Kioti NX5510 vs Kubota L5460HSTC

Across 9 measurable specs, the Kioti NX5510 leads 5 categories to 4. Machine pages: Kioti NX5510 and Kubota L5460HSTC.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	KiotiNX5510	KubotaL5460HSTC

▶Engine
Engine Manufacturer	KIOTI (Daedong)	Kubota
Engine Model	3F183T	V2403-CR-TE4-GL3
Engine Type	KIOTI 3 Cylinder, In-Line Vertical, Water-Cooled 4-Cycle Turbo Diesel, CRDI	Liquid-cooled, 4-cycle multi valve, diesel, Turbocharged
No. of Cylinders	3	4
Displacement	111.4 in³	148.5 in³
Rated Engine Speed	2600 rpm	2600 rpm
Engine Power (Gross)	55 hp	56 hp
PTO Power	46 hp	46.5 hp
Engine Emissions Constraints	Tier 4	Tier 4
Cooling System Type	Water-cooled	Liquid-cooled
Air Cleaner	Dry type element	Dry paper, dual element
Fuel System	Common Rail Direct Injection (CRDI)	Electronic Common Rail System (CRS)
Alternator	Not Published	60 A, 12 V
▶Hydraulics
Pump Type	Gear	Tandem pump - gear type
Implement Flow	8.2 gpm	9.4 gpm
Steering Flow	8.2 gpm	4.7 gpm
Total Hydraulic Flow	16.5 gpm	14.1 gpm
Overall Hydraulic Pump Flow	16.5 gpm	14.1 gpm
Hydraulic System Type	Open Center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	1	Not Published
No. of Optional Remote Valves	1	Optional, up to 3 (double-acting valve or float detent valve options, any position)
▶Fluid Capacity
Fuel Tank Capacity	14.8 gal	13.5 gal
Coolant Capacity	2.0 gal	8.7 qt
Crankcase Capacity	1.58 gal	9.9 qt
Transmission / Hydraulic System Capacity	14.53 gal	11.9 gal
Front Axle Fluid Capacity	1.8 gal	8.9 qt
▶PTO & Hitch
PTO Type	Independent	Live independent (hydraulic clutch)
PTO Rear	540 rpm	540 rpm @ 2400 engine rpm
Mid-PTO Availability	Optional (2,000 rpm)	Optional
Category, 3-Point Hitch	Category I & II	SAE Category 1 & 2
Hitch Lift Capacity	3,538 lb	3,858 lb
Hitch Lift Capacity (at 24”)	3,177 lb	2,976 lb
Lift Control Type	Position with Draft Control	Position control
▶Transmission & Drivetrain
Transmission Type	Synchro Shuttle	Hydrostatic transmission
No. of Speeds	24x24	3-range, 6 speeds (H-DS), infinitely variable in each
Max Travel Speed (Forward)	17.35 mph	16.8 mph
Max Travel Speed (Reverse)	15.42 mph	15.2 mph
Clutch	Dry Type Single Stage	Not Published
Differential Lock & Limited Slip Options	Differential Lock: Rear (Standard)	Rear differential lock, standard
▶Chassis, Steering & Controls
Frame Type	Not Published	Not Published
Steering	Hydrostatic Power Steering	Hydrostatic power steering
Brakes	Wet Multi Disc	Wet disc type, mechanically activated
Seat Suspension & Adjustability	Adjustable Seat	Suspension seat with fore/aft travel adjustment, suspension adjust knob, backrest tilt adjustment, swivel and arm rest
Front Axle Type	Not Published	4WD: Bevel gear front axle, non-adjustable tread spacing
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	1,655 lb (max. drawbar vertical load)	1,433 lb
▶Dimensions & Maneuverability
Overall Length with 3-Point Hitch	139.6 in	135.0 in
Overall Width	65.7 in	67.3 in
Wheelbase	75.6 in	75.4 in
Ground Clearance	15.7 in	15.4 in
Min. Turn Radius without Brakes	10.0 ft	9.2 ft (with brake applied)
Height to Top of ROPS	103.1 in	Not Applicable
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	Not Published	92.5 in
▶Weight
Tractor Weight (Base)	4,209 lb	4,365 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	R1 Agricultural, R3 Turf, R4 Industrial	Standard R1 (9.5-16 / 14.9-26); options: R1 (9.5-16 / 13.6-28), R4 (10-16.5 / 17.5L-24), R3 (29x12.50-15 / 44x18-20), LSW R3 (LSW305R343 / LSW610R470)
R1 Agricultural - Front	9.5-16	9.5-16
R1 Agricultural - Rear	16.9-24	14.9-26; 13.6-28
R3 Turf - Front	29-12.5-15	29X12.50-15
R3 Turf - Rear	21.5L-16.1	44X18-20
R4 Industrial - Front	10-16.5	10-16.5
R4 Industrial - Rear	17.5-24	17.5L-24
▶Loader & Attachments
Quick Attach Loader System	Built-in parking stand; quick attach/detach; single-lever joystick control with float; bucket level indicator	Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional)
Loader Model	KL6010	LA1055
Loader Lift Height	KL6010: 108.3 in (to pivot pin)	112.7 in
Loader Lift Capacity (Full Height)	KL6010: 2,761 lb (at pivot pin, max height)	2361 lb
Loader Breakout Force	KL6010: 3,727 lb (at pivot pin)	3171 lbf (19.7 in forward of pivot pin)
▶Warranty
Warranty Length & Coverage	Non-commercial tractor: 24 months, unlimited hours, parts & labor; non-commercial powertrain (engine and driveline): 72 months, unlimited hours, parts & labor	Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
▶ITC Company Accessories
Accessories that fit	Kioti NS/NX Brush Screen Insert $265.00 Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection	Kubota Grand L60 Series Brush Guard Insert (L3560-L6060) $289.00

Find a KIOTI dealer near you→Find a Kubota dealer near you→

Kioti NX5510 vs Kubota L5460HSTC: Quick Answers

Which has more horsepower, the Kioti NX5510 or the Kubota L5460HSTC?

The Kubota L5460HSTC leads on engine hp at 56 hp hp, compared to 55 hp hp for the Kioti NX5510.

Which has more PTO horsepower, the Kioti NX5510 or the Kubota L5460HSTC?

The Kubota L5460HSTC leads on pto hp at 46.5 hp hp, compared to 46 hp hp for the Kioti NX5510.

Which is heavier, the Kioti NX5510 or the Kubota L5460HSTC?

The Kubota L5460HSTC leads on weight at 4,365 lb lb, compared to 4,209 lb lb for the Kioti NX5510.

Which has more loader lift capacity, the Kioti NX5510 or the Kubota L5460HSTC?

The Kioti NX5510 leads on loader lift at 2,761 lb lb, compared to 2,361 lb lb for the Kubota L5460HSTC.

Which has more three-point hitch lift capacity, the Kioti NX5510 or the Kubota L5460HSTC?

The Kioti NX5510 leads on 3-pt lift (24 in) at 3,177 lb lb, compared to 2,976 lb lb for the Kubota L5460HSTC.
