Up to 4 rear remote valves (deluxe, with diverter); up to 3 mid-mount valves
Fuel Tank Capacity
46.2 gal
47.5 gal
Coolant Capacity
5.3 gal
Not Published
Crankcase Capacity
4.5 gal
Not Published
Transmission / Hydraulic System Capacity
15.8 gal (PowrQuad Plus/AutoQuad Plus)
Not Published
Front Axle Fluid Capacity
2-piece front axle (types 730/733/735): axle housing 1.69 gal (suspended axle) or 1.43 gal (axle without suspension); final drive per side 0.21 gal (without brake), 0.37 gal (with brake). 3-piece front axle version 1 (type 740 M40): axle housing 1.90 gal; final drive per side 0.21 gal (without brake), 0.37 gal (with brake). 3-piece front axle version 2 (types 730/733/735): axle housing 1.7 gal; final drive per side 0.21 gal (without brake), 0.47 gal (with brake)
Not Published
PTO Type
Electro-hydraulically operated, oil cooled, multi-disc; standard 1.5 in 540/1000 reversible shaft
Fully independent direct-drive PTO with electro-hydraulic wet clutch and Soft Start
Terralock Auto Diff and Auto 4WD (standard); electro-hydraulic front and rear differential lock
Frame Type
Full frame design
Not Published
Steering
Power steering
Power steering
Brakes
Hydraulic wet disc brakes
Hydraulic wet disc
Seat Suspension & Adjustability
Economy seat with mechanical suspension standard; standard seat with air suspension optional
Comfort seat, low-frequency suspension, cloth (standard); Dynamic Comfort or Auto Comfort seats with heating and active ventilation (optional); instructor seat optional
Front Axle Type
MFWD standard; 2WD optional; Triple Link Suspension (TLS) MFWD available (hydro-pneumatic, self-levelling, 3.9 in range), also with brakes
Class 1.75 heavy-duty 4WD front axle (standard); Terraglide front axle suspension (optional)
Front Axle Rating
9,655 lb maximum permissible front axle load, MFWD, normal operation up to 25 mph
176.6 in (basic 242.5 lb front weight, cab + MFWD, to draft link in horizontal position)
173 in (max, weight carrier to rear linkage)
Overall Width
100.4 in (maximum width for road travel)
74 in (narrow); 90 in (standard)
Wheelbase
94.5 in
98 in
Ground Clearance
Front-wheel drive axle: 11.3-25.1 in depending on front tire SRI; differential housing with drawbar: 13.7-23.5 in depending on rear tire SRI (cab + MFWD)
Not Published
Min. Turn Radius without Brakes
14 ft (4.36 m) (6110M & 6120M)
182 in (4WD / Terraglide suspended front axle; brake use not stated)
Height to Top of ROPS
105.2-115.0 in depending on rear tire SRI (ground to extended ROPS, without beacon light, open operator's station)
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
105.4-115.3 in depending on rear tire SRI (ground to cab roof, without beacon light)
