| Engine Manufacturer | John Deere | Kubota |
|---|
| Engine Model | CD3029DLV50 | V2403-CR-TE4-GL1 |
|---|
| Engine Type | 3-cylinder, naturally aspirated, direct injection, liquid-cooled diesel | Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged |
|---|
| No. of Cylinders | 3 | 4 |
|---|
| Displacement | 179 in³ | 148.5 in³ |
|---|
| Rated Engine Speed | 2400 rpm | 2700 rpm |
|---|
| Engine Power (Gross) | 53 hp | 52 hp |
|---|
| PTO Power | 45 hp | 44 hp |
|---|
| Engine Emissions Constraints | Not Published | Tier 4 |
|---|
| Cooling System Type | Liquid-cooled | Liquid-cooled |
|---|
| Air Cleaner | Dry type with safety element | Dry paper, dual element |
|---|
| Fuel System | Direct injection, rotary injection pump, electric shutoff | Electronic Common Rail System (CRS) |
|---|
| Alternator | 40 A | 45 A, 12 V |
|---|
|
|---|
| Pump Type | Tandem gear pump | Tandem pump - gear type |
|---|
| Implement Flow | 11.4 gpm | 9.8 gpm |
|---|
| Steering Flow | 6.8 gpm | 4.9 gpm |
|---|
| Total Hydraulic Flow | 18.2 gpm | 14.7 gpm |
|---|
| Overall Hydraulic Pump Flow | 18.2 gpm | 14.7 gpm |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | 11.4 gpm | Not Published |
|---|
| No. of Standard Remote Valves | Not Published | Not Published |
|---|
| No. of Optional Remote Valves | Not Published | Optional, up to 3: double-acting valve or float detent valve, any position |
|---|
|
|---|
| Fuel Tank Capacity | 18 gal (open station); 22 gal (cab) | 13.5 gal |
|---|
| Coolant Capacity | 10 qt | 8.7 qt |
|---|
| Crankcase Capacity | 9 qt | 9.9 qt |
|---|
| Transmission / Hydraulic System Capacity | 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) | 11.9 gal |
|---|
| Front Axle Fluid Capacity | 5.3 qt (MFWD differential housing); 0.63 qt (each wheel hub) | Not Published |
|---|
|
|---|
| PTO Type | Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever-operated clutch | Live independent (hydraulic clutch) |
|---|
| PTO Rear | 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) | 540 rpm @ 2550 engine rpm |
|---|
| Mid-PTO Availability | Not Published | Optional |
|---|
| Category, 3-Point Hitch | Category I and II | SAE Category I & II |
|---|
| Hitch Lift Capacity | Not Published | 3,858 lb |
|---|
| Hitch Lift Capacity (at 24”) | 3,374 lb | 2,976 lb |
|---|
| Lift Control Type | Position and depth control, top link draft sensing | Position control |
|---|
|
|---|
| Transmission Type | CollarShift standard; SyncShuttle optional; PowrReverser optional | Glide Shift |
|---|
| No. of Speeds | 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) | 12Fx8R |
|---|
| Max Travel Speed (Forward) | 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) | 16.5 mph |
|---|
| Max Travel Speed (Reverse) | 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) | 15.8 mph |
|---|
| Clutch | Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) | Dry type single stage |
|---|
| Differential Lock & Limited Slip Options | Not Published | Rear differential lock, standard |
|---|
|
|---|
| Frame Type | Two-post ROPS; cab optional; two-wheel drive or MFWD | Not Published |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering |
|---|
| Brakes | Wet disk, self-equalizing, self-adjusting | Wet disc type, mechanically activated |
|---|
| Seat Suspension & Adjustability | Not Published | Suspension seat with swivel function |
|---|
| Front Axle Type | Two-wheel drive or mechanical front wheel drive (MFWD) | 4WD: Bevel gear front axle, non-adjustable tread spacing |
|---|
| Front Axle Rating | 2,720 to 4,700 lb (2WD, by front tire, no loader); 2,760 to 4,620 lb (MFWD, by front tire, without loader) | Not Published |
|---|
| Drawbar Capacity | 1,675 lb (maximum permissible static vertical load, drawbar fully extended) | 1,433 lb |
|---|
|
|---|
| Overall Width | 94.6 in (maximum) | 67.3 in |
|---|
| Wheelbase | 80.7 in | 75.4 in |
|---|
| Ground Clearance | 19 in (2WD front axle); 17 in (MFWD front axle); 14.3 in (drawbar) | 15.4 in |
|---|
| Min. Turn Radius without Brakes | 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) | 9.2 ft (with brake applied) |
|---|
| Height to Top of ROPS | 88.7 in (extended) | 98.0 in |
|---|
| Height to Top of ROPS (folded) | 76.7 in | Not Published |
|---|
| Height to Top of Cab Model | 97 in | Not Published |
|---|
| Overall Length | 122.6 in (2WD); 125.9 in (MFWD) (less drawbar and front weights) (without 3-point hitch) | 135.0 in (with 3-point hitch) |
|---|
|
|---|
| Tractor Weight (Base) | 4,370 lb (2WD); 4,730 lb (MFWD); add 1,000 lb with cab | 3,979 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 18.4-16.1 | Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470) |
|---|
| R1 Agricultural - Front | 8.3-24 (MFWD) | 9.5-16 |
|---|
| R1 Agricultural - Rear | 13.6-28 | 14.9-26; 13.6-28 |
|---|
| R3 Turf - Front | Not Published | 29X12.50-15 |
|---|
| R3 Turf - Rear | Not Published | 44X18-20 |
|---|
| R4 Industrial - Front | Not Published | 10-16.5 |
|---|
| R4 Industrial - Rear | Not Published | 17.5L-24 |
|---|
|
|---|
| Quick Attach Loader System | Not Published | 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) |
|---|
| Loader Model | 521; 541; 541 self-leveling; 542; 542 self-leveling | LA1055 |
|---|
| Loader Lift Height | 521: 122 in; 541: 126 in; 541 self-leveling: 130 in | 112.7 in (at pivot pin) |
|---|
| Loader Lift Capacity (Full Height) | 521: 2,500 lb; 541: 2,500 lb; 541 self-leveling: 2,800 lb (full at pin) | 2,361 lb (at pivot pin) |
|---|
| Loader Breakout Force | 521: 3,485 lbf; 541: 3,484 lbf; 541 self-leveling: 4,125 lbf (at pin) | 3,171 lbf |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
