraulic wet disk brakes, self-equalizing and self-adjusting Not Published Seat Suspension & Adjustability Mechanical suspension seat standard; air suspension seat optional; premium air suspension seat (heated, low-frequency) optional Mechanical suspension seat standard; deluxe air suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab) Front Axle Type MFWD Heavy-duty front axle, 2WD or 4WD (both optional, cab only) Front Axle Rating Not Published Not Published Drawbar Capacity 3,197 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 184.7 in (4WD, with front weights); 184.5 in (2WD, with front weights) Overall Width Not Published Not Published Wheelbase 92.5 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 110.2 in ▶ WeightTractor Weight (Base) 9,185 lb 11,200 lb (shipping, 4WD, cab, flange axle); 12,192 lb (4WD, cab, bar axle); 9,921 lb (2WD, cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural 18.4-38 R1 rear with 14.9-28 R1 front (4WD) or 10.00-16 front (2WD) R1 Agricultural - Front 12.4R24 14.9-28 (4WD); 10.00-16 (2WD) R1 Agricultural - Rear 18.4R30 18.4-38 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 in, 12PR R4 Bias Not Published R4 Industrial - Rear 19.5L-24 in, 10PR R4 Bias Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid steer (SSL) or Euro style attachment couplers Loader Model 520M (4WD only); 540M; 540R; 600M 4WD: 830LA (NSL), 835LA (MSL); 2WD: 810LA (NSL) Loader Lift Height 520M: NSL/MSL 130-132 in; 540M: NSL 137-141 in, MSL 138-141 in; 540R: 141.85 in; 600M: NSL 148.8-152.8 in, MSL 148-153 in 830LA: 150.0 in; 835LA: 150.0 in; 810LA (2WD): 144.0 in (to pivot pin) Loader Lift Capacity (Full Height) 520M (4WD): NSL 3,334.9-3,611.6 lb, MSL 2,460.1-2,661 lb; 540M: NSL 2,394-2,666 lb, MSL 3,117.3-3,309.1 lb; 540R: 3,406 lb; 600M: NSL 3,104-3,236 lb, MSL 3,891-4,085 lb 830LA: 2,557 lb; 835LA: 3,813 lb; 810LA (2WD): 2,094 lb (to maximum height, measured 31.5 in forward of the pivot pin) Loader Breakout Force Not Published 830LA: 3,681 lb; 835LA: 3,968 lb; 810LA (2WD): 3,020 lb (measured 31.5 in forward of the pivot pin) ▶ WarrantyWarranty Length & Coverage 24 Months or 2000 Hours, Whichever Comes First (whole-machine, standard Agricultural Equipment tractor term) Not Published
