▶ EngineEngine Manufacturer John Deere KIOTI (Daedong) Engine Model PowerTech EWL 4J243TA-TP5B Engine Type Diesel, single turbocharger with wastegate In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4J243TA-TP5B) No. of Cylinders 4 4 Displacement 275 in³ 233.9 in³ Rated Engine Speed 2100 rpm 2200 rpm Engine Power (Gross) 120 hp 115.3 hp PTO Power 94 hp 83.9 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled (Cool-Gard II coolant) Water-cooled Air Cleaner Dry air cleaner, primary and secondary elements Dry element with evacuator valve Fuel System Not Published Common Rail Direct Injection (CRDI) Alternator 120 A, 14 V Not Published ▶ HydraulicsPump Type Not Published Gear Implement Flow Not Published 19.8 gpm Steering Flow Not Published 12.2 gpm Total Hydraulic Flow 21 gpm standard; 30 gpm optional 32 gpm Overall Hydraulic Pump Flow 21 gpm standard; 30 gpm optional 32 gpm Hydraulic System Type Pressure Compensated (PC) standard; Pressure & Flow Compensated (PFC) with Load Sensing optional Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (ISO couplers, rear) 3 No. of Optional Remote Valves Up to 4 total (ISO couplers, rear) 1 ▶ Fluid CapacityFuel Tank Capacity 46.2 gal 47.6 gal Coolant Capacity 5.3 gal 4.7 gal Crankcase Capacity 4.5 gal 3.9 gal Transmission / Hydraulic System Capacity 15.8 gal (PowrQuad Plus/AutoQuad Plus) 20.34 gal Front Axle Fluid Capacity 2-piece front axle (types 730/733/735): axle housing 1.69 gal (suspended axle) or 1.43 gal (axle without suspension); final drive per side 0.21 gal (without brake), 0.37 gal (with brake). 3-piece front axle version 1 (type 740 M40): axle housing 1.90 gal; final drive per side 0.21 gal (without brake), 0.37 gal (with brake). 3-piece front axle version 2 (types 730/733/735): axle housing 1.7 gal; final drive per side 0.21 gal (without brake), 0.47 gal (with brake) 2.6 gal ▶ PTO & HitchPTO Type Electro-hydraulically operated, oil cooled, multi-disc; standard 1.5 in 540/1000 reversible shaft Independent PTO Rear 540 rpm @ 1977 engine rpm; 1000 rpm @ 1972 engine rpm 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/IIIN (SAE designation) Category II Hitch Lift Capacity 8,267.3 lb standard; 11,023.1 lb optional 8,079 lb Hitch Lift Capacity (at 24”) 5,582 lb standard; 7,432 lb optional, measured 24 in behind the coupling points (6110M and 6120M) 8,002 lb Lift Control Type Not Published Electronic control ▶ Transmission & DrivetrainTransmission Type Standard John Deere 24 Speed PowrQuad Plus 24.9 mph; optional 16 Speed PowrQuad Plus, 24 Speed AutoQuad Plus, 24 Speed CommandQuad Plus, AutoPowr/IVT, Creeper Power Shuttle w/ Hi-Lo Shift No. of Speeds 24F/24R (standard PowrQuad Plus) 24 forward / 24 reverse Max Travel Speed (Forward) 24.9 mph 23.83 mph Max Travel Speed (Reverse) 25 mph; standard 24F/24R PowrQuad PLUS 23.67 mph Clutch Not Published Wet Multi Disc Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock (standard); front limited-slip differential ▶ Chassis, Steering & ControlsFrame Type Full frame design Not Published Steering Power steering Hydrostatic Power Steering Brakes Hydraulic wet disc brakes Wet Multi Disc Seat Suspension & Adjustability Economy seat with mechanical suspension standard; standard seat with air suspension optional Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Front Axle Type MFWD standard; 2WD optional; Triple Link Suspension (TLS) MFWD available (hydro-pneumatic, self-levelling, 3.9 in range), also with brakes 4WD with outboard planetary final drives and limited-slip differential Front Axle Rating 9,655 lb maximum permissible front axle load, MFWD, normal operation up to 25 mph Not Published Drawbar Capacity Standard duty: 4,960 lb, 3,085 lb, 2,645 lb; Heavy-duty: 6,610 lb, 3,960 lb, 3,520 lb (field operation, CAT 2) Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 176.6 in (basic 242.5 lb front weight, cab + MFWD, to draft link in horizontal position) 170.8 in Overall Width 100.4 in (maximum width for road travel) 88.6 in Wheelbase 94.5 in 94.9 in Ground Clearance Front-wheel drive axle: 11.3-25.1 in depending on front tire SRI; differential housing with drawbar: 13.7-23.5 in depending on rear tire SRI (cab + MFWD) 18.9 in Min. Turn Radius without Brakes 14 ft (4.36 m) (6110M & 6120M) 12.7 ft (with brake applied) Height to Top of ROPS 105.2-115.0 in depending on rear tire SRI (ground to extended ROPS, without beacon light, open operator's station) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 105.4-115.3 in depending on rear tire SRI (ground to cab roof, without beacon light) 111.9 in ▶ WeightTractor Weight (Base) 12,522 lb 10,230 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) R1 Agricultural - Front Not Published 13.6-24 R1 Agricultural - Rear Not Published 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Automatic mast latch (self-correcting floating system, automatic implement latch) KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Loader Model 600R; 620R KL1155 Loader Lift Height Not Published KL1155: 150.6 in (to pivot pin) Loader Lift Capacity (Full Height) Not Published KL1155: 4,216 lb (at pivot pins) Loader Breakout Force Not Published KL1155: 8,554 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage 24 total month / 2,000 total hour factory basic limited warranty Tractors (Non-Commercial): 24 months parts & labor, unlimited hours, 0% deductible; powertrain (engine and driveline): 48 months unlimited hours on HX Series
