▶ EngineEngine Manufacturer John Deere FPT Engine Model PowerTech EWL F36 Engine Type Diesel, single turbocharger with wastegate 4-cylinder No. of Cylinders 4 4 Displacement 275 in³ Not Published Rated Engine Speed 2100 rpm Not Published Engine Power (Gross) 120 hp 117 hp PTO Power 94 hp 99 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled (Cool-Gard II coolant) Not Published Air Cleaner Dry air cleaner, primary and secondary elements Not Published Fuel System Not Published Not Published Alternator 120 A, 14 V Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow Not Published Not Published Steering Flow Not Published Not Published Total Hydraulic Flow 21 gpm standard; 30 gpm optional 21 gpm Overall Hydraulic Pump Flow 21 gpm standard; 30 gpm optional Not Published Hydraulic System Type Pressure Compensated (PC) standard; Pressure & Flow Compensated (PFC) with Load Sensing optional Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (ISO couplers, rear) Not Published No. of Optional Remote Valves Up to 4 total (ISO couplers, rear) Not Published ▶ Fluid CapacityFuel Tank Capacity 46.2 gal 34.3 gal Coolant Capacity 5.3 gal Not Published Crankcase Capacity 4.5 gal Not Published Transmission / Hydraulic System Capacity 15.8 gal (PowrQuad Plus/AutoQuad Plus) Not Published Front Axle Fluid Capacity 2-piece front axle (types 730/733/735): axle housing 1.69 gal (suspended axle) or 1.43 gal (axle without suspension); final drive per side 0.21 gal (without brake), 0.37 gal (with brake). 3-piece front axle version 1 (type 740 M40): axle housing 1.90 gal; final drive per side 0.21 gal (without brake), 0.37 gal (with brake). 3-piece front axle version 2 (types 730/733/735): axle housing 1.7 gal; final drive per side 0.21 gal (without brake), 0.47 gal (with brake) Not Published ▶ PTO & HitchPTO Type Electro-hydraulically operated, oil cooled, multi-disc; standard 1.5 in 540/1000 reversible shaft Not Published PTO Rear 540 rpm @ 1977 engine rpm; 1000 rpm @ 1972 engine rpm Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/IIIN (SAE designation) Not Published Hitch Lift Capacity 8,267.3 lb standard; 11,023.1 lb optional Not Published Hitch Lift Capacity (at 24”) 5,582 lb standard; 7,432 lb optional, measured 24 in behind the coupling points (6110M and 6120M) Not Published Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type Standard John Deere 24 Speed PowrQuad Plus 24.9 mph; optional 16 Speed PowrQuad Plus, 24 Speed AutoQuad Plus, 24 Speed CommandQuad Plus, AutoPowr/IVT, Creeper 12x12 electronic power shuttle No. of Speeds 24F/24R (standard PowrQuad Plus) 12 forward / 12 reverse Max Travel Speed (Forward) 24.9 mph Not Published Max Travel Speed (Reverse) 25 mph; standard 24F/24R PowrQuad PLUS Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Full frame design Not Published Steering Power steering Not Published Brakes Hydraulic wet disc brakes Not Published Seat Suspension & Adjustability Economy seat with mechanical suspension standard; standard seat with air suspension optional Air ride seat (standard); instructor seat available Front Axle Type MFWD standard; 2WD optional; Triple Link Suspension (TLS) MFWD available (hydro-pneumatic, self-levelling, 3.9 in range), also with brakes Class 1.0 HD heavy-duty front axle Front Axle Rating 9,655 lb maximum permissible front axle load, MFWD, normal operation up to 25 mph Not Published Drawbar Capacity Standard duty: 4,960 lb, 3,085 lb, 2,645 lb; Heavy-duty: 6,610 lb, 3,960 lb, 3,520 lb (field operation, CAT 2) Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 176.6 in (basic 242.5 lb front weight, cab + MFWD, to draft link in horizontal position) Not Published Overall Width 100.4 in (maximum width for road travel) Not Published Wheelbase 94.5 in Not Published Ground Clearance Front-wheel drive axle: 11.3-25.1 in depending on front tire SRI; differential housing with drawbar: 13.7-23.5 in depending on rear tire SRI (cab + MFWD) Not Published Min. Turn Radius without Brakes 14 ft (4.36 m) (6110M & 6120M) Not Published Height to Top of ROPS 105.2-115.0 in depending on rear tire SRI (ground to extended ROPS, without beacon light, open operator's station) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 105.4-115.3 in depending on rear tire SRI (ground to cab roof, without beacon light) Not Published ▶ WeightTractor Weight (Base) 12,522 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Automatic mast latch (self-correcting floating system, automatic implement latch) Not Published Loader Model 600R; 620R 630LU; 635LU Loader Lift Height 600R: 154 in 143.9 in (630LU and 635LU) Loader Lift Capacity (Full Height) 600R: 4,134 lb (at pivot, full height) 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, 31.5 in forward of the bucket pivot point) Loader Breakout Force 600R: 5,875 lb (boom breakout at pivot) Not Published ▶ WarrantyWarranty Length & Coverage 24 total month / 2,000 total hour factory basic limited warranty Not Published
