| Engine Manufacturer | John Deere | FPT |
|---|
| Engine Model | 3029T | S8000 |
|---|
| Engine Type | 3-cylinder liquid-cooled diesel, turbocharged, direct injection | Turbocharged 3-cylinder diesel |
|---|
| No. of Cylinders | 3 | 3 |
|---|
| Displacement | 179 in³ | 179 in³ |
|---|
| Rated Engine Speed | 2400 rpm | 2300 rpm |
|---|
| Engine Power (Gross) | 64 hp | 64 hp |
|---|
| PTO Power | 55 hp | 50 hp |
|---|
| Engine Emissions Constraints | Not Published | Tier 4 |
|---|
| Cooling System Type | Liquid-cooled | Not Published |
|---|
| Air Cleaner | Dry type with safety element | PowerCore dry air cleaner |
|---|
| Fuel System | Direct injection, rotary injection pump with electric shutoff | Bosch electronic high-pressure common rail |
|---|
| Alternator | 40 A | 120 A |
|---|
|
|---|
| Pump Type | Tandem gear pump | Dual gear pumps |
|---|
| Implement Flow | 11.4 gpm | 12.6 gpm |
|---|
| Steering Flow | 6.8 gpm | 7.6 gpm |
|---|
| Total Hydraulic Flow | 18.2 gpm | 20.2 gpm |
|---|
| Overall Hydraulic Pump Flow | 18.2 gpm | 20.2 gpm |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | 11.4 gpm | Not Published |
|---|
| No. of Standard Remote Valves | Not Published | 2 |
|---|
| No. of Optional Remote Valves | Not Published | 1 |
|---|
|
|---|
| Fuel Tank Capacity | 18 gal (open station); 23 gal (cab) | 21.7 gal |
|---|
| Coolant Capacity | 10 qt | Not Published |
|---|
| Crankcase Capacity | 9 qt | Not Published |
|---|
| Transmission / Hydraulic System Capacity | 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) | Not Published |
|---|
| Front Axle Fluid Capacity | 5.2 qt (MFWD axle housing); 0.6 qt (each wheel hub); 5.7 qt (MFWD assembly) | Not Published |
|---|
|
|---|
| PTO Type | Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever operated clutch | Fully independent, hydraulic wet clutch |
|---|
| PTO Rear | 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) | 540 rpm (540/540E optional) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category I and II | Category I/II |
|---|
| Hitch Lift Capacity | Not Published | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 3374 lb | 3,500 lb (4,000 lb with optional auxiliary lift ram) |
|---|
| Lift Control Type | Position and depth control, top link draft sensing | Lift-O-Matic with mechanical draft control (upper-link draft sensing) |
|---|
|
|---|
| Transmission Type | CollarShift standard; SyncShuttle optional; PowrReverser optional | 12x12 hydraulic power shuttle |
|---|
| No. of Speeds | 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) | 12F/12R |
|---|
| Max Travel Speed (Forward) | 15.62 mph (CollarShift and SyncShuttle, gear C-3); 15.52 mph (PowrReverser, gear C-4) | 25 mph |
|---|
| Max Travel Speed (Reverse) | 13.33 mph (CollarShift and SyncShuttle, gear C-R); 17.95 mph (PowrReverser, gear C-4 reverse) | Not Published |
|---|
| Clutch | Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) | 11 in single dry disc |
|---|
| Differential Lock & Limited Slip Options | Not Published | Mechanically engaged rear differential lock; limited-slip 4WD front axle with electro-hydraulic push-button engagement |
|---|
|
|---|
| Frame Type | Two-post ROPS; cab optional; two-wheel drive or MFWD | Not Published |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering |
|---|
| Brakes | Wet disk, self-equalizing, self-adjusting | Hydraulic-assist wet brakes |
|---|
| Seat Suspension & Adjustability | Not Published | Cloth air-suspension seat with fold-back instructor seat |
|---|
| Front Axle Type | Two-wheel drive or mechanical front wheel drive (MFWD) | 4WD (MFD) limited-slip front axle, electro-hydraulic engagement |
|---|
| Front Axle Rating | 2720 to 4700 lb (2WD, by front tire, no loader); 2760 to 4620 lb (MFWD, by front tire, without loader) | 6,500 lb dynamic capacity |
|---|
| Drawbar Capacity | 1675 lb | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 123.6 in (2WD); 128.1 in (MFWD) (w/o 3P, less hitch, drawbar and front weights) (without 3-point hitch) | 154.1 in |
|---|
| Overall Width | 66.7 in | Not Published |
|---|
| Wheelbase | 80.7 in | 83.6 in |
|---|
| Ground Clearance | 18.1 in (2WD front axle); 14.8 in (MFWD front axle); 15.8 in (2WD drawbar); 16.3 in (MFWD drawbar) | Not Published |
|---|
| Min. Turn Radius without Brakes | 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) | Not Published |
|---|
| Height to Top of ROPS | 88.7 in | Not Published |
|---|
| Height to Top of ROPS (folded) | 75.5 in | Not Published |
|---|
| Height to Top of Cab Model | 97.9 in | 100.2 in |
|---|
|
|---|
| Tractor Weight (Base) | 4350 lb (2WD); 4750 lb (MFWD); add approximately 1000 lb with cab | 6,800 lb (cab, 4WD) |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 16.9-30, 18.4-16.1 | R1 agricultural (11.2x24 / 16.9x30 standard, R1W radials optional), R4 industrial (12.5/80-18 / 19.5L-24) |
|---|
| R1 Agricultural - Front | 7.50-16 (2WD); 9.5-24 (MFWD) | 11.2x24 R1, 6 ply |
|---|
| R1 Agricultural - Rear | 14.9-28 | 16.9x30 R1, 6 ply |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | 12.5/80-18 R4, 10 ply |
|---|
| R4 Industrial - Rear | Not Published | 19.5L-24 R4, 10 ply |
|---|
|
|---|
| Quick Attach Loader System | Not Published | 72 in bucket with SSL (skid steer) or Euro-style quick attach |
|---|
| Loader Model | 521; 541; 541 self-leveling | 550LU (non self-leveling); 555LU (mechanical self-leveling) |
|---|
| Loader Lift Height | 521: 122 in; 541: 126 in; 541 self-leveling: 130 in | 550LU: 131.3 in; 555LU: 130.0 in (at pivot pin) |
|---|
| Loader Lift Capacity (Full Height) | 521: 2500 lb; 541: 2500 lb; 541 self-leveling: 2800 lb (full at pin) | 550LU: 2,425 lb; 555LU: 3,153 lb (at max height, 31.5 in ahead of bucket pivot pin) |
|---|
| Loader Breakout Force | 521: 3485 lbf; 541: 3484 lbf; 541 self-leveling: 4125 lbf (at pin) | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
