▶ EngineEngine Manufacturer KIOTI (Daedong) Kubota Engine Model 4J243TA-TP5B V3800-TI-CRS Engine Type In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4J243TA-TP5B) Common rail direct injection, liquid-cooled, 4-cylinder turbocharged and intercooled diesel No. of Cylinders 4 4 Displacement 233.9 in³ 230 in³ Rated Engine Speed 2200 rpm 2600 rpm Engine Power (Gross) 115.3 hp 114.1 hp PTO Power 83.9 hp 92 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Water-cooled Liquid-cooled, heavy duty pressurized radiator with recovery tank Air Cleaner Dry element with evacuator valve 8 in dry, dual element Fuel System Common Rail Direct Injection (CRDI) Common rail direct injection Alternator Not Published 130 A, 12 V ▶ HydraulicsPump Type Gear Gear pumps Implement Flow 19.8 gpm 18.7 gpm Steering Flow 12.2 gpm 16.0 gpm Total Hydraulic Flow 32 gpm 34.7 gpm (18.7 + 16.0, computed) Overall Hydraulic Pump Flow 32 gpm Not Published Hydraulic System Type Open Center Pressure compensated, fixed displacement Rear Remote Hydraulic Flow Not Published 18.7 gpm No. of Standard Remote Valves 3 2 (with built-in flow control) No. of Optional Remote Valves 1 3rd and 4th optional (4 max) ▶ Fluid CapacityFuel Tank Capacity 47.6 gal 50.2 gal Coolant Capacity 4.7 gal 11.3 qt Crankcase Capacity 3.9 gal 11.3 qt Transmission / Hydraulic System Capacity 20.34 gal 17.2 gal Front Axle Fluid Capacity 2.6 gal 7.2 qt (differential) plus 3.8 qt per bevel gear case ▶ PTO & HitchPTO Type Independent Live independent PTO, hydraulically operated wet clutch with PTO brake PTO Rear 540 / 540E / 1000 rpm 540/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 8,079 lb 8598 lb Hitch Lift Capacity (at 24”) 8,002 lb 6834 lb (optional 9447 lb) Lift Control Type Electronic control Electronic draft control, lower link sensing; left fender-mounted hitch switch standard ▶ Transmission & DrivetrainTransmission Type Power Shuttle w/ Hi-Lo Shift Intelli-Shift, 24F/24R (8-speed powershift main, 3-speed mechanical range with clutch button, microprocessor-controlled electro-hydraulic shuttle); 32F/32R with optional creep No. of Speeds 24 forward / 24 reverse 24F/24R (32F/32R with optional creep) Max Travel Speed (Forward) 23.83 mph 23.4 mph Max Travel Speed (Reverse) 23.67 mph 22.33 mph Clutch Wet Multi Disc Multiple wet disc, electro-hydraulically operated, 5.2 in Differential Lock & Limited Slip Options Mechanical rear differential lock (standard); front limited-slip differential Electro-hydraulic front differential lock; rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Certified ROPS cab standard Steering Hydrostatic Power Steering Hydrostatic power steering Brakes Wet Multi Disc Hydraulically operated wet disc brakes with automatic front axle engagement (4WD) Seat Suspension & Adjustability Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Air ride seat, swivel, reclining, fully adjustable (height, weight, fore and aft), arm rests, retractable seat belt Front Axle Type 4WD with outboard planetary final drives and limited-slip differential 4WD bevel gear type, on-the-go electro-hydraulic engagement, with electro-hydraulic front differential lock Front Axle Rating Not Published 6610 lb at 62.2 in tread (9700 lb with loader) Drawbar Capacity Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 170.8 in 165.4 in Overall Width 88.6 in 82.7 in Wheelbase 94.9 in 95.9 in Ground Clearance 18.9 in 19.5 in Min. Turn Radius without Brakes 12.7 ft (with brake applied) 16.1 ft (13.1 ft with Bi-Speed turn, 4WD on) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 111.9 in 111.8 in ▶ WeightTractor Weight (Base) 10,230 lb 9789 lb (cab, standard tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) Standard: 13.6 R24 front, 18.4 R34 rear (R1 options 12.4-24, 13.6-24 front; 16.9-34, 18.4R30, 18.4-34 rear) R1 Agricultural - Front 13.6-24 13.6 R24 R1 Agricultural - Rear 18.4-34 18.4 R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator LA1955: 2-lever quick coupler or Euro quick coupler; single-lever hydraulic quick coupler; quick attach/detach loader with boom stands and two mounting pins Loader Model KL1155 LA1955 Loader Lift Height KL1155: 150.6 in (to pivot pin) LA1955 (height position): 145.7 in; LA1955 (power position): 132.7 in Loader Lift Capacity (Full Height) KL1155: 4,216 lb (at pivot pins) LA1955 (height position): 4178 lb; LA1955 (power position): 4299 lb Loader Breakout Force KL1155: 8,554 lb (at pivot pins) LA1955 (height position): 5589 lbf; LA1955 (power position): 6576 lbf ▶ WarrantyWarranty Length & Coverage Tractors (Non-Commercial): 24 months parts & labor, unlimited hours, 0% deductible; powertrain (engine and driveline): 48 months unlimited hours on HX Series Not Published
