▶ EngineEngine Manufacturer John Deere AGCO Power Engine Model PowerTech EWL Not Published Engine Type Diesel, single turbocharger with wastegate 4-cylinder, turbocharged intercooled diesel No. of Cylinders 4 4 Displacement 275 in³ 268.5 in³ Rated Engine Speed 2100 rpm 2200 rpm Engine Power (Gross) 120 hp 115 hp PTO Power 94 hp 90 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled (Cool-Gard II coolant) Liquid cooled Air Cleaner Dry air cleaner, primary and secondary elements Not Published Fuel System Not Published High-pressure common-rail direct fuel injection Alternator 120 A, 14 V Platform: 80 A; Cab: 120 A ▶ HydraulicsPump Type Not Published Engine-driven gear pump Implement Flow Not Published 15.3 gpm Steering Flow Not Published 8.5 gpm Total Hydraulic Flow 21 gpm standard; 30 gpm optional 23.8 gpm (15.3 + 8.5, computed) Overall Hydraulic Pump Flow 21 gpm standard; 30 gpm optional 23.8 gpm (15.3 + 8.5, computed) Hydraulic System Type Pressure Compensated (PC) standard; Pressure & Flow Compensated (PFC) with Load Sensing optional Open center Rear Remote Hydraulic Flow Not Published 26 gpm No. of Standard Remote Valves 2 (ISO couplers, rear) 2 No. of Optional Remote Valves Up to 4 total (ISO couplers, rear) 3 ▶ Fluid CapacityFuel Tank Capacity 46.2 gal 52.8 gal Coolant Capacity 5.3 gal Not Published Crankcase Capacity 4.5 gal Not Published Transmission / Hydraulic System Capacity 15.8 gal (PowrQuad Plus/AutoQuad Plus) Not Published Front Axle Fluid Capacity 2-piece front axle (types 730/733/735): axle housing 1.69 gal (suspended axle) or 1.43 gal (axle without suspension); final drive per side 0.21 gal (without brake), 0.37 gal (with brake). 3-piece front axle version 1 (type 740 M40): axle housing 1.90 gal; final drive per side 0.21 gal (without brake), 0.37 gal (with brake). 3-piece front axle version 2 (types 730/733/735): axle housing 1.7 gal; final drive per side 0.21 gal (without brake), 0.47 gal (with brake) Not Published ▶ PTO & HitchPTO Type Electro-hydraulically operated, oil cooled, multi-disc; standard 1.5 in 540/1000 reversible shaft Independent, electrohydraulic engagement PTO Rear 540 rpm @ 1977 engine rpm; 1000 rpm @ 1972 engine rpm 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/IIIN (SAE designation) Category II Hitch Lift Capacity 8,267.3 lb standard; 11,023.1 lb optional 9,480 lb Hitch Lift Capacity (at 24”) 5,582 lb standard; 7,432 lb optional, measured 24 in behind the coupling points (6110M and 6120M) 7,500 lb Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type Standard John Deere 24 Speed PowrQuad Plus 24.9 mph; optional 16 Speed PowrQuad Plus, 24 Speed AutoQuad Plus, 24 Speed CommandQuad Plus, AutoPowr/IVT, Creeper 12 x 12: 2-range power shuttle with electrohydraulic shuttle lever; Dyna-4: semi-powershift No. of Speeds 24F/24R (standard PowrQuad Plus) 12 x 12: 12F/12R; Dyna-4: 16F/16R Max Travel Speed (Forward) 24.9 mph Not Published Max Travel Speed (Reverse) 25 mph; standard 24F/24R PowrQuad PLUS Not Published Clutch Not Published Multidisk wet clutch with electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Not Published Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch ▶ Chassis, Steering & ControlsFrame Type Full frame design Not Published Steering Power steering Power steering Brakes Hydraulic wet disc brakes Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Economy seat with mechanical suspension standard; standard seat with air suspension optional ROPS: mechanical spring suspension with armrests; Cab: air-ride swivel seat Front Axle Type MFWD standard; 2WD optional; Triple Link Suspension (TLS) MFWD available (hydro-pneumatic, self-levelling, 3.9 in range), also with brakes Heavy-duty 4WD front axle Front Axle Rating 9,655 lb maximum permissible front axle load, MFWD, normal operation up to 25 mph Not Published Drawbar Capacity Standard duty: 4,960 lb, 3,085 lb, 2,645 lb; Heavy-duty: 6,610 lb, 3,960 lb, 3,520 lb (field operation, CAT 2) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 176.6 in (basic 242.5 lb front weight, cab + MFWD, to draft link in horizontal position) 165.6 in Overall Width 100.4 in (maximum width for road travel) Dyna-4 cab: 74.9 in; 12 x 12 cab: 79.8 in Wheelbase 94.5 in 95.7 in Ground Clearance Front-wheel drive axle: 11.3-25.1 in depending on front tire SRI; differential housing with drawbar: 13.7-23.5 in depending on rear tire SRI (cab + MFWD) 20.3 in Min. Turn Radius without Brakes 14 ft (4.36 m) (6110M & 6120M) Not Published Height to Top of ROPS 105.2-115.0 in depending on rear tire SRI (ground to extended ROPS, without beacon light, open operator's station) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 105.4-115.3 in depending on rear tire SRI (ground to cab roof, without beacon light) 105.7 in ▶ WeightTractor Weight (Base) 12,522 lb ROPS: 9,195 lb; Cab: 10,011 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Automatic mast latch (self-correcting floating system, automatic implement latch) Not Published Loader Model 600R; 620R Not Published Loader Lift Height Not Published Not Published Loader Lift Capacity (Full Height) Not Published Not Published Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage 24 total month / 2,000 total hour factory basic limited warranty Not Published
