| Engine Manufacturer | KIOTI (Daedong) | FPT Industrial |
|---|
| Engine Model | 4J243TA-TP5B | F5G |
|---|
| Engine Type | In-Line Vertical, Water-cooled 4-Cycle Turbo Diesel, CRDI (4J243TA-TP5B) | 4-cylinder diesel, turbocharged and aftercooled |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 233.9 in³ | 207 in³ |
|---|
| Rated Engine Speed | 2200 rpm | 2300 rpm |
|---|
| Engine Power (Gross) | 115.3 hp | 117 hp |
|---|
| PTO Power | 83.9 hp | 100 hp |
|---|
| Engine Emissions Constraints | Not Published | Tier 4 |
|---|
| Cooling System Type | Water-cooled | Liquid-cooled |
|---|
| Air Cleaner | Dry element with evacuator valve | Not Published |
|---|
| Fuel System | Common Rail Direct Injection (CRDI) | Electronic high-pressure common rail fuel injection |
|---|
| Alternator | Not Published | ROPS: 120 A; Cab: 150 A |
|---|
|
|---|
| Pump Type | Gear | Open-center; dual pumps (implement pump plus dedicated steering pump) |
|---|
| Implement Flow | 19.8 gpm | 16.9 gpm |
|---|
| Steering Flow | 12.2 gpm | 9.7 gpm |
|---|
| Total Hydraulic Flow | 32 gpm | 26.6 gpm |
|---|
| Overall Hydraulic Pump Flow | 32 gpm | 26.6 gpm |
|---|
| Hydraulic System Type | Open Center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 3 | 2 rear remotes (open center with detent) |
|---|
| No. of Optional Remote Valves | 1 | 1 (third rear remote, DIA kit) |
|---|
|
|---|
| Fuel Tank Capacity | 47.6 gal | 30.3 gal |
|---|
| Coolant Capacity | 4.7 gal | Not Published |
|---|
| Crankcase Capacity | 3.9 gal | Not Published |
|---|
| Transmission / Hydraulic System Capacity | 20.34 gal | Not Published |
|---|
| Front Axle Fluid Capacity | 2.6 gal | Not Published |
|---|
|
|---|
| PTO Type | Independent | Fully independent hydraulic PTO |
|---|
| PTO Rear | 540 / 540E / 1000 rpm | 540/1000 rpm (standard, interchangeable shafts) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II | Category II |
|---|
| Hitch Lift Capacity | 8,079 lb | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 8,002 lb | 5,620 lb |
|---|
| Lift Control Type | Electronic control | Mechanical draft control; Lift-O-Matic PLUS single-lever raise/lower (standard) |
|---|
|
|---|
| Transmission Type | Power Shuttle w/ Hi-Lo Shift | 12x12 power shuttle, column-mounted (standard); 20x20 power shuttle with creeper (optional) |
|---|
| No. of Speeds | 24 forward / 24 reverse | 12F/12R (standard); 20F/20R with creeper (optional) |
|---|
| Max Travel Speed (Forward) | 23.83 mph | 27 mph (4WD front axle); 20 mph (2WD front axle) |
|---|
| Max Travel Speed (Reverse) | 23.67 mph | 27.25 mph (12x12, 4WD front axle, 18R34 tires) |
|---|
| Clutch | Wet Multi Disc | Not Published |
|---|
| Differential Lock & Limited Slip Options | Mechanical rear differential lock (standard); front limited-slip differential | Mechanical rear differential lock (pedal); limited-slip 4WD front axle with electrohydraulic engagement |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Hydrostatic Power Steering | Power steering |
|---|
| Brakes | Wet Multi Disc | Hydraulic wet disc |
|---|
| Seat Suspension & Adjustability | Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft | Cab: air-suspension cloth seat with armrests, 10° swivel (standard); ROPS: vinyl mechanical-suspension seat with armrests |
|---|
| Front Axle Type | 4WD with outboard planetary final drives and limited-slip differential | Limited-slip 4WD front axle with electrohydraulic engagement (standard); heavy-duty 2WD front axle (optional) |
|---|
| Front Axle Rating | Not Published | 10,360 lb (standard heavy-duty 4WD front axle, maximum capacity); 7,716 lb (optional 2WD heavy-duty front axle) |
|---|
| Drawbar Capacity | Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 170.8 in | 163.1 in (2WD); 160.9 in (4WD) |
|---|
| Overall Width | 88.6 in | 75.7 in |
|---|
| Wheelbase | 94.9 in | 92.2 in (2WD); 89.9 in (4WD) |
|---|
| Ground Clearance | 18.9 in | Not Published |
|---|
| Min. Turn Radius without Brakes | 12.7 ft (with brake applied) | 134 in (optional 2WD front axle, w/o brakes) |
|---|
| Height to Top of ROPS | Not Published | 106.5 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 111.9 in | 102.1 in |
|---|
|
|---|
| Tractor Weight (Base) | 10,230 lb | 6,988 lb (ROPS/2WD); 7,672 lb (ROPS/4WD); 7,473 lb (cab/2WD); 8,157 lb (cab/4WD) |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) | 2WD: 10.00-16 front, 18.4-30 rear; 4WD: 12.4-24 front, 18.4-30 rear (standard); 18.4R34 rear is the reference tire for weights and dimensions |
|---|
| R1 Agricultural - Front | 13.6-24 | 2WD: 10.00-16; 4WD: 12.4-24 |
|---|
| R1 Agricultural - Rear | 18.4-34 | 18.4R34 (reference tire for OEM weights and dimensions) |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator | Skid-steer-style or Euro-style quick attach faceplate (optional, all four LU loaders) |
|---|
| Loader Model | KL1155 | 710LU (NSL); 715LU (MSL); 720LU (NSL); 725LU (MSL) |
|---|
| Loader Lift Height | KL1155: 150.6 in (to pivot pin) | 710LU: 126.3 in; 715LU: 125.9 in; 720LU: 134 in; 725LU: 135 in |
|---|
| Loader Lift Capacity (Full Height) | KL1155: 4,216 lb (at pivot pins) | 710LU: 3,461 lb; 715LU: 3,573 lb; 720LU: 3,849 lb; 725LU: 4,204 lb |
|---|
| Loader Breakout Force | KL1155: 8,554 lb (at pivot pins) | 710LU: 3,739 lb; 715LU: 3,860 lb; 720LU: 4,455 lb; 725LU: 5,661 lb (31.5 in forward of the bucket pivot point) |
|---|
|
|---|
| Warranty Length & Coverage | Tractors (Non-Commercial): 24 months parts & labor, unlimited hours, 0% deductible; powertrain (engine and driveline): 48 months unlimited hours on HX Series | Not Published |
|---|
